2D Barcode Scanner
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OCBS-2004 and is the answer not in the manual?

Questions and answers

Related Manuals for Ocom OCBS-2004

Summary of Contents for Ocom OCBS-2004

  • Page 1 2D Barcode Scanner USER’S GUIDE...

  • Page 3: Table Of Contents

    Content Getting to Start Specification ......................01 Distance of Field ....................02 ON, OFF, IDLE, RESTART ................04 Connect Scanner to the Host................05 Removal of Communication Cable ..............06 Reading Hand-held Mode....................07 Specification Hands-Free Mode....................08 Programming Code Query ........................09 Factory Default..................... 10 Reading Mode.......................11 RS232 Programming.....................12 USB Programming....................15...

  • Page 4: Getting To Start Specification

    Getting to Start Specification Performance Image Sensor CMOS Resoluing 752 * 480 Interface RS232 / HID-KBW / UDP / USB COM Port Emulation / HID-POS PDF417, QR Code(Model 1/2), DataMatrix (ECC200, ECC000, 050, 080,100,140), Aztec, Maxicode, etc. Symbologies Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, China post 25,Interleaved 2 of 5, ISBN, Code 93, GS1 Databar, Code 11,etc Precision...

  • Page 5: Distance Of Field

    Getting to Start Distance of Field 36° 63mm Code 39 (5 mil) 120mm 25mm Code 39 (10 mil) 210mm 57mm PDF417 (5 mil) 115mm 37mm PDF417 (10 mil) 215mm 35mm QR Code (10 mil) 145mm 25mm QR Code (15 mil) 210mm 35mm Data Matrix (10 mil)

  • Page 6: On, Off, Idle, Restart

    Getting to Start ON, OFF, IDLE, RESTART Power On Connect Scanner and Host. One click the "Trigger". Scanner powers on and in "Idle" (ready to use) state (factory default). Power Off There are 4 ways to "Power OFF": » Remove Cable Off scanner ; »...

  • Page 7: Connect Scanner To The Host

    Getting to Start Connect Scanner to the Host Connecting with PS/2 Cable 1、 Insert PS/2 cable (RJ 45 male DIN) into Scanner cable slot; 2、 Insert PS/2 cable (PS/2 male DIN) into Host PS/2 female slot; 3、 If necessary, connect PS/2 cable and the power adapter;...

  • Page 8: Removal Of Communication Cable

    Getting to Start Removal of Communication Cable A Pin that fit the Scanner “ dismount hole” is needed. A paper clip could be ideal. Stretch one end of the paper clip to fit the “Dismount Hole”. Follow the steps: 1、 For RS232 and PS/2 connections, unplug the power adaptor.

  • Page 9: Reading

    请更换节标题 Reading Hand-held Mode 1、 Ensure Scanner, cables, and the Host are connected, then turn the unit Power ON 2、 Press & hold Trigger. Illumination LED and Aiming LED cast an Illumination Pattern (red light) and an Aiming Pattern (blue light); 3、...

  • Page 10: Hands-Free Mode

    Reading Hands-Free Mode 1、 Select reading mode “sensor mode” or “continuous mode” when working in hands- free mode. 2、 Adjust the stand height for the optimum reading stance.

  • Page 11: Programming Code

    请更换节标题 Programming Code Code Programming ON Query “Send Product Info”, the engine sends product information to the Host immediately.“Send Sys Info when Power ON”, the engine sends product information through RS232(only) to the Host after Power ON. Code Programming OFF Send Product Info Send Sys Info when Power ON Do not Send Product Info when Power ON...

  • Page 12: Factory Default

    Programming Code Factory Default Code Programming ON Code Programming OFF Load All Factory Default Part of Factory Default Subject Factory Default RS232 and USB Self-adaption ，The default value is as below： RS232（Baud Rate: 9600bit/s,Parity Check:No Check,Data / Stop Interface Bit:8 bits/1 bit); USB(HID-KBW) Beep Scan Mode Hand-held Mode...

  • Page 13: Reading Mode

    Programming Code Reading Mode » Code Programming ON Hand-held Mode: Pull and keep holding the trigger line to read. Complete one reading or release the trigger to terminate reading status. » Auto Mode: The ambient luminance change in front of the engine automatically initiates reading.

  • Page 14: Rs232 Programming

    Programming Code RS232 Programming Code Programming ON Baud Rate Under RS232 connection, the engine and the Host should set communication baud rate to the same to keep normal communication. Baud rate is the bits transmitted per second (8 bits per bytes). The engine and the Host must communicate at the same baud rate.
  • Page 15 Programming Code RS232 Programming Code Programming ON Parity Check Code Programming OFF NO Check (Factory Default) Odd Check Even Check Stop Bits 1 Stop Bit (Factory Default) 2 Stop Bits...
  • Page 16 Programming Code RS232 Programming Code Programming ON Data Bits Transmitted Code Programming OFF 8 Data Bits (Factory Default) 6 Data Bits 7 Data Bits 5 Data Bits...

