BHG Sullivan Ridge 10' x 10' steel hard top gazebo with net,
steel without E-coat
ASSEMBLY INSTRUCTIONS
ITEM# BH17-092-097-23
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
Questions, problems, missing parts with this product? Do not return to your
retailer,please call our customer service department 9:00 a.m. to 5:00 p.m.
Eastern Standard Time Monday through Friday Phone # 1-800-457-4652
or
contact us at www.numarkcustomerservice.com
DON'T RETURN TO STORE
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BHG BH17-092-097-23
Summary of Contents for BHG BH17-092-097-23
- Page 1 BHG Sullivan Ridge 10' x 10' steel hard top gazebo with net, steel without E-coat ASSEMBLY INSTRUCTIONS ITEM# BH17-092-097-23 ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE INTENDED FOR RESIDENTIAL USE ONLY. Questions, problems, missing parts with this product? Do not return to your retailer,please call our customer service department 9:00 a.m.
- Page 2 WARNINGS AND CAUTIONS ＊It is essential to place the gazebo on level ground and not less than 6 feet from any obstruction such as fences, garages, the house, overhanging branches, laundry lines, or electrical wires. Assembly by at least eight adults is recommended. ＊...
- Page 3 Remove all components from the polybag and unwrap all package materials. Please count the components, there are: Part Description Quantity Top Beam Top Beam Short Canopy Frame Bar Long Canopy Frame Bar Connection Ring Long Connect Bar Long Connect Bar Short Connect Bar Short Connect Bar Small Canopy...
- Page 4 Quantity Description Part Bowl-shaped Cover Large Upper Roof Cover Large Upper Roof Cover Large Upper Roof Cover Large Upper Roof Cover Large Upper Roof Cover Large Upper Roof Cover Short Large Canopy Cover Slat Long Large Canopy Cover Slat Leg Post Base Plate Post Base L-shaped...
- Page 5 DON’T RETURN TO STORE...
- Page 6 ACCESSERY Part Description Quantity 96+3 Spare M6x15L Bolt 24+1 Spare M6x20L Bolt 8+1 Spare M6x30L Bolt 24+1 Spare M6x36L Bolt 16+1 Spare M6x50L Bolt M8x45L Bolt Small Metal Washer 16+1 Spare M6 Nut M6x12 Countersink 8+1 Spare Screw 8+1 Spare Lock Washer Lawn Stake M6 Large Metal...
- Page 7 Step 1 Rg x 12 Ra x 12 M6x15L Bolt Small Metal Washer Don’t secure bolt into this hole at this step Don’t tighten completely. Repeat procedure for the other 3 top beams. Step 2 Repeat procedure for the other 3 small canopy bars. DON’T RETURN TO STORE...
- Page 8 Step 3 Ra x 4 Rg x4 M6 x 15 Bolt Small Metal Washer Don’t tighten completely. Repeat procedure for the other 3 holes. Tighten all bolts of above steps. Step 4 Rb x 8 Rg x 16 Rh x 4 Re x 4 Small Metal Washer M6 x 50 Bolt...
- Page 9 Step 5 Rh x 4 Rb x 8 Re x 4 Rg x 16 Small Metal Washer M6 x 50 Bolt M6 x 20 Bolt Don’t tighten completely. Repeat procedure for remaining 3 canopy frame bars. Step 6 Rg x 16 Rh x 8 Re x 8 Small Metal Washer...
- Page 10 Step 7 Rg x 8 Rc x 8 Small Metal Washer M6x30L Bolt NOTE: Top label facing upside. Don’t tighten completely. Repeat procedure for other small upper roof covers and small canopy cover slat. Tighten all bolts of this step. Step 8 Rf x 1 M8x45L Bolt...
- Page 11 Step 9 Rl x 4 Ra x 20 Rg x 16 M6x15L Bolt Large Metal Washer Small Metal Washer 15-2 15-1 NOTE: Top label facing upside. Don’t tighten completely. Repeat procedure for other large upper roof covers(K1& K6). Step 10 Ra x 20 Rg x 16 M6x15L Bolt...
- Page 12 Step 11 Rg x 16 Ra x 16 M6x15L Bolt Small Metal Washer NOTE: Top label facing upside. Don’t tighten completely. Repeat procedure for other large upper roof covers(K3&K4). Tighten all bolts of above steps. Step 12 Rg x 12 Rd x 12 M6 x 36 Bolt Small Metal Washer...
- Page 13 Step 13 Rd x 12 Rg x 12 M6x36L Bolt Small Metal Washer Don’t tighten completely. Repeat procedure for other short large canopy cover slats. Securely tighten all bolts for all above steps. Step 14 Ri x 8 M6x12L Bolt Securely tighten all bolts.
- Page 14 Step 15 Rg x 8 Rj x 8 Rb x 8 M6x 20L Bolt Small Metal Washer Locker Washer Don’t tighten completely. Repeat procedure for the remaining three leg posts. Step 16 Ra x 16 M6 x 15 Bolt Rg x 16 Small Metal Washer Rg Ra Repeat procedure for the remaining three leg posts.
- Page 15 Step 17 Rg x 8 Ra x 8 Small Metal Washer M6x 15L Bolt Securely tighten all bolts. Repeat procedure for the remaining 3 “L” shaped plates. Step 18 Rk x 16 Lawn Stake DON’T RETURN TO STORE...
- Page 16 Step 19 Your gazebo with net is now ready for use. DON’T RETURN TO STORE Printed in China...
