Chino TP-L0260EN Instruction Manual

Compact thermal image sensor

Advertisement

Quick Links

INST.No.TPL-02-5A
TP-L L L L 0260
TP
TP
TP
Compact
Thermal Image Sensor
Instruction Manual
INSTRUCTIONS
Please
manual in a designated place for
future reference.
0260EN
0260
0260
EN
EN
EN
store
this
instruction
CHINO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP-L0260EN and is the answer not in the manual?

Questions and answers

Summary of Contents for Chino TP-L0260EN

  • Page 1 INST.No.TPL-02-5A TP TP-L L L L 0260 TP TP 0260 0260 0260EN EN EN EN Compact Thermal Image Sensor Instruction Manual INSTRUCTIONS Please store this instruction manual in a designated place for future reference. CHINO...
  • Page 3 Introduction Thank you for purchasing a compact thermal image sensor. In order to use this product safely, please read this instruction manual completely before use and confirm the correct handling and instructions. In addition, please retain this instruction manual for future reference.
  • Page 4 About this instruction manual Under absolutely no circumstances may the contents of this instruction manual, in part or in whole, be transcribed or copied without permission. The contents in this instruction manual are subject to change without notice in future. The figures in this instruction manual may be emphasized, simplified or omitted.
  • Page 5 Safety precautions The safety precautions shown in this manual indicate the important contents about safety. Please be sure to understand and follow these precautions. In this manual, in order to use this product safely, the precautions are described with the following indications and marks.
  • Page 6: Precautions For Use

    Precautions for use This product is a precision instrument. Do not drop it or make a strong impact on it. Do not use it in water. Keep this product away from equipments generating strong static electricity and electromagnetic waves including TVs, microwave ovens and wireless applications, or it may cause malfunction or trouble on this product.
  • Page 7: Table Of Contents

    【準備・設定編】 Contents ■ Introduction ............I ■ Safety precautions ..........III ■ Precautions for use ..........IV ■ Outline of product 1. Configuration........... 1 2. Features ..........1 3. Functions ..........1 4. Model/specification........1 5. Basic configuration ……………………… 2 ■...
  • Page 8: Outline Of Product

    Outline of product 1. Configuration The system consists of the thermal image sensor utilizing a thermopile array detector and the application software for displaying thermal images converted from the temperature data from the sensor.. The application software allows to connect up to 4 thermal image sensors and display thermal image from these sensors.
  • Page 9: Basic Configuration

    5. Basic configuration 5-1. Connection with 1 Thermal Image Sensor to PC (Monitor mode) Monitor mode (when the supplied application software is used) The temperature data of entire thermopile array can be obtained from the PC. Supplied custom Network cable (Crossing cable) Thermal image sensor Alarm setup...
  • Page 10 (DC12V 1.5A) 5-4. Connection to PLC (Capture mode) Capture mode ( when the supplied CHINO application software is not used) The temperature data in a single row of the thermopile array can be obtained at a time by a command from a master unit (e.g. PC or PLC).
  • Page 11: Names And Functions

    Names and functions (1) Monitor lamp (2) Lens Power/alarm output LAN connector connector (3) Mounting screw (6) Reset switch (Behind the screw) Name Function The state of alarm and the condition of the sensor is indicated Monitor lamp with colors of blue, red and purple. (Refer to Page 8.) For forming image of radiation energy from a measurement Lens object on the detecting element...
  • Page 12: Connection

    Connection ● Connect the custom power/alarm output cable and the custom Network cable to this product. Connect them to align the marks of [ ] back of this product and [Arrow] on the cable connectors. To avoid misconnections, the custom Network cable is designed not to connect to the power/alarm output connector of this product.
  • Page 13 [Details of custom power/alarm output cable] O-tip terminal 0.5-3.5 Power + Black Power - Orange Alarm 1 + AL1 + Pink Alarm 1 - AL1 - Bright green Alarm 2 + AL2 + Blue Alarm 2 - AL2 - [Example of contact output circuit] Use the contact output with a protection device (e.g.
  • Page 14: Installation

    Installation By referring the figure below, install the thermal image sensor at the measuring distance that a measuring object can be imaged at the center of screen as large as possible. Do not install the sensor where subjected to vibration/shock or inductive ambient. 7.0m <Relation between a measuring surface and a measuring distance>...
  • Page 15: Operation

    * Refer to Page 14 Troubleshooting. Operation mode 1. Monitor mode: When CHINO application software is used The temperature data is sent continuously to a master unit (e.g. PC) by a command from the software.(The frame rate of the thermal image on the software is 3fps without any Alarm activated.) The alarm set on the sensor can provide a non-voltage contact output while sending the temperature data.(The frame rate goes down to 1fps or less with the alarm set on the sensor.)
  • Page 16: Alarm Output

    Alarm output 1. Specifications Item Specification Alarm area 1 area Alarm set value 2 values in a specified area Setting resolution 1 degree (°C/ºF) When consecutive 4 frames have satisfied the alarm Alarm activation condition condition When the measured temperature returns from the Alarm reset condition alarm set value in 4 images continuously Output Control...
  • Page 17 ● Alarm output and storing image 警報状態 警報状態 警報状態 警報状態 警報有 警報有 警報有 警報有 警報無 警報無 警報無 警報無 警報有 警報有 警報有 警報有 Alarm state Contact output 警報出力 警報出力 警報出力 警報出力 自動復帰 自動復帰 自動復帰 自動復帰 Auto Reset Image is overwritten. 画像上書 画像上書き...
  • Page 18: About Reset Switch

    ■ About reset switch In case of an error, etc. at the LAN environment settings, the set values can be reset to the default values as shipped from factory by removing the mounting screw and then pushing the reset switch. Turn the power on while pushing the reset switch for 1 second continuously.
  • Page 19: Specifications

    ■ Specifications Items Specifications Detecting element Thermopile array with 48 x 47 pixels Measurement wavelength Center wavelength 10 m Measurement view angle 60° x 60° Temperature measurement -20°C to 300°C range Temperature resolution 0.5°C (at 100°C black body) °C, whichever is greater ±2% of measured value or ±3 Accuracy ratings °C)
  • Page 20 [I/F] ■ Accessory (sold separately) Protective case: Model: TP-ZCC1 (Refer to Extrernal Dimension.) ■ Minimum requirements for the CHINO application software Compatible PC: DOS/V computers with PC/AT compatible * The LAN port is required. * Display resolution: 800 x 600 pixels or more recommended * .NET Framework 2.0 or later has been installed and runs correctly.
  • Page 21: Precautions (For Maintaining Measurement Accuracy)

    Precautions (For maintaining measurement accuracy) Pay attention to the followings for maintaining the measurement accuracy. Vibration and shock Vibration and shock causes not only a damage to the thermal image sensor in a long term but in stability of the measurement. When vibration is present, anti-vibration/shock absorber may be required between the thermal image sensor and a mounting plate or between the mounting bracket and a mounting plate.
  • Page 22: External Dimensions

    ■External dimensions 1. Thermal image sensor 2. Universal head When the thermal image sensor is installed with the universal head, mount the mounting bracket with 3 pieces of screws through the 3 holes on the bracket. If the universal head needs to be mounted on concrete surface, drill holes with 6.5mmø...
  • Page 23: Protective Case

    3. Accessory Protective case: Model TP-ZCC1 Hole for air purge (PT1/8)

This manual is also suitable for:

Tp-l0260un
