TOYOTA PROACE PRODUCT GUIDE
Release of 19 April 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proace 2016 and is the answer not in the manual?

Questions and answers

Andy
February 13, 2025

Hi ive previously been made a named driver on a toyota proave ambulance and needed to know what the red handle on the front passenger side floor is

0

Related Manuals for Toyota Proace 2016

Summary of Contents for Toyota Proace 2016

  • Page 1 TOYOTA PROACE PRODUCT GUIDE Release of 19 April 2016...
  • Page 2 Style...
  • Page 3 Style differentiation on Proace and Proace Verso Halogen Headlamps + DRL Xenon Headlamps + DRL in LED Front detail Proace Verso Front detail Proace Chrome insert in coloured bumper Black Bumper, side protections, door handles Coloured bumper, side protections, door handles and rear view mirrors and rear view mirrors (Look Pack)
  • Page 4 Style: differentiation on the wheels 4 wheel cover and rim families: Black hub cap on grey steel wheel in 16’’ and 17’’, on Van and Combi grade. Full wheel cover on black steel wheel in 16’’ on shuttles (optional on Van comfort grade). Full wheel cover on black steel wheel in 17’’...
  • Page 5 Style: interior style Differences are more marked between Proace and Proace Verso grades: Proace Differentiation between Proace and Proace Verso Common across all versions with detail variants The dashboard on Proace vans and combi has a more functional design, with maximum directly accessible Common to Proace open storage, whereas the dashboard on Proace Verso cultivates a more opulent design, with decorative strips...
  • Page 6 Style: Proace vs. Proace Verso differentiation Proace Common black upper part of dashboard Black plastic surround on side vents Open storage Light grey colour scheme compartment Door panel with dark grey plastic insert Open lower glove box Proace Verso Common black upper part of dashboard Chromium-plated surround on side vents...
  • Page 7 Closed Urethane steering wheel with storage Closed upper or without infotainment compartme glovebox controls nt with Toyota Traction Select knob overhead or open storage display compartment Stop/Start Depending on heating or air push- conditioning button Short elephant foot on A/T and MMT version, while long on 5M/T and 6M/T.
  • Page 8 Business Closed upper or without infotainment shuttle glovebox controls, or leather with Decorative controls strip With Toyota Traction Select matching knob and decoration, or the version without Stop/Start Depending on heating push-button or air conditioning Short elephant foot on A/T and MMT version, while long on 5M/T and 6M/T.
  • Page 9 Style: PC level differentiation The following pages set out the main visual exterior and interior differences (presentation and trims) between the PC versions. They do not recap equipment differences, they simply show relatively standard exterior and interior configurations. Certain images include optional equipment for the standard configurations across the range. Different lengths are possible for different grades.
  • Page 10 Style: grade differentiation Optional Proace combi swing doors Long antenna if no radio Tinted rear windows (image non-compliant) Halogen bulbs Black coloureddoor handles, mirror shells and side strips Black-coloured front and rear Black hub caps on 16’’ bumpers (STD) or 17’’ steel wheels or 17”...
  • Page 11 Style: level differentiation Optional Proace Verso Shuttle Grade swing doors Short antenna Dark tinted rear windows Halogen bulbs (STD) or Xenon +LED DRL (OPT) Chrome insert in coloured bumper Look pack Full wheel covers on 16’’ (STD) or 17’’ full wheel cover or alloy (OPT) PC-style dashboard Open central storage compartment...
  • Page 12 Style: level differentiation Proace Verso Family Grade Opening rear Window Short antenna Dark tinted rear windows Halogen bulbs Chrome insert in coloured bumper Look pack Full wheel covers on 17’’ steel wheels (STD) or 17” alloy (OPT) PC-style dashboard Sunshade curtains Airline- style trays...
  • Page 13 Style: level differentiation Proace Verso VIP Grade Short antenna Extra-tinted rear windows Xenon headlamps + LED DRL Ext. opening Chrome insert in controls with coloured chromium-plated bumper strip (Stop/Start) Look pack 17’’ alloy wheel rims PC-style dashboard Multi function roof Closed central storage compartment Sunshade curtains...
  • Page 14 Style: level differentiation Optionally: Proace VAN base/ Comfort Glazed tailgate or glazed doors Halogen headlamps (STD), Xenon + LED DRL (OPT) Black coloured door handles, mirror shells and side strips Black-coloured front and rear bumpers Black hub caps on 16’’ (STD) or 17’’...
  • Page 15 Style: Look pack on Proace VAN Proace VAN with Look pack have adopted the Proace Verso look, with in particular the same front bumper: Body-coloured bumpers, door handles, mirror shells and side protection strips Chrome insert in coloured front bumper fog headlights The Look pack is available on vans and crew cabs (comfort grade only).
