assembly
Installation above cupboards or drawers
Under hob access must be restricted by the addition of a
board mounted at least 20mm from underside of hob.
Installation above cupboards or drawers
Under hob access must be mounted at least 20mm from
top of appliance.
14 ASSEMBLY Ceramic Cooktops
min. 20mm
min. 20mm
min.
25mm
min.
25mm
