Model #
EV-5105-N1SQ
EV-5105-P1SQ
Features:
Wide angle lens
960H high resolution
Weatherproof IP67 construction
Vandal-resistant design
Wall-Plate Cameras
Manual
Video Output
NTSC
PAL
®
Effective Pixels
976x494 pixels
976x582 pixels
Adjustable mounting angle
Includes: 1 camera, 1 single-gang plate,
1 slimline plate, and angled mounting rings
WDR and 2DNR
Advertisement
Table of Contents
Related Manuals for SECO-LARM ENFORCER EV-5105-N1SQ
Summary of Contents for SECO-LARM ENFORCER EV-5105-N1SQ
- Page 1 Wall-Plate Cameras Manual Model # Video Output Effective Pixels EV-5105-N1SQ NTSC 976x494 pixels EV-5105-P1SQ 976x582 pixels Features: Wide angle lens Adjustable mounting angle 960H high resolution Includes: 1 camera, 1 single-gang plate, Weatherproof IP67 construction 1 slimline plate, and angled mounting rings ...
- Page 2 1x Aluminum hex nut 1x Manual Parts list for the EV-5105-N1SQ shown Dimensions: Single-gang plate Slimline plate Camera body " (70mm) " (38mm) " (38mm) " (22mm) " " " " (28mm) (22mm) (114mm) (114mm) Dimensions for the EV-5105-N1SQ shown SECO-LARM U.S.A., Inc.
- Page 3 " (22mm) hole into the wall to fit the camera Install the angled rubber ring on the front of the plate body. If mounting to a thick surface, it may not be so that the camera is tilted (approximately 20°). necessary to use the angled rings. SECO-LARM U.S.A., Inc.
- Page 4 WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for three (3) years from the date of sale to the original customer. SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if...