  • Page 16 Architecture...
  • Page 17 Architecture: Best in Class in consumption and CO2 emissions The combination of the new platform and 1.6 D/2.0 D engines enables Proace/Proace Verso to boast the lowest consumption and CO2 emissions in the segment. This performance has been made possible thanks, among other things, to a reduced weight, refined aerodynamics and SCR technology (Adblue).
  • Page 18 Architecture: 5 stars in the EuroNCAP test...
  • Page 19 Architecture: 3 body styles 3 lengths with 2 wheelbases and 2 rear overhangs Rear Wheelbase overhang 4.6 m COMPACT 2925mm short short 4.9 m MEDIUM 3275mm long short 5.3 m 3275mm LONG long long...
  • Page 20 Architecture: height limited to 1.90 m A strong point of Proace: its height is limited to 1.90 m, to enable it to access everywhere that most of its competitors in the segment cannot access: underground car parks shopping centre car parks tourist areas...
  • Page 21 Architecture: a max. payload of up to 1400 kg / 3.1 t GVW The standard for this van segment is currently to offer a payload of up to 1400 kg. This is the maximum payload reached by the versions with a GVW (or GVM) of 3.1 t. Not all powertrains can achieve a value of 3.1 t, so the increased payload does not always reach 1400 kg: it is between 1200 and 1400 kg, depending on the engine-gearbox assembly.
  • Page 22 Architecture: van GVWs On vans: - The Long versions are only available with increased GVW. - The 1.6 D 115 engine comes only with standard payload. For this power level, increased GVW would require a switch to the 2.0 D 120. standard increased Compact Medium...
  • Page 23 Architecture: van payloads On vans: Payload - The Long versions are only available with increased payload. 1XXX - The 1.6 D 115 engine comes only with standard payload. For this power level, increased 1000 payload would require a switch to the 2.0 D 120. standard increased Compact Medium...
  • Page 24 Architecture: PC GVWs On PCs: - The Compact versions are only available with standard GVW. - Unlike the van range, on 1.6 D 115 PCs increased GVW is available. standard increased Compact Medium Long 1.6 D 95 5MT / 6MMT S&S 2.8 t 2.6 t 2.6 t...
  • Page 25 Architecture: van towable weights (MTW) Regardless of the car length, the max. towable weight is 2.5 t. It is the GTW (Gross Train Weight), by means of the GVM (=GVW), varying with the engine-gearbox assembly, which determines the maximum towable weight. Long Compact Medium...
  • Page 26 Architecture: van loading volumes Loading Loading volume volume w/o Smart Cargo with Smart cargo CG Proace CG Proace Standard height versions NG Proace NG Proace Compact / Medium / Long Compact / Medium / Long Smart Cargo additional loading volume: Proace: +0.5 m Loading volume m without Smart Cargo...
  • Page 27 Architecture: van external dimensions Updated 01/04/2016 Van dimensions Compact Medium Long External dimensions Overall length (van) 4609 4959 4805 5309 5135 Overall width (excl. door mirror) 1920 1920 1895 1920 1895 Width with door mirrors folded in 2010 2010 2010 Width with door mirrors deployed 2204 2204...
  • Page 28 Architecture: van useful dimensions Updated 01/10/2015 Van dimensions Compact Medium Long Load area dimensions Max. floor load length (without modularity) 2162 2512 2254 2862 2584 Max. floor load length (with modularity) 3324 3674 4026 Mid-height load length 1835 2185 2535 Load width between wheel arches 1258 1258...
  • Page 29 Architecture: dimensions of people carrier versions PC specifics Compact Medium Long External dimensions Overall length (van) 4606 4956 5306 Overall width (excl. door mirror) 2925 3275 3275 Width with door mirrors folded in Width with door mirrors deployed 1153 PC overall height with standard payload (kerb height) 1905 1890 1890...
  • Page 30 Architecture: external dimensions for sticker info Dimensions in mm Compact Front 1420 190 530 1010 1050 1600 1160 1040 Medium Tailgate 1180 1290 1310 1410 1090 1160 1050 1470 1210 Long Doors Unavail. 1180 Unavail. 1090 Unavail. Unavail. 1160 Unavail. Unavail.
  • Page 31 Architecture: doors and access Rear doors - Vans are equipped as standard with 50/50 panel swing doors, and people carriers with a glazed tailgate screen with heating and wiper. - On Family grade, the rear screen can open. This makes for easy and optimised trunk loading; or avoids having to open the tailgate (which measures more than 1.30 m) if there is little reversing space.
  • Page 32 Architecture: 250° rear swing doors Standard 180° doors The 250° doors prevent tripping on the pavement or road when parking beside a pavement. They also facilitate moving around the vehicle.  Rear doors less of a hindrance when loading and unloading. They are available only on the Long version.
