Chino TP-U0260ES Quick Manual

Body-surface temperature checker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INST.No.TPL-02-34A
This unit is a sensor to measure a surface temperature and is not a clinical
thermometer. This unit cannot be used for medical treatment or medical
examination.
ＴＰ-Ｕ０２６０ＥＳ
Unit type
体 Body-surface
temperature checker
Q
u
Q
u
INSTRUCTIONS
Store this instruction manual in
a designated place for future
reference.
i
c
k
m
a
n
u
i
c
k
m
a
n
u
a
l
a
l
CHINO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-U0260ES and is the answer not in the manual?

Questions and answers

Related Manuals for Chino TP-U0260ES

Summary of Contents for Chino TP-U0260ES

  • Page 1 INSTRUCTIONS Store this instruction manual in a designated place for future reference. This unit is a sensor to measure a surface temperature and is not a clinical thermometer. This unit cannot be used for medical treatment or medical examination. CHINO...

  • Page 2: Safety Precautions

    ■Before using Please confirm the contents of packing. If something is missing, please contact to your nearest distributor. Name Quantity Body surface temperature checker (unit itself) Wall mounting holder (commonly used for wall and tripod mountings) Table stand Urea capped screw LAN cable (straight cable with RJ-45 terminal/2m) Wood screw Lens cap...

  • Page 3: Precautions For Use

    Precautions for use This product is an instrument to measure a surface temperature and is not a clinical thermometer. The measured result is the surface temperature of skin or in the mouth and differs from a value of the commonly-used clinical thermometer. For measuring body temperature correctly, use a clinical thermometer.

  • Page 4: Table Of Contents

    Contents ■Before using ............Ⅰ ■Safety precautions ............Ⅰ ■Precautions for use ............. Ⅱ ■Installation ■Setting on a table ........... １ ■Mounting to a wall .......... １ ■Installing on a tripod .......... ２ ■Power ..............２ ■Operational procedure............ ３ ■Connection of the checker and PC and its setting ......４...

  • Page 5: Installation

    ■Installation Install this unit by using the holder or the stand depended on an installation environment. ■Setting on a table By using the attached table stand, this unit can be put on a reception desk or a table. Angle adjustment Table stand Urea capped screw Fixing screw...

  • Page 6: Installing On A Tripod

    ■Installing on a tripod Easy installation is available by installing it on a tripod using the attached wall mounting holder. Attach the wall mounting holder to this unit with the urea capped screws. Fix the camera mounting screw of tripod to the screw hole for tripod of the wall mounting holder. When the pin (to stop turning) is provided on the tripod, mount the wall mounting holder by aligning the pin hole to the pin.

  • Page 7: Operational Procedure

    ■Operational procedure  Install this unit in an environmental stabilized place. This unit is easily influenced by the ambient temperature of the place installed and is not a dustproof and splash-proof structure. Install it in an indoor area where the temperature is stabilized and is free from the influence of direct sunlight, wind/rain, etc ...

  • Page 8: Connection Of The Checker And Pc And Its Setting

    3. Confirm the judgment result. When the buzzer sounds “Be-Beep” for the judgment completion, confirm the result by lamps. Measurement Judgment result error Green lighting blinking (Try again.) Green/red lighting The buzzer sounds.  Be-Be-Beep-Be-Be-Beep  Be-Be-Beep-Be-Be-Beep Beeeeep Good Fever suspected Green lamp lighting Good (The measured value is lower than the set value.) [Without beep sound]...
  • Page 9 ■PC settings Set the IP address of your personal computer by the following procedures. (Example: Windows XP&7) Since the settings of connection to the network are changed by performing this settings, it becomes impossible to connect with the conventional network. Take a note of the IP address, etc. and consult with your network administrator.
  • Page 10 5. From the list of [This connection uses the following items:] in the [General tab], select the [Internet Protocol (TCP/IP)] and press the [Properties] button. 【 XP 】 【 7 】 6. Check [Use the following IP address:], set the IP address, the Subnet mask and Default gateway as shown below, and then press the [OK] button.

