Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Ref: 101212
24
5 Ton Log Splitter
01967
Please read and fully understand the instructions in
this manual before operation. Keep this manual
safe for future reference
1
Advertisement
Related Manuals for SIP 01967
Summary of Contents for SIP 01967
- Page 1 This will allow the recycling of raw materials and help protect the environment. 01967 FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com Please read and fully understand the instructions in www.sip-group.com...
-
Page 2: Declaration Of Conformity
Leicestershire LE12 9NH England As the manufacturer's authorised representative within the EC declare that the 5 Ton log splitter - SIP Pt. No. 01967 Conforms to the requirements of the following directive(s), as indicated. 2006/95/EC Low Voltage Directive 2006/42/EC Machinery Directive... - Page 3 NOTES CONTENTS Page No. Description Safety instructions Electrical connection Guarantee Getting to know your log splitter Technical specifications Operating instructions Maintenance Wiring diagram Troubleshooting Exploded diagram Parts list Notes Declaration of conformity...
- Page 4 Motor WD03-00065 SIP recommends that this log splitter should not be modified or used for any applica- tion other than that for which it was designed. If you are unsure of its relative applica- Switch box WD03-00066 tions do not hesitate to contact us and we will be more than happy to advise you.
- Page 5 O-ring WD03-00046 optional leg stand (SIP code 01971), it must whenever possible bolted to the work Sliding Sleeve Spring WD03-00047 bench, keep your work area clean and free of clutter.
- Page 6 SAFETY INSTRUCTIONS….cont PARTS LIST Safety Symbols Used Throughout This Manual: Description SIP Part No. Cylinder WD03-00001 Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Piston O-ring WD03-00002 Piston WD03-00003 O-ring WD03-00004 Spring WD03-00005 Warning: Risk of electrical injury or damage!
- Page 7 Connecting to the power supply: This SIP log splitter is fitted with a standard 230v ~ 13 amp type plug. Before using the log splitter, inspect the mains lead and plug to ensure that neither are damaged. If any damage is visible have the log splitter inspected / repaired by a suitably quali- fied person.
- Page 8 Loosen bleed screw before tem while operating. operating the log splitter. This SIP log splitter is covered by a 12 month parts and labour warranty covering failure Bleed screw is not tightened Tighten the bleed screw up. due to manufacturers defects. This does not cover failure due to misuse or operating Oil leaks around before moving the log splitter.
- Page 9 MAINTENANCE INSTRUCTIONS….cont GETTING TO KNOW YOUR LOG SPLITTER Sharpening The Wedge: This log splitter is equipped with reinforced splitting wedge with a blade that is specially treated. After long periods of operation, and when required, sharpen the wedge using a fine-toothed file removing any burrs or flat spots on the edge. WIRING DIAGRAM Log pusher Switch box...
- Page 10 MAINTENANCE INSTRUCTIONS GETTING TO KNOW YOUR LOG SPLITTER….cont CAUTION: At least 2 persons are required to carry out this operation. Replacing The Hydraulic Oil: Emptying Emptying. Make sure all moving parts stop and the log splitter is unplugged. Unscrew the oil drain bolt (14) and re- move it.
- Page 11 OPERATING INSTRUCTIONS….cont GETTING TO KNOW YOUR LOG SPLITTER….cont Freeing A Jammed Log: Do not wear loose clothing, neckties or jewellery (rings, wrist watches), they can be caught in moving parts, non-skid footwear are recommended when working, wear protective hair covering to contain long hair, prevent- ing it from get caught in machinery.
- Page 12 2 logs at the same time, one could fly up and injure you. tach to an optional leg stand (SIP code 01971), if this isn't fitted to a leg stand then it must be placed on a work bench, never run the machine on the ground.