  • Page 33 Architecture: opening rear screen The opening rear screen is fitted on Proace Verso Family Grade, in all 3 lengths. It is available as an option on the Shuttle versions.  If there is little reversing space behind the car, the trunk is still accessible.
  • Page 34 Architecture: doors and access Sliding side doors - All versions, vans and people carriers alike, are equipped as standard with a Compact right-hand sliding side door in LHD versions, and with 2 sliding side doors for RHD. They are absent only on platform cabs, since their body stops at the B- pillar.
  • Page 35 Architecture: doors and access Smart Entry & Start System + Push-button start (Stop/Start) - Available as an option on vans (Comfort Grade), and people carriers (opt on Combi (?), Shuttle and Family, standard on VIP grade) - Detectors on the front doors, sliding side door(s) and rear doors or tailgate. - Independent of the sliding side door motor system: this function is available on vehicles equipped with manual or motorised sliding side door(s).
  • Page 36 Architecture: doors and access Hands-free sliding doors (Kick-activated side doors opening) 1 sliding door The principle is the same as on sedans, estates or MPVs equipped with the function on the tailgate or trunk, but has been tailored to Proace applications: Proace features motorised sliding side doors.
  • Page 37 Architecture: acoustics of vans and combis Differentiation in acoustic treatment between Base and Comfort grade Comfort Grade vans are differentiated from Base grade by standard or optional equipment, but also by a more sophisticated acoustic treatment, to offer a superior comfort level. Base Grade Combi PC Equipped with better soundproofing than vans, due to Rubber Floor covering and the accompanying insulant layer.
  • Page 38 Architecture: acoustics of people carrier versions Differentiation in acoustic treatment between grades Proace Verso grades are differentiated from entry-level Combis by their interior and exterior presentations, but also by a more sophisticated acoustic treatment, to offer a superior comfort level: - Addition of foam to the body around the passenger compartment and in the doors - Different glazing thicknesses, and addition of a "sheet"...
  • Page 39 Chassis...
  • Page 40 Chassis: suspensions Running gear architecture  reinforced pseudo-McPherson front axle with anti-roll bar  oblique wishbone trailing arms rear axle AMVAC: Load adaptive variable damping All Proace are equipped with variable stiffness springs, with load adaptive variable damping (AMVAC) shock absorbers, a "passive" system which varies the damping with the vehicle's ride height.
  • Page 41 Chassis: suspensions Finish Proace Verso Proace Combi Proace Van CRD2* or CRD2* or CRD2* or driving standard standard rough road standard standard Rough road standard standard standard Rough road conditions pack pack pack Compact standard/ standard/ standard Unavail. increased standard Unavail.
  • Page 42 Chassis: braking Specifications  Ventilated front discs on all versions  Plain rear discs on all versions All types except  Manual parking brake operated by a conventional lever situated between the van – 95/115hp van – 95/115hp driver's and passenger's seats. No electric handbrake option. PC - 95/115hp PC - 95/115hp Boost...
  • Page 43 Chassis: steering Electro-hydraulic power steering Rack ratio (mm/rev.) Steering wheel-wheels ratio (°/rev.) Mechanism Law 102 - L1H1 van and L1 PC Valve law Law 103 - All versions exc. L1H1 van and L1 PC Type GEP K0 LP Capacity cm³ 1.7cc Pump unit Max.
  • Page 44 215/60 R17 C 104H Agilis: for traction on rugged terrain and mud.  This tyre set is particularly suited to “difficult terrain” mode with the Toyota Traction Select option. 225/55 R17 XL 101W: comfort styling, specific to people carrier versions with standard payload Spare wheels The spare wheel is located in a cage under the rear floor.
  • Page 45 Chassis: tyres Uses for vans Base and Comfort grade van 215/65 R16 C 106T tyre Product With Toyota Traction Select, aluminium wheel rims 215/60 R17 C 104H Agilis tyre or diam.17’’ options Uses for PCs Combi Shuttle Family Standard, all powertrains 215/65 R16 C 106T tyre except on 2.0 D 180 A/T...
  • Page 46 Chassis: tyre and wheel rim combinations This table explains the types of tyre and wheel rim fitted on the vehicle, depending on the powertrain, options, finishes and payloads. Tire 215/65 R16 C 106T 16" (DPLGU) Tire 215/60 R17 C 104H Agilis 17"...
  • Page 47 This equipment is designed for optimum performance in every situation, enabling the vehicle to handle the majority of low-grip conditions. - As for the group's other models, Toyota Traction Select on Proace is controlled by a dashboard knob. 1 tyre type, to boost the Toyota Traction Select action - 17’’...
