Specifications; Installation - K+R Performance Engineering PRO-CUBE Installation And Operating Manual

Pro Cube
Pro-Stage ä:
staging process. Developed by Frank Hawley, the patented Pro-Stage
stage with your foot to the floor for both Pro tree and Full tree. Provides better driver concentration,
more consistency, and reduced wear and tear on the engine and converter.
Output Protection:
electronic circuit breaker technology. Faulty outputs are indicated by flashing light on the front
panel, allowing fast diagnosis and correction of system problems.
OPTIONS
1 Timer: 4 stages (2 on/off cycles), first on/off cycle adjustable from 0.000 - 9.999 seconds, second
on/off cycle adjustable from 0.00 - 39.99 seconds. Bump-Down Ò can be used during the
run to make minor adjustments to your settings.
2 Timers: Timer 1 is same as above. Timer 2 has 2 stages (1 on/off cycle) adjustable from 0.00 - 39.99
seconds.
3 Timers: All 3 timers have 2 stages (1 on/off cycle each). Timer 1 adjustable from 0.000 - 9.999
seconds, timer 2 and 3 adjustable from 0.00 - 39.99 seconds.

SPECIFICATIONS

Overall Dimensions (H x W x D):
Weight:
Power Supply Voltage:
Power Supply Input Current (no outputs activated):
Output Current, Transbrake:
Output Current, Line Lock:
Output Current, Timers and Pro-Stage ä:

INSTALLATION

1. Mount the unit in a convenient location where you can easily read the display and reach the front
panel when strapped in the driver's seat.
2. Refer to the wiring diagram for electrical connections.
3. IN ORDER TO DAMPEN VIBRATION, THE UNIT MUST BE MOUNTED USING THE THREE
RUBBER MOUNTS LOCATED ON THE BACK.
MAINTAINED ALL AROUND THE UNIT SO THAT IT DOESN'T VIBRATE AGAINST ANY
SURROUNDING METAL. NOTE: RUBBER MOUNTS ARE NOT REMOVEABLE.
4. FOR THRU-DASH INSTALLATIONS ALLOW CLEARANCE BETWEEN DASH AND UNIT AND
USE FIRM RUBBER MOLDING TO FILL THE GAP. THE UNIT MUST FIT SNUG IN OPENING.
ALWAYS COMPLETELY DISCONNECT THE UNIT BEFORE ANY WELDING IS DONE ON
5.
THE CHASSIS.
1
Pro-Stage™
is protected by US Patents 5,839,419 and 5,855,196
This special output controls a Pro-Stage ä compatible throttle stop during the
All outputs are fully protected against shorts and severe overloads by advanced
4.3" x 4.7" x 2.95"
1.3 lbs
10 - 18 Vdc
0.08 Amps
25 Amps for 1 minute
2 Amps continuous
10 Amps continuous
! Important
SUFFICIENT CLEARANCE SHOULD BE
.
2
K+R Performance Engineering, Inc.
system 1 allows you to
™