  • Page 17: Usb Programming

    Programming Code USB Programming Code Programming ON Code Programming OFF Select USB HID-KBW Select USB COM Port Emulation Select USB DataPipe Select USB HID-POS Note： A driver has to be installed before using USB DataPipe and USB COM Port Emulation.

  • Page 18: Usb Hid-Kbw Programming

    Programming Code USB HID-KBW Programming Code Programming ON Keyboard Coutry The keyboard arrangements and country codes vary in different countries. Refer country codes to the table “USB Country Keyboard Types”. Follow the steps mentioned below to program. 1.“Code Programming ON” Code Programming OFF 2.“Select Country Code”...
  • Page 19 Programming Code USB HID-KBW Programming Code Programming ON Keystroke Delay This parameter sets the delay, in milliseconds, between emulated key- strokes. Scan programming code below to increase the delay when the Host require a slower transmission of data. Code Programming OFF Short Delay(Continuous keystroke）...
  • Page 20 Programming Code USB HID-KBW Programming Code Programming ON Convert Case The Imager converts all barcode messages to the selected case. Code Programming OFF No Case Conversion （Factory Default) Convert All to Lower Case Convert All to Upper Case...

  • Page 21: Beeper

    Programming Code Beeper Code Programming ON Decoding Beep Code Programming OFF Beep ON (Factory Default) Beep OFF Volume Loud (Factory Default) Medium Beep Denotation (Beeper Definitions) Beep Denotation low-higher-higher-higher Power ON completed 1 beep successful reading of an ordinary barcode 2 beeps successful reading of an programming barcode 3 short low-2 high...

  • Page 22: Line Feed And Carriage Return

    Programming Code Line Feed and Carriage Return Code Programming ON Need to program stop suffix and enable it supports line feed and carriage return. Program Stop Suffix Read “Program Stop Suffix”. Then program stop suffix byte(s) to end Code Programming OFF the suffix, read “Save ”.
  • Page 23 Programming Code 1D Symbols Code Programming ON All 1D Symbols Code Programming OFF Enable Reading All 1D Disable Reading All 1D Code 128 Disable Code 128 Enable Code 128 (Factory Default) Min Message Length (default: 1) Max Message Length (default: 48)

  • Page 24: D Symbols

    Programming Code 1D Symbols EAN-8 Code Programming ON Code Programming OFF Enable EAN-8 (Factory Default) Disable EAN-8 EAN-13 Enable EAN-13 (Factory Default) Disable EAN-13...
  • Page 25 Programming Code 1D Symbols UPC-E Code Programming ON Code Programming OFF Enable UPC-E (Factory Default) Disable UPC-E UPC-A Enable UPC-A (Factory Default) Disable UPC-A...
  • Page 26 Programming Code 1D Symbols Code Programming ON Interleaved 2 of 5 Code Programming OFF Enable Interleaved 2 of 5 (Factory Default) Disable Interleaved 2 of 5 Min Message Length (default: 4) Max Message Length (default: 80)
  • Page 27 Programming Code 1D Symbols Code Programming ON Code 39 Code Programming OFF Enable Code 39 (Factory Default) Disable Code 39 Min Message Length (default: 1) Max Message Length (default: 48) GS1 Databar Enable GS1 Databar (Factory Default) Disable GS1 Databar...

  • Page 28: D Symbols

    Programming Code 2D Symbols Code Programming ON All 2D Symbols Code Programming OFF Enable Reading All 2D Disable Reading All 2D PDF417 Enable PDF417 (Factory Default) Disable PDF417 Data Matrix Enable Data Matrix (Factory Default) Disable Data Matrix...
  • Page 29 Programming Code 2D Symbols Code Programming ON QR Code Code Programming OFF Enable QR Code (Factory Default) Disable QR Code Aztec Enable Aztec Disable Aztec (Factory Default) Maxicode Enable Maxicode Disable Maxicode (Factory Default)

  • Page 30: Appendi

    Appendix B. Digit Code and Save It is must to read save after reading digit code. Save 2８...

  • Page 31: Troubleshooting

    Appendix C. Troubleshooting Problem Possible Cause Possible Solution With RS232 communication, adapter Insert the adapter not inserted With RS232 communication, Connect communication Scanner does not turn on communication interface port in right way fails. With USB or PS/2 communication, Connect communication communication interface port in right way fails.
