DUAL ZONE WINE CHILLER / VINERA CON 2 ZONAS
Model Numbers / Nos. de Modelos:
WCR534WDZD – N
WCR534WDZD – M (Mahogany Finish) / (Color Caoba)
WCR534WDZD – E (Espresso Finish) / (Color Espresso)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 16.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
(Natural Finish) / (Color Natural)
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Advertisement
Table of Contents
Related Manuals for Avanti WCR534WDZD E
Summary of Contents for Avanti WCR534WDZD E
- Page 1 INSTRUCTIONS. La sección en español empieza en la página 16. Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc.
-
Page 2: Table Of Contents
Power Failure Vacation Time Moving Your Wine Chiller Energy Saving Tips Troubleshooting Guide Service for Your Appliance Wiring Diagram Your Avanti Products Warranty Instrucciones en Español Registration Information and Registration Card TABLE OF CONTENTS 10 – 11 16 – 18... -
Page 3: Appliance Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. -
Page 4: Important Safeguides
Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precaution, including the following: •... -
Page 5: Help Us Help You
Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period. -
Page 6: Parts And Features
PARTS & FEATURES 1. WOODEN COUNTERTOP 2. WOODEN DOOR 3. WOODEN CABINET 4. RECESSED HANDLE 5. DIGITAL CONTROL PANEL 6. VENTILATION GRILLE 7. LEVELING LEGS 8. ROLL-OUT SHELVES (5) 9. SMALL BOTTOM SHELF (1) -
Page 7: Important Safety Instructions
(ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized Avanti Products service center. To reduce the risk of fire, electrical shock,... -
Page 8: Electrical Connection
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products service center. This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock. -
Page 9: Operating Your Wine Chiller
It is recommended you install the Wine Chiller in a place where the ambient temperature is between 72-78 degrees Fahrenheit. If the ambient temperature is above or below recommended temperatures, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. -
Page 10: Storage
• When you store mostly white wines, you can store them in the TOP ZONE or BOTTOM ZONE. When you use the BOTTOM ZONE, the temperature can be set at between 55 to 57°F/13º to 14ºC and the green LED lamp marked “WHITE” will be lit. When you use the TOP ZONE, the temperature can be set at between 48 to 55°F/9 to 13ºC and the green LED lamp marked “WHITE”... - Page 11 • To remove the shelves out of the rail pull each shelf approximately 60% out. Use a long flat screwdriver to press down the right plastic notch as shown in Figure A and at the same time lift the left plastic notch as shown in Figure B. Then proceed to pull out the shelf slowly. Contact our service department if assistance is needed.
-
Page 12: Care And Maintenance
CLEANING YOUR WINE CHILLER • Turn off the power, unplug the appliance, and remove all items including shelves. • Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. •... -
Page 13: Troubleshooting Guide
PROBLEMS WITH YOUR WINE CHILLER? You can solve many common Wine Chiller problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM Wine Chiller does not operate. -
Page 14: Service For Your Appliance
We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti appliances. With the purchase of your Avanti appliance, you can have the confidence that if you ever need additional information or assistance, the Avanti Products Customer Service team will be here for you. -
Page 15: Your Avanti Products Warranty
In rental or commercial use, the warranty period is 90 days. Avanti Products will provide you with a reasonably similar replacement product that is either new or factory refurbished. All Avanti Appliances of 3.5 cubic feet capacity... -
Page 16: Instrucciones En Español
INSTRUCCIONES DE SEGURIDAD Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable a tierra con una enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado correctamente y conectado a tierra. -
Page 17: Luz Interior
Temperaturas recomendadas para enfriar vinos: Vinos tintos Vinos blancos / secos Vinos rosé / Zinfandel Vinos blanco / espumante Para encender el electrodoméstico, oprima el botón marcado En la fábrica se programa la zona superior a los 50ºF (10ºC). La zona inferior se programa a los 60ºF (16ºC). Ud puede cambiar de grados Centígrados a Fahrenheit o viceversa, oprimiendo el botón marcado ºF/C . - Page 18 DESCONGELACION Su refrigerador para vinos ha sido diseñado con un sistema de descongelación de “ciclo automático”. Las superficies refrigeradas del compartimiento para vinos se descongela automáticamente, durante el ciclo “apagado” del control de enfriamiento (termostato). El agua descongelada del compartimiento es eliminada automáticamente, encauzándola hacia una bandeja de goteo ubicado en el compresor.
-
Page 19: Registration Information And Registration Card
REGISTRATION INFORMATION Thank you for purchasing this fine Avanti products. Please fill out this form and return it within 100 days of purchase and receive these important benefits to the following address: Avanti Products, A Division of The Mackle Co., Inc. -
Page 20: Printed In China
PRINTED IN CHINA...