  • Page 48 Chassis: the 5 Toyota Traction Select modes Standard ESP mode This mode is calibrated for a low slip level, based on various grip levels usually encountered on the road. Off-road ESP: Under exceptional conditions (vehicle starting from stuck position, immobilised in snow, on Snow mode loose soil, etc.), it may prove useful...
  • Page 49 On-board comfort...
  • Page 50 On-board comfort: storage compartments in row 1 in the van and combi versions A4 format upper storage compartment on vans Closed upper glove box, which can be lit and refrigerated and shuttle, closed on Family and VIP using the air conditioning. 5.4 l LH cup holder RH cup holder...
  • Page 51 On-board comfort: storage compartments in row 1 in PC version A4 format upper storage compartment on vans and shuttle, Closed upper glove box, which can be lit and refrigerated closed on family and VIP shuttle using the air conditioning. 5.4 l LH cup holder RH cup holder Cubby...
  • Page 52 On-board comfort: sockets Jack socket: 230V Connected to the audio systems, i.e. only absent on vehicles not (for row 2, under row 1 single equipped with a radio. 12V + jack passenger seat) (in lower glovebox) USB socket: Connected to the audio systems, i.e. only absent on vehicles not 12V + USB equipped with a radio.
  • Page 53 Fuel gauge and water temperature on white picto screen Standard on base grade van and combi except with A/T or MMT gearbox, with Toyota Pro-Touch and with F0-based design (text LCD instrument panel) Instrument panel with white text LCD 2 additional needle meters: fuel...
  • Page 54 - Cruise control/speed limiter information - Vehicle distance information and emergency automatic braking alerts, if the vehicle is equipped with the Toyota Safety Sense Pack 2 - Navigation directions, if the vehicle is equipped with Navigation - The speed limit signs detected by the camera, if the vehicle is equipped with...
  • Page 55 On-board comfort: Passenger compartment temperature conditions The various front heating / air conditioning units Heating/ventilation: Entry-level offering Temperature regulated manual air conditioning: The temperature is regulated to the value selected using the rotary button, but the ventilation speed and flow orientation should be set manually. Dual-zone automatic air conditioning (left/right): Automatic temperature regulation (independent left / right), speed and flow regulation.
  • Page 56 On-board comfort: Passenger compartment temperature conditions Warm, hot and very cold destinations - Warm and hot destination countries: the air conditioning circuit has boosted performance, so as to ensure the cooling expected by the customer. - Very cold destination countries: the heating performance is increased by the Webasto heater, available as standard. Automatic air conditioning with additional rear unit The additional unit is housed behind the rear right-hand wheel.
  • Page 57 On-board comfort: panoramic glazed roof A unique offering in the segment  None of the competition offers a glazed roof for the rear passengers. This is a 2-part glazed roof, which boost the brightness and visibility for row 2 and 3 occupants. Its specific features: - Available in all 3 lengths.
  • Page 58 On-board comfort: glazing Glazing tinting Front windows and windscreen: just one tinting level - tinted to 30% opacity, to comply with the European standard. Row 2 & row 3 side windows: 3 tinting levels - Tinted with 30% opacity, standard on vans and combis: classic transparent windows - Dark tinted with 70% opacity, standard on shuttle and family - Extra-tinted with 90% opacity, standard on VIP : from the outside, the windows appear practically opaque, like those of the Mercedes V Class.
  • Page 59 On-board comfort: Glazing tinting optional tailgate sliding windows or swing door windows Tinted (light Dark tinted (30%) Extra-tinted (10%) Dark tinted (25%) transm. 70%) acoustic acoustic acoustic Compact Medium & Long Compact, Medium & Long Dark-tinted sliding Dark-tinted sliding windows option windows option Thickened glazing Extra-tinted...
  • Page 60 Seats and trunk...
  • Page 61 Seats: available info Seat descriptions The following pages set out the fullest possible description of these seats: - General seating philosophy on Proace - The seat variants and their descriptions for row 1 (driver and passenger), and rows 2 and 3 - The available combinations by finish level and bodywork length for PCs and vans - The trunk volumes...
  • Page 62 Seats: general philosophy on Proace Driver's seat There are several types of driver's seats, divided into 3 main families: - Entry-level seat with length and seat back tilt adjustment. - "Ergonomic" seat featuring, in addition to height and lumbar support adjustment, an armrest to separate the driver from the passenger's side.
  • Page 63 Seats: general philosophy on Proace Row 2 and row 3 rear seats On PCs, customer needs and expectations are very different, depending on whether we are talking about standard shuttles, Family or VIP. So Proace offers various seats to meet the various specific requirements of these customers. They are all easily removable, to provide a flat floor space and maximum volume.
  • Page 64 Seats: configurations on van and combi Proace van and platform cab  Available in all 3 lengths and 3 finish levels  The segment standard:  The alternative for maximum  Smart Cargomodularity. Not 3-person cab passenger comfort available on platform cab Proace crew cab van ...