  • Page 11: Installing The Application Software

    Before this application software is installed, close all other applications that are running. If not, the installation may be affected from them. 2. Insert the CD with the CHINO application software. Setup Wizard should start automatically. If not, double-click the setup program in the CD to start.
  • Page 12 The following screen will appear. 【 7 】 【 XP 】 Specify directory and folder you want to install. The default folder is [C:/program file/CHINO/ Body-surface temperature checker]. In addition, select users who can use this application software. After the selections are completed, click [Next] button.
  • Page 13 4. [Confirmation of installation] The following confirmation screen will appear. Click [Next] button to start the installation. 【 XP 】 【 7 】 Before the installation, close all other applications that are running. If not, the installation may be affected by them. 5.

  • Page 14: Uninstallation Of Application Software

     Uninstallation of application software The following is the uninstall procedure of the Body-surface temperature checker application software from a PC. (The procedure is for Windows XP & 7.) 1. Select [Control Panel] from [Start] button. 【 XP 】 【 7 】 2.

  • Page 15: Confirmation Of Thermal Image

    ■Confirmation of thermal image 1. Starting the application (Example: Windows XP&7) Start the application by clicking the [Body-surface temperature checker] icon on your desktop or in the Start menu > All Programs. When you first start the application, you may get a warning of the security. Please set your communications allow this application or please disable the firewall.

  • Page 16: Screen Configuration And Explanation

    Screen configuration and explanation Origin (0,0) Names Explanations Main Menu Bar Various functions can be selected. Refer to the next page. Alarm Area Display alarm area in the thermal image. The place of the highest temperature in the Alarm area is indicated with a  mark and its and Highest Temperature temperature is displayed on the upper left of the thermal image.
  • Page 17  Menu bar and its functions 1. Image/Data File (F) Save the body surface temperature data to a PC. Save the filtered data of the judgment to the “GOOD” folder and “ FAILURE ” folder in the designated folder. →Refer to Save data [Image/data File](P.18) ■...

  • Page 18: How To Change The Setting

    ■How to change the settings ■Select how to set alarm Alarm setting can be selected from the Auto correct or Manual correct. → Refer to  Changing alarm temperature [Auto correct]. (P.15) → Refer to  Changing alarm temperature [Manual correct]. (P.16) Perform relative deviation alarm settings from moving Auto correct average of measured values (Reference value)

  • Page 19: Auto Correct

    ■Auto correct ■Changing alarm temperature [Auto correct] This is the setting of a reference temperature for judging, Good or Failure, when the body surface temperature is measured. [Default: Reference 36.5°C, alarm 38.0°C] 1. Select the [Auto correct] in the [Sensor Setup] menu to display the Auto correct screen. Press the [Read setup] button at the [Sensor Selection] to read the current settings of the body surface temperature sensor being connected.

  • Page 20: Manual Correct

    ■Manual correct  Changing alarm temperature [Manual correct] This is the setting of a reference temperature for judging, Good or Failure, when the body surface temperature is measured. [Default: 38°C] 1. Select the [Manual correct] in the [Sensor Setup] menu to display the Manual correct screen. Press the [Read setup] button at the [Sensor Selection] to read the current settings of the body surface temperature sensor being connected.

  • Page 21: Checking And Saving Of Body Surface Temperature By Exclusive Software

    ■Checking and saving of body surface temperature by exclusive software In addition to the Good/Failure judgment function by this unit, by utilizing the function of the application software, a message promoting awareness can be displayed and measured data can be preserved. f a large position change (position in the screen or distance) occurs during the measurement, the measured value will become unstable and the correct measurement cannot be performed.

  • Page 22: Maintenance

    ■Save data [Image/data File] Save the body surface temperature data to a PC. Save the filtered data of the judgment to the “GOOD” folder and “ FAILURE ” folder in the designated folder. ［Default：Save data＝Not available］ 1. Select the save mode. If you check ”Save the measuring data”...

  • Page 23: Specifications

    ■Specifications Model TP-U0260ES Temperature measurement range 20 - 40°C Accuracy rating ±0.5°C at 37°C (Ambient temperature 25℃) Detecting element Two-dimensional thermopile array 2000 pixels Measurement wavelength Center wavelength 10μm Measurement view angle 60° × 60° Radius resolution 21.8mrad Frame time...
