Riedel CCP1116 Quick Manual

Riedel CCP1116 Quick Manual

Commentary control panel

Advertisement

CCP1116
Commentary Panel

Quick Guide

Document Reference 1.2
S.Franke
01/2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCP1116 and is the answer not in the manual?

Questions and answers

Summary of Contents for Riedel CCP1116

  • Page 1: Quick Guide

    CCP1116 Commentary Panel Quick Guide Document Reference 1.2 S.Franke 01/2013...
  • Page 2 © 2013 Riedel Communications GmbH & Co KG. All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Riedel. Every effort has been made to ensure that the information in...
  • Page 3: Table Of Contents

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 TABLE OF CONTENT 1 CONTROL ELEMENTS - DESCRIPTION .......................... 4 2 CONNECTORS .................................. 5 Connectors front side ................................5 Connectors rear side ................................6 3 REAR SIDE - DIP SWITCHES ............................7 4 AUDIO BLOCK DIAGRAM ..............................
  • Page 4: Control Elements - Description

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 1 CONTROL ELEMENTS - DESCRIPTION Function Description AUX 1 ON Activating the button: Mixes analog input „AUX 1“ from the rear side to the Headphones (depending of the dip-settings on the rear side to the left-, right- or both ears).
  • Page 5: Connectors

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 Intercom Mic Connector for standard Artist microphones. Normally not used for commentary mode, only when the CCP-1116 is used as ordinary Intercom panel. Function keys Standard Artist panel function keys (Shift, HS, OPT, F1, F2) + Master Volume. ATTENTION: The Master Volume is not influencing the volume of Phones A or B Speaker Panel speaker.
  • Page 6: Connectors Rear Side

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 2.2 Connectors rear side 10 11 13 14 Function Connector Type Artist Pin out Main Input 90-265V, 47-63Hz Pin 1: GND Pin 2: n.c. DC EXT. 12V Pin 3: n.c. Pin 4: +10 …+14VDC (3A) XLR4 male Pin 1: OUT - ( >...
  • Page 7: Rear Side - Dip Switches

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 3 REAR SIDE - DIP SWITCHES Example for Commentator A. Identical functionality for Commentator B Function Group Function Description PHONES MODE MIC A Routes MIC A signal (Sidetone) to left-(L), right- (R), or both ears (M) PHONES MODE MIC B Routes MIC B signal to left-(L), right- (R), or both ears (M)
  • Page 8: Audio Block Diagram

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 4 AUDIO BLOCK DIAGRAM Page 8...
  • Page 9: Director Configuration Of A Ccp-1116

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 5 DIRECTOR CONFIGURATION OF A CCP-1116 When you want to use the CCP-1116 Commentary panel with its full functionality for 2 commentators, you have to adapt some configuration settings in the Director. First you have to create a new CCP-1116 on an odd digital port (for 2channel operation) and activate „enable 2nd Audio channel“...
  • Page 10: Key Assignment Commentator A/B

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 5.1 Key assignment Commentator A/B Attention: The commentator Function buttons, like „ON AIR, MIC Mute, AUX1, AUX2, etc“ cannot be configured and monitored in Remote control in the Director. They are just showing the Design of the CCP-1116.
  • Page 11 CCP-1116 Commentary Control Panel – Quick Guide 1.2 Commentator A -> B Commentator B -> A Please keep in mind, that on audio functions on other ports to call/listen to the Commentator B also the 2 audio channel of the CCP-1116 have to be used. Therefore you have to activate the flag “to 2 channel”...
  • Page 12: Gpio Functions

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 5.2 GPIO functions Open the „Properties“ of the CCP-1116 to define the GPIOs. GPIO IN 1 and 2 can be used within the Artist system to signalize activated „ON AIR“ buttons on the CCP-1116 somewhere and somehow in the system.
  • Page 13: Commentary Audiopatch Settings

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 5.3 Commentary Audiopatch settings Finally you have to adjust the internal audio routing of the Audio patches in the CCP-1116. Up to Director Version 6.50 the audio in-and outputs of the Audio patches are used inside the CCP- 1116 as follows: Audiopatch INPUT CCP-1116 connector...
  • Page 14 CCP-1116 Commentary Control Panel – Quick Guide 1.2 Up to Director Version 6.50: For the basic commentator functionality you have to adjust the Audiopatch for Speaker AND Headset mode minimum as follows: Up from Director 6.60 the labels of the audio IOs are showing the correct names of a CCP and the basic crosspoints within the Audiopatch are already set as default.
  • Page 15: Panel Test / Config Mode

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 6 PANEL TEST / CONFIG MODE The CCP-1116 panel also has an internal Setup-Menu available, to edit basic settings of the panel or for testing. Therefore you have to press “Shift”+”F1”+”F2” simultaneous to reboot the panel. Immediately press the “F1”...
  • Page 16: Config

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 In the “Key Test” mode you can test all key-contacts, rotary encoders, encoder switches and LEDs. Every time you press a button or turn an encoder, the half side color on the responsible OLED- display will change.
  • Page 17: Pan Type

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 6.3.2 Pan Type For some reasons it is necessary, to change the panel type information that is sent to the Director. For example if you want to use the CCP panel with an Artist version older 6.40 where the CCP is not directly supported.
  • Page 18: Specifications

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 7 SPECIFICATIONS POWER Internal Power Supply 90 – 253V AC (47-63Hz) max 35VA Power supply redundancy via external power supply 10 – 16V DC via XLR4 MICROPHONE INPUT (MIC A IN, MIC B IN) Coupling Transformer Phantom Power...
  • Page 19: Service

    For repairs, please contact your local distributor. Your distributor will help you with the repair process and with securing replacement parts. The address for sending repairs directly to Riedel Communications GmbH & Co. KG is: Riedel Communications GmbH & Co. KG - Repairs - Uellendahler Str.
  • Page 20: Notes

    CCP-1116 Commentary Control Panel – Quick Guide 1.2 9 NOTES Page 20...
  • Page 21 CCP-1116 Commentary Control Panel – Quick Guide 1.2 Page 21...
  • Page 22 CCP-1116 Commentary Control Panel – Quick Guide 1.2 Riedel Communications GmbH & Co. KG • Uellendahler Str. 353 • 42109 Wuppertal • Germany Phone: +49 (0) 202 292-90 • Fax: +49 (0) 202 292-99 99 • sales-international@riedel.net Wuppertal • Beijing• Berlin • London • Los Angeles • Singapore • Sydney • Vienna • Zurich www.riedel.net...