  • Page 65 Seats: configurations on PC Proace Verso shuttle: fixed seats  Available in all 3 lengths  Maximum people carrying  Long-distance comfort for the  No seat manipulation for access capacity front passenger to row 3 Trunk water volumes Compact Standard Long Up to the roof...
  • Page 66 Seats: emblematic configurations on family PC Proace Verso Family grade  Available in all 3 lengths/ 5 seater configuration is only possible on Compact  Modular space adjustment between 8 people and max. trunk volume Trunk water volumes Compact Standard Long Up to the roof 900 l...
  • Page 67 Seats: examples of seat modularity on Family grade  Modular space adjustment between 8-seater 8 people and max. trunk volume 7-seater 6-seater 5-seater 2-seater 4-seater...
  • Page 68 Seats: examples of seat modularity on Family grade  Modular space adjustment between 8-seater 8 people and max. trunk volume...
  • Page 69 Seats: the bare essentials to remember on one page Smart Cargo bench seat in vans Sliding seats in Family Flat floor space freed up by lifting Sliding seats to vary the Easy to remove up the right-hand trunk volume and and refit in the seat base against passenger space...
  • Page 70 Seats: Proace Combi Row 1 Rows 2 & 3 Row 1 & rows 3 lengths Compact Medium – Long 2-3 can be combined freely...
  • Page 71 Seats: shuttle seat base configurations Row 1 Rows 2 - 3 3 lengths Compact Standard – Long Row 1 & rows 2-3 can be combined freely Not available Not available...
  • Page 72 Seats: Family grade seat base configurations Row 1 Rows 2 - 3 3 lengths Compact Standard – Long Trim fabric Not available Leather trim leathe Not available Not available leathe leathe leathe leathe leathe leather leather leather leather...
  • Page 73 Seats: VIP seat base configurations Row 1 Rows 2 - 3 3 lengths Compact Medium – Long leathe leathe leathe leathe Not available leathe leathe leathe leathe leathe leathe leathe Not available leathe leathe leathe NB: optional folding table. It is compatible with the row 3 bench seat, and requires an additional central rail leathe leathe...
  • Page 74 Seats: Base grade van seat base configurations Same options in Compact, medium and Long...
  • Page 75 Seats: Comfort grade van seat base configurations Same options in Compact, medium and Long...
  • Page 76 Seats: row 1 driver's seat families associated with associated with fixed rear seats rail-mounted rear seats leather armrest : height adjuster : lumbar support shelf-folding, emergency exit airline-style trays on back electrically adjusted, heating and massaging Light grey fabric Dark Grey fabric or Light Grey Light Grey or Dark grey...
  • Page 77 Seats: row 1 passenger seat families associated with associated with fixed rear seats rail-mounted rear seats leathe bench seat Type individual individual individual bench seat bench seat individual individual Smart cargo armrest shelf folding storage compartment yes + lift-up under seat base seat base airline-style trays on back...
  • Page 78 Seats: 4 row 2 & 3 seats leathe leathe leathe leathe leather Single-piece or Single-piece or 2/3 LH - 1/3 RH Reversible individual Type 2/3 LH - 1/3 RH 2/3 LH - 1/3 RH 3 customised seat backs armchairs (drop & go) rails rails floor-anchored...
  • Page 79 Seats: removable rear seat weights 50 kg* 19.3 kg 50.5 kg 20 kg 23.3 kg* 24 kg* 33 kg* 33 kg* leathe leathe Seat weights leathe leathe leather 39.6 kg 40 kg 46.6 kg* 48 kg* 33 kg* 33 kg* 01/2016 estimates...
  • Page 80 Seats: Combi and shuttle trunk volumes (fixed seats) Compact Medium Long 1300 1900 2500 Single-piece row 3 bench seat  No shelf-folding or 1200 1600 1274 portfolio-folding in row 3 1700 2300 3000 1200 1600 2000 1138 1488 1838 3600 4200 4900 2800...
  • Page 81 Seats: Family trunk volume (rail-mounted seats) Compact Medium Long 1500 1060 1500 1950 2600 1100 1500 1082 2100 2550 3100 1400 2100 1700 1242 1497 1847 2400 3000 3600 2811 3161 3511 1600 2000 2500 1322 *with passenger seat back folded forward to load long items (not available on 2-seater passenger bench) 3600 4200 4900...
  • Page 82 Seats: Combi and shuttle trunk volumes (fixed seats) Compact Medium Long 1237 1600 .2250 approx. approx Single-piece row 3 bench seat  No shelf-folding or 1350 approx. approx. portfolio-folding in row 3 1274 1633 2228 2787 1172 1556 1950 1138 1488 1838 3397...
