BUILT -IN DUAL ZONE WINE CHILLER / VINERA CON 2 ZONAS
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
WC5101DZD / WCR5104DZD / WCR524SDZD
Model Numbers / No. de Modelos:
(Picture May Vary)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 20.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Advertisement
Table of Contents
Related Manuals for Avanti WCR524SDZD, WCR5104DZD, WC5101DZD
Summary of Contents for Avanti WCR524SDZD, WCR5104DZD, WC5101DZD
- Page 1 INSTRUCTIONS. La sección en español empieza en la página 20. Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc.
-
Page 2: Appliance Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manua l and on your appliance. Always read and obey all safety messages . This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. -
Page 3: Important Safeguides
IMPORTA NT SAFEGUIDES Before the appliance is used, it must be properly positioned and installed as described in this manual , so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precaution, including the following: Plug into a grounded 3 -prong outlet, do not remove grounding prong, do not use an ad apter, and do not use an extension cord. -
Page 4: Registration Information
REGISTRATION INFORMATION Thank you for purchasing this fine Avanti products. Please fill out this form and return it within 100 days of purchase and receive these important benefits to the following address: Avanti Products, A Division of The Mackle Co., Inc. -
Page 6: Help Us Help You
Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period. -
Page 7: Parts And Features
PARTS & FEATURES (Only for WC5101DZD) 1. COUNTERTOP 2. DIGITAL CONTROL PANEL 3. GLASS DOOR RECESSED HANDLE LARGE SHELVES (TOTAL 5) 6. MIDDLE PARTITION 7. BOTTOM SMALL SHELF (TOTAL 1) 8. BOTTOM GRILLE 9. LEVELING LEGS 10. SECURITY LOCK 11. CABINET... - Page 8 PARTS & FEATURES (Only for WCR5104DZD / WCR524SDZD) 1. COUNTERTOP 2. DIGITAL CONTROL PANEL 3. STAINLESS STEEL DOOR 4. STAINLESS STEEL HANDLE 5. ROLL-OUT SHELVES (TOTAL 5) 6. MIDDLE PARTITION 7. BOTTOM SMALL SHELF (TOTAL 1) 8. BOTTOM GRILLE 9. LEVELING LEGS 10.
-
Page 9: Table Of Contents
Cleaning Your Wine Chiller _____________________________________________________ 15 Power Failure Vacation Time_________________________________________________________________ 15 Moving Your Wine Chiller Energy Saving Tips____________________________________________________________ 16 Troubleshooting Guide ________________________________________________________ 16 Service For Your Wine Chiller___________________________________________________ 17 Your Avanti Products Warranty _________________________________________________ 18 Wiring Diagram _______________________________________________________________ 19 INSTRUCCIONES EN ESPAÑOL______________________________________________20~23... -
Page 10: Important Safety Instructions
(ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized Avanti Products service center. To reduce the risk of fire, electrical shock,... -
Page 11: Electrical Connection
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products service center. This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock. -
Page 12: On/Off Power
Recommended Temperatures for Chilling Wine Red Wines 58-65 F Dry/White Wines 48-57 F Rose Wines 49-51 F Sparkling Wines 40-47 F DISPLAY SCALE UPPER ZONE The LED readout will show the original temperature set previously (the preset temperature at the factory for UPPER ZONE is 60ºF and for LOWER ZONE is 50ºF). -
Page 13: Storage
the one indicated on the LED readout. This is normal and it is due to the length of the activation time. Once the wine chiller is running for a few hours everything will be back to normal. ? STORAGE Many bottles may differ in size and dimensions. As such the actual number of bottles you may be able to store may vary. - Page 14 To remove the shelves out of the rail pull each shelf approximately 1/3 out. Use a long flat screwdriver to press down the right plastic notch as shown in Figure A and at the same time lift the left plastic notch as shown in Figure B. Then proceed to pull out the shelf slowly. Contact our service department if assistance is needed.
-
Page 15: Care And Maintenance
Normal Wooden Shelves To prevent damaging the door gasket, make sure to have the door all the way opened when pulling the bottom shelf out of the rail compartment. For easy access to the storage content, you must pull the shelf approximately 1/3 out of the rail compartment, however this unit was designed with a plastic post on each sides of the shelf track to prevent bottles from falling. -
Page 16: Energy Saving Tips
? ENERGY SAVING TIPS The Wine Chiller should be located in the coolest area of the room, away from heat producing appliances, and out of the direct sunlight. PROBLEMS WITH YOUR WINE CHILLER? You can solve many common Wine Chiller problems easily, saving you the cost of a possible service call. -
Page 17: Service For Your Wine Chiller
We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti appliances. With the purchase of your Avanti appliance, you can have the confidence that if you ever need additional information or assistance, the Avanti Products Customer Service team will be here for you. -
Page 18: Your Avanti Products Warranty
WHAT IS COVERED LIMITED ONE-YEAR WARRANTY For one year from the date of purchase by the original owner, Avanti Products will, at its option, repair or replace any part of the unit, which proves to be defective in material or... -
Page 19: Wiring Diagram
WIRING DIAGRAM... -
Page 20: Instrucciones En Español
INSTRUCCIONES DE SEGURIDAD Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable a tierra con una enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado correctamente y conectado a tierra. - Page 21 Temperaturas recomendadas para enfriar vinos: Vinos tintos: Vinos blanco/seco: Vinos rosé/Zinfandel: Vinos blanco/espumante: DISPLAY SCALE UPPER ZONE Para encender el electrodoméstico, oprima el botón marcado “ON/OFF” para ON. En la fábrica se programa la zona superior a los 60ºF (15ºC). La zona inferior se programa a los 50ºF ( 10ºC).
- Page 22 CER RADURA DE LA PUERTA Su unidad viene equipada con una combinación de cerradura y llave. Las llaves (2) están dentro de la bolsa plástica junto al manual de instrucciones. Introduzca la llave en la cerradura y gírela hacia la izquierda para abrir la puerta. Para cerrarla, gire la llave hacia la derecha.
- Page 23 de su vinera. Sin embargo, Ud. deberá reducir la cantidad de veces que abra la puerta cuando la corriente esté apagada. SI UD. SE MUDA Saque o asegure todos los artículos dentro de su vinera. Para evitar que los tornillos nivelantes se averíen, gírelos completamente hacia la base.
