- Page 1 DIGITAL VIDEO RECORDER Quick Start Guide...
-
Page 2: Table Of Contents
Digital Video Recorder Quick Start Guide TABLE OF CONTENTS Chapter 1 Description of Panels ..................... 7 Front Panel ........................7 Front Panel 1 ........................7 Front Panel 2 ........................7 Front Panel 3 ........................8 Rear Panel ........................10 Chapter 2 Installation and Connections ..................12 DVR Installation ....................... -
Page 3: Quick Start Guide
Guide Quick Start Guide This Manual is applicable to Vezco’s Digital Video Recorder (DVR). The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. -
Page 4: Regulatory Information
Digital Video Recorder Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 5 Digital Video Recorder Quick Start Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
-
Page 6: Safety Instructions
Digital Video Recorder Quick Start Guide Safety Instructions Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. -
Page 7: Chapter 1 Description Of Panels
Digital Video Recorder Quick Start Guide Chapter 1 Description of Panels 1.1 Front Panel Front Panel 1 Figure 1. 1 Front Panel 1 Table 1. 1 Description of Front Panel 1 Icon Description Turns red when DVR is powered up. Turns red when data is being read from or written to HDD. -
Page 8: Front Panel 3
Digital Video Recorder Quick Start Guide Name Function Description STATUS Flickers red when data is being read from or written to HDD. Flickers yellow when network connection is functioning Tx/Rx properly. Receiver for IR remote IR Receiver Universal Serial Bus (USB) ports for additional devices such Interfaces as USB mouse and USB Hard Disk Drive (HDD). - Page 9 Digital Video Recorder Quick Start Guide Name Function Description Buttons Uses the Up and Down buttons to speed up and slow down the playing of video files in Playback mode. The Left and Right button will select the next and previous record files.
-
Page 10: Rear Panel
Digital Video Recorder Quick Start Guide Name Function Description Starts wiper (if applicable) in PTZ control mode. Shows/hides the control interface in playback mode. Switches between single screen and multi-screen mode. PREV/FOCUS- Adjusts the focus in conjunction with the A/FOCUS+ button in PTZ control mode. - Page 11 Digital Video Recorder Quick Start Guide Item Description Connector for alarm input. Connector for alarm output. Power Supply 100 to 240V AC power supply. Power Switch Switch for turning on/off the device. Ground LINE IN BNC connector for audio input. eSATA Connects external SATA HDD, CD/DVD-RW.
-
Page 12: Chapter 2 Installation And Connections
Digital Video Recorder Quick Start Guide Chapter 2 Installation and Connections 2.1 DVR Installation During the installation of the DVR: 1. Use brackets for rack mounting. 2. Ensure there is ample room for audio and video cables. 3. When installing cables, ensure that the bend radius of the cables are no less than five times than its diameter. - Page 13 Digital Video Recorder Quick Start Guide Figure 2. 2 Connect the Data Cable 3. Connect the power cable to the HDD. Figure 2. 3 Connect the Power Cable 4. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD. Figure 2.
-
Page 14: Rs-485 And Controller Connection
Digital Video Recorder Quick Start Guide 2.3 RS-485 and Controller Connection Typical Connection: Figure 2. 5 Controller Connection A To connect PTZ to the DVR: 1. Disconnect pluggable block from the RS-485 terminal block. 2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part. -
Page 15: Hdd Storage Calculation Chart
Digital Video Recorder Quick Start Guide 2.4 HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K... -
Page 16: Chapter 3 Menu Operation
Digital Video Recorder Quick Start Guide Chapter 3 Menu Operation 3.1 Menu Structure The menu structure varies according to different models. Menu Playback Configuration Maintenance Shutdown Export VCA Search Record Camera Manual Behavior Normal Normal Schedule Camera General System Info Logout Record General... -
Page 17: Activating Your Device
Digital Video Recorder Quick Start Guide After the device starts up, the wizard will guide you through the initial settings, including modifying password, date and time settings, network settings, HDD initializing, and recording. To shut down the DVR: 1. Enter the Shutdown menu. Menu >... -
Page 18: Login And Logout
Digital Video Recorder Quick Start Guide 2. Click OK to save the password and activate the device. For the old version device, if you update it to the new version, a warning box will pop up once the device starts up to remind you to use a strong admin password to ensure your information security. You can click YES and follow the wizard to set a strong password. -
Page 19: User Logout
Digital Video Recorder Quick Start Guide User Logout Purpose: After logging out, the monitor turns to the live view mode and if you want to perform any operations, you need to enter user name and password log in again. Steps: Enter the Shutdown menu. -
Page 20: Using The Setup Wizard
Digital Video Recorder Quick Start Guide You can also click Menu > Camera > Signal Input Status to configure the signal input. Steps: Enter the Signal Input Status interface. Menu > Camera > Signal Input Status Check the checkbox to select different signal input types: TVI, AHD/CVBS or IP Configure Signal Input Type Figure 3. -
Page 21: Network Settings
Digital Video Recorder Quick Start Guide the guide of the Setup Wizard to configure the system resolution, system date/time, network settings, HDD management, record settings, etc. Figure 3. 9 Wizard 3.7 Network Settings Purpose: Network settings must be properly configured before you operate DVR over network. Steps: 1. -
Page 22: Adding Ip Cameras
Digital Video Recorder Quick Start Guide 3.8 Adding IP Cameras Purpose: Before you can get live video or record the video files, you should add the network cameras to the connection list of the device. Before you start: Ensure the network connection is valid and correct, and the IP camera to add has already been activated. -
Page 23: Live View
Digital Video Recorder Quick Start Guide Figure 3. 12 Add IP Camera Select the detected IP camera and click the Add button to add it directly, and you can click the Search button to refresh the online IP camera manually. ... -
Page 24: Playback
Digital Video Recorder Quick Start Guide After rebooting all the manual records enabled are canceled. Steps: 1. On the live view window, right-click the window and click the icon (Continuous Record) or icon (Motion Detection Record) on your demand. Figure 3. 13 Right-Click Menu 2. -
Page 25: Chapter 4 Accessing By Web Browser
Digital Video Recorder Quick Start Guide Chapter 4 Accessing by Web Browser You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. - Page 26 Digital Video Recorder Quick Start Guide Figure 4. 2 Login Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in. After login, you can perform the operation and configuration of the device, including the live view, playback, log search, configuration, etc.