  • Page 83 Seats: Family Grade trunk volume (rail-mounted seats) Compact Medium Long 1384 1350 1750 2400 approx. approx. approx. .750 .1000 1400 approx approx approx. 1082 1978 2381 2932 1356 2011 1624 1242 1497 1847 2200 .2700 .3300 approx. approx approx 2811 1500 .1800 2300...
  • Page 84 Architecture: leg space and trunk length Row 2-3 fixed seats (cup-mounted) Côtes en mm Rg 2 Volume coffre repére Silhouette -X / +X -X / +X VDA210 2063 R1 individual seat nominal position (Point H) 2413 2763 1138 R2/R3 cup-mounted bench seat 1488 1838 R2/R3 rail-mounted sliding bench seat...
  • Page 85 Architecture: leg space and trunk length Row 2-3 rail-mounted seats -x/+x Côtes en mm Rg 2 Volume coffre repére Silhouette -X / +X -X / +X VDA210 R1 individual seat nominal position (Point H) 1062 -90/+90 1407 -90/+90 Rg2 Coulis 1757 -90/+90 R2/R3 cup-mounted bench seat...
  • Page 86 On-board comfort: vertical load restraint net on PC Compact Medium Long behind row 1 behind row 2 behind row 3 Holes in roof in lines (behind row 1, 2 and 3  6 holes) Plastic hooks and guards in end-of-line workshop Net included in on-board kit with 2 refs: for fixed seats and sliding seats for lower anchor points Complies with standard ISO 27955 (PC), supplied with an ISO 27955 certificate, which is being formalised.
  • Page 87 Safety...
  • Page 88 Safety: EuroNCAP 5-star rating Lane Departure Alert (LDA) ★★★★★ Road Sign Assist Driver Attention Alert (DAA) Standard equipment: Rear camera with  ESP / DSC 180° overview  Driver & passenger front airbags Head-Up  Cruise control / speed limiter display Blind Spot Detection (BSD) Adaptive Cruise Control (ACC)
  • Page 89 Safety: airbags Airbags in row 1 Front airbags: All van and PC are equipped as standard with driver and passenger airbags (housed on the front part of the dashboard, in front of the upper glove box). Only certain design bases, which do not require the passenger airbag as standard, offer it as an option only on base vans and combi PCs.
  • Page 90  Autonomous emergency braking system with Pedestrian Detection, level 2 (AEBS2) Requires a camera at the top of the windscreen, a front radar, entails a matrix instrument panel and the Toyota Pro-Touch Toyota Safety Sense Pack 1  VISIBILITY pack ...
  • Page 91 Driving aids: Toyota Safety Sense pack 1 Technologies: Windscreen top multi-function camera LDW Lane Departure Alert System  Alerts the driver when the car crosses a line without using a direction indicator. The system detects unintentional lane departure, based on ground markings (continuous or dashed line), and alerts the driver by emitting a sound and providing visual feedback on the instrument panel.
  • Page 92 Driving aids: Toyota Safety Sense pack 2 Technologies: Front radar and windscreen top multi-function camera Adaptive Cruise Control  Enables the driver to let the vehicle adapt to the speed of the vehicle ahead. This cruise control system is able to reduce its speed to 20 km/h, acting only on the accelerator. There is no active braking action.
  • Page 93 Driving aids: parking assistance 4 levels of parking assistance Rear radar only - An audible alert indicates the proximity to obstacles measured by the rear bumper sensors. A proximity view is shown on the radio screen (simple radio, Pro-Touch/Pro-Touch with navi). Rear radar and rear camera - For vehicles not equipped with the Pro-Touch/Pro-Touch with navi, i.e.
  • Page 94 Driving aids: 180° Camera Advantages of 180° camera1 over the AVR reversing camera As a reminder, 180° camera is available only in combination with the connected colour radio or connected navigation touch screens.  Better visibility thanks to a bigger screen ...
  • Page 95 Powertrains...
  • Page 96 Powertrain: Euro6 powertrains in vans Proace VAN 1.6 D 95 MT 1.6 D 95 MMT 1.6 D 115 MT 1.6 D 120 MT 1.6 D 150 MT 1.6 D 180 AT GVW (t) 2.6* - 2.8 2.6* - 2.8 2.6* 2.7* - 3.1 2.7* - 3.0 *not on long...
  • Page 97 Powertrain: Euro6 powertrains in PCs Proace PC 1.6 D 95 MT 1.6 D 95 MMT 1.6 D 115 MT 1.6 D 150 MT 1.6 D 180 AT GVW (t) 2.6* - 2.8 2.6* - 2.8 2.6* 2.7* - 3.1 2.7* - 3.0 *not on long Engine DV6FDU...
  • Page 98 EURO6 powertrains: CO2 emissions and cons. of van versions CO2 emissions and cons. in mixed cycle. Data of 12 February 2016. Values on a grey background are those of versions which have not yet been approved. These values can nonetheless be published in catalogues, specifying "subject to approval".
