- Page 1 BARTELL MORRISON INC. 375 Annagem Blvd., Mississauga, ON L5T 3A7 Telephone: 1-647-953-4100 Fax: 1-647-953-4101 MASONRY SAW BSM1402 OWNER’S MANUAL www.BARTELLGLOBAL.com Doc. # OI-B19042 Orig. Rel. – 02/2017 Curr Rev. - 00...
- Page 2 No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written permission of Bartell Morrison Inc. unless such copying is permitted by federal copyright laws.
-
Page 3: Safety Precautions
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL SAFETY PRECAUTIONS DANGER EXPLOSION HAZARD Never operate the machine in an explosive atmosphere, near combustible materials or airborne dust, or in areas if inadequate ventilation. CAUTION ROTATING HAZARD Never place hands or fingers inside safety guard or near rotating blade. -
Page 4: Table Of Contents
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL TABLE OF CONTENTS WARRANTY INFORMATION SAFETY INFORMATION FEATURES SPECIFICATIONS HEALTH WARNING UNPACKING SET UP TAND OLDABLE ASSEMBLY AND OPERATION L ADE NSTALL ATION ATER NSTALLATION HEEL NSTALL ATION SING THE UTTING ABLE... -
Page 5: Warranty Information
OWNER’S MANUAL WARRANTY INFORMATION All products sold by Bartell Morrison Inc. and Bartell Morrison (USA) LLC (the “Company”) are warranted against defects in materials and/or workmanship for a period of 12 months; excluding the normal wear on wearing components and components covered by a separate original manufacturer’s warranty. -
Page 6: Safety Information
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL SAFETY INFORMATION Before using this equipment, study the entire owner’s manual to become familiar with its operation. Do not allow untrained or unauthorized personnel, especially children, to operate this equipment. Use only factory authorized parts for service. - Page 7 OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL behavior of the machine) must be reported to the supervisor. If necessary, stop the machine at once and secure it. In the case of a malfunction, stop the machine immediately and secure it. Fix the problem as soon as possible.
-
Page 8: Features
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL FEATURES Heavy Duty Power Switch Prevents the motor from overheating and protects the saw from power High Plunge Handle surges Provides a convenient handle for Cutting Reference Marks better user leverage during plunge... -
Page 9: Health Warning
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL HEALTH WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •... -
Page 10: Set Up
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL SET UP Saw Stand Foldable Legs To deploy the foldable legs, unscrew the wing bolts located at the corner of the frame of the leg to be deployed. Only unscrew the wing bolts far enough so that the leg is movable. Do not remove the wing bolts. -
Page 11: Assembly And Operation
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL ASSEMBLY AND OPERATION Blade Installation Open the blade nut door found on the blade guard by rotating it. Using the supplied wrench, loosen the nut. Remove the nut and the outer flange. -
Page 12: Wheel Installation
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Wheel Installation Wheel assembly can be installed on the frame or the rear folding legs (see figure 6). To remove the wheel assembly, slide the spring pin out of its current slot and pull the wheel out. -
Page 13: Performing Straight Cuts
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Performing Straight Cuts Set the rip guide at the desired location on the ruler guide and tighten the threaded knob. Make sure the rip guide is firmly tightened to avoid slippage. After the rip guide is positioned for the desired cut, place the material being cut flat against the side of the rip guide and the ruler guide. -
Page 14: Setting The Cutting Depth
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Setting the cutting Depth Blade Diam eter Cutting Depth 10” 2” 12” 3⅜” 14” 4½” WARNING: Setting the blade too low may damage the cutting table and if set too high, the blade may grab the material being cut, possibly causing injury to the operator and the saw. -
Page 15: Proper Blade Use
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL PROPER BLADE USE Don’ts • • Inspect blades daily for cracks or uneven Do not operate the saw w ithout w ear. safety guards in position. Blades • • Alw ays use... -
Page 16: Care And Maintenance
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL CARE and MAINTENANCE WARNING: For your safety, before performing any maintenance on the saw turn OFF the power switch and UNPLUG the power cord. General Rules • Always clean the machine before performing any maintenance/repair. -
Page 17: Prolonged Period Of Non-Use
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL • Rinse the immersion pump with fresh water to prevent the water pump from clogging with residual dirt. After wet cleaning and b efore using the machine again: Connect the machine to an electric power outlet equipped with a “GFCI” safety power breaker. -
Page 18: Belt Replacement
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Take the lid off the pump. Be careful not to damage or lose the gasket underneath. Clean the pump lid. Remove all dirt and incrustations from the pump wheel. Check whether the pump wheel can be easily turned. -
Page 19: Realignment
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Realignment Method 1: This procedure deals with the most common source of misalignment that occurs when the guide rails are not parallel with the blade. Set the cutting depth such that the blade passes through the table, not over. - Page 20 OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL If the straight edge only touches the blade when the table is positioned midway along the rail or at the ends of the rail, then the rail may be deformed (i.e. bowed) (figure 10).
-
Page 21: Leveling Adjustment
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL After adding shim(s), mount the table back onto the guide rails. Realign the table to the blade using Method 1. Check to see if any shifting persists. A shift tolerance of 0.5mm is allowed. -
Page 22: Electrical Specifications
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Square figure 13 7. The square face closest to the blade should be parallel to the blade. If it is not, raise/lower both flat rollers until it is level. 8. The table should now be level and square with the blade. If it is not repeat previous steps 2 thru 7. -
Page 23: Extension Cord Chart
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Extension Cord Chart WARNING: To avoid permanent motor damage, you must use the correct extension cord. Never use more than one extension at a time. Follow the chart below for proper size. -
Page 24: Troubleshooting
OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL TROUBLESHOOTING Problem Possible Cause Solution Machine does not run w hen Pow er cord not properly fixed/ Check that the machine is sw itched on plugged in properly connected to the pow er... - Page 25 OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Drive motor no longer runs at Have the motor checked by a rated speed (RPM) qualified electrician and have it replaced if necessary Problem Possible Cause Solution Insufficient flow of cooling w ater...
- Page 26 OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Shaft of motor causes w obbling Have bearings of the motor or the motor replaced Overheating Ensure optimum flow of cooling w ater Cracks in or near the diamond Saw blade too hard...
- Page 27 OI – B19042 BSM1402 MASONRY SAW OWNER’S MANUAL Check the receiving flange and have it replaced if necessary Saw blade show s blooming colors Saw blade overheating due to a Ensure an optimum flow of lack of cooling w ater...
- Page 28 Bartell Morrison Inc. Bartell Morrison (USA) LLC 375 Annagem Boulevard 200 Commerce Drive, Unit A Mississauga, Ontario, Canada Freehold, New Jersey, USA L5T 3A7 07728 Tel: 1-647-953-4100 Tel: 1-848-225-8100 Fax: 1-647-953-4101 Fax: 1-848-225-8101 Innovatech SPE International Honeyholes Lane 832 80th Street SW...