  • Page 99 EURO6 powertrains: CO2 emissions and cons. of PC versions  In France, families with 3 or more children CO2 emissions and cons. in mixed cycle. Data of 12 February 2016. enjoy a tax incentive which greatly reduces or eliminates the CO2 premium (in 2016). Values on a grey background are those of versions which have not yet been Terms to be specified, see brand approved.
  • Page 100 Powertrain: maintenance Maintenance interval In Europe, the maintenance interval is 2 years or 40,000 km on 1.6 and 2.0 D engines from 95 to 150 hp in normal use, and 1 year or 20,000 km for tough use. Only the 2.0 D 180 AT is subject to a 2-year or 30,000 km interval, because of the presence of balancer shafts, which enhance the ride comfort but restrict the oil pan capacity.
  • Page 101 Powertrain: SCR on Proace 22.4 l tank for a range of approx. 15,000 km. factory 10,000 km 25,000 km 40,000 km Initial factory fill: 15 l, for a range of approx. 10,000 km.  1st customer filling at 10,000 km ...
  • Page 102 Powertrains: EURO4 & EURO5 range HDi 90 5MT Euro 5 Euro 5 HDi 150 6MT Euro 5 HDi 150 6AT Euro 5 HDi 90 5MT Euro 5 HDi 150 6MT Euro 5 HDi 150 6AT...
  • Page 103 Powertrain: technology 1.6l and 2.0l D for Euro6 destinations, 95hp / 210 Nm at 150hp / 370Nm Withdrawal of Stop&Start and possibly the SCR system for Euro5 destinations: 1.6 D 95hp 5MT Euro5 based powertrain, i.e. Euro5 Unavail. no SCR or STT different from the EURO6 powertrain 2.0 D 150hp 6MT...
  • Page 104 Van specifics...
  • Page 105 Van specifics: Smart Cargo Smart Cargo refers to the partition + front 3-seat bench assembly. It provides 3 functions: A flat floor space freed up by the side passenger seat being lifted up against the partition The flap in the partition for carrying loads up 4 m long The adjustable writing tray in the armrest, in the spirit of a mobile office All these configurations enable another passenger on-board in addition to the driver.
  • Page 106 Van specifics: Smart Cargo flat floor Proace is the only van to offer additional volume with a flat floor, because it is the only one equipped with a side seat which can be lifted up against the partition. This is a very simple Protective net operation: you pull on the blue tab and the seat automatically lifts up.
  • Page 107 Van specifics: Smart Cargo ‘‘long loads’’ flap Proace has adopted the flap principle in the separation partition, so that loads 1.15 m longer than the useful length can be slid in behind the partition. Flap dimensions: Flap closed 333 mm Central seat deflector 335 mm...
  • Page 108 Van specifics: the Smart Cargo ‘‘long loads’’ flap The flap in the partition enables the user to exceed the useful length of 4 m on the Long version, and exceed the useful length of 3.30 m on the Compact version, just 4.60 m long. Height under dashboard similar to flap height Compact...
  • Page 109 Van specifics: Smart cargo writing tray The Smart Cargo develops the "mobile office", by means of the writing tray.  More comfort for working on-board between 2 jobs, or to have a bite to eat Elastic to hold a pen or notebook, with a non-slip surface to prevent Adjustable writing tray a laptop placed on it from sliding...
  • Page 110 Van specifics: Load restraints behind the passenger space 4 load restraint families: Standard partitions Comfort partition Protective ladder frame Partition behind row 2 for crew cabs Standard partitions New standard ISO 27956 for Europe All vans in Europe are equipped with a separating partition from floor to Standard ceiling, as the Proace is based on a new platform, and is therefore subject to steel...
  • Page 111 Van specifics: Load restraints behind the passenger space Nordic partition wall The comfort partition is available on Proace as an alternative to the standard partitions. It also meets standard ISO 27956. Pluses of this comfort partition: Comfort Standard  thermal insulation ...
  • Page 112 Van specifics: Load restraints behind the passenger space Comfort partition (cont'd) Increased adjustment range for the driver's seat: - Compared to a seat fully withdrawn against the standard partition, the comfort partition enables the seat back to be tilted by an additional 8.5°.
  • Page 113 Van specifics: crew cabs 2 crew cab families x 2 lengths  For professionals who need to carry 3 people more than with a van (5 or 6 people on board), Medium while still driving a van-approved vehicle with more space for merchandise. They are both based on the van body styles in medium and Long lengths.
  • Page 114 Van specifics: crew cabs Overview Fixed-partition crew cabs Available in 3 presentation levels: Eco fixed crew cabs: Based on a level 1 van type environment, with Isorel panels, visible steel panel and coated wood floor covering.  For professionals who need 3 additional seats at the lowest cost. Comfort fixed crew cabs: Storage compartment on Proace on top of the Eco level, they also feature:...
  • Page 115 Van specifics: crew cabs Crew cab interior trims This table recaps the various trims on the crew cab variants. All the crew cab versions are equipped with head and chest level side airbags, since the front seats are the same as on the PC versions, which are all fitted with them.
  • Page 116 Van specifics: crew cab dimensions Crew Cab dimensions Compact Medium Long Load area dimensions Max. floor load length 2017 1370 2365 1700 Mid-height load length 1352 1700 Max. load width 1618 1602 1618 1602 Max. load height 1337 1449 1339 1449 Max.
  • Page 117 Van specifics: hitches as factory option Hooks available as factory option Several hitching options are available for factory fitting: Single-piece van type hitch, removable using tool In this case, the customer chooses the hook that they need PC type hitch, RDSO (removable without a tool) PC+van type hitch, removable using a gooseneck A hitch option always comes with a built-in trailer engine relay unit (see next page)
  • Page 118 Van specifics: units for towing Trailer engine relay unit BSG-RQ - The hitch preconfiguration comes as standard on all Proace. This involves a wiring harness with connector, into which the BSG-RQ unit can be plugged. - The hitching factory option available on vans and combis comprises the BSG-RQ unit installed in the vehicle, the hitching wiring harness and the hitch: - AQ10 for vans ...
  • Page 119 Colours and trims...
  • Page 120 Colours and trims: bodywork colours Arctic White Atonium Silver Falcon Grey Grey Limestone Non-metallic colour Metal colour Metal colour Metal colour Van and colours Martinique Blue Sicily Black Rich Brown Carnelian Orange Non-metallic colour Non-metallic colour Metal colour Metal colour Sevilia Red Specifics on standard colour vans without Look pack: Van only...
  • Page 121 Infotainment...
  • Page 122 7’’ Touchscreen • Mirror Screen: Mirror Link • Bluetooth / USB connectivity Toyota Pro-Touch with Navigation system: In addition to Pro-Touch Radio: 3D Navigation, Voice synthesis • Navi: Wi-Fi / Bluetooth / USB connectivity  Connected traffic jam (TomTom Traffic), parking, fuel stations, ...
  • Page 123 Infotainment: New-generation navigation Map representation Full-HD: Europe's main cities are mapped in "full 3D", i.e. many buildings and textured landmarks are already represented in 3 dimensions. This enables motorists to find their way even more easily in urban environments. Realism: All reliefs are also represented (mountains, hills, etc.) particularly realistically.
  • Page 124 Infotainment: New-generation navigation Voice control To simplify touch-controlled interfaces and make driving the car safer, (hands remain on the wheel and eyes on the road), voice recognition is available to interact with the following fields: Media Phone • Consult missed calls •...
  • Page 125 Infotainment: loudspeakers Vehicles without a radio are preconfigured, including the wiring harness. Base Grade van and Combi PC Vehicles equipped with the simple radio are equipped as standard with: 50 W - 2 loudspeakers in the front door panels - 2 tweeters in the windscreen side pillars. Shuttle and Family PC As standard, these vehicles equipped with the simple radio, the Pro-Touch radio system or the Pro-Touch with navigation are equipped with:...
  • Page 126 Infotainment: antennae 3 types of antennae: - Long strand if the vehicle does not have a radio - Short strand if the vehicle is equipped with a factory audio system (simple radio or Pro-Touch or Pro-Touch with navigation system) - Short strand with shark fin base if the vehicle is equipped with the stand-alone infotainment unit ( BTA ERAGLONASS Zone D0) There is practically no visible difference between the 2 short strands.
  • Page 127 TCO: Total cost of ownership...
  • Page 128 A low cost of ownership (TCO) oriented vehicle Smart design Hands-free access for Maximum height 1.90 m Navigation with sliding doors Cost savings in use Real fuel consumption voice control "Best in class" Product tricks Mobile office concept Maintenance interval 40,000 km Competitive standard 16’’...
  • Page 129 Coachbuilder conversions...
  • Page 130 Conversions: preconfigurations "Key off" function: The key-off function consists in being able to lock the vehicle doors without switching off the engine, so as to keep in operation the electrical consumers providing vehicle comfort and safety functions, as well as ensuring the operation of the devices fitted on the vehicle for professional applications.
  • Page 131 Conversions: conversion and hitching units Trailer engine relay unit BSG-RQ - The hitching preconfiguration comes as standard on all Proace. This involves a wiring harness with connector, into which the BSG-RQ unit can be plugged. - The hitching factory option available on vans and combis comprises the BSG-RQ unit installed in the vehicle, the hitching wiring harness and the hitch: - AQ10 for vans ...
