THUNDER LOW FREQUENCY AMPLIFIER 655-0010-01-01 INSTALLATION MANUAL TABLE OF CONTENT PAGE NO General Description Technical Specification Mechanical Installation Electrical Installation Dip Switch Setting Package Contents Warranty and product return policy 212-0100 10 MAR 2017... -
Page 2: General Description
General Description The Thunder works with any standard vehicle’s existing siren, creating a new tone half a quarter or a combination of the original tones. This low frequency tones drives one or two special designed low frequency speaker which mounted in front of the vehicle. - Page 3 General Warning 1. The use of emergency warning devices does not ensure the safety of the operator. The operator is responsible to ensure safe operation of the vehicle regardless of whether the warning device is in operation or not 2. The effectiveness of this or any warning device is highly dependent on proper installation and maintenance.
-
Page 4: Mechanical Installation
Mechanical Installation Speaker Installation 1. Mounting bracket for speaker can be mount in several position de- pending on your vehicle. 2. Decide the mounting location, mark and drill six mounting holes. 3. Secure the bracket to the vehicle with supplied hardware. 4. -
Page 5: Electrical Installation
Electrical installation Wiring diagram FIGURE 2 WIRING DIAGRAM 212-0100 10 MAR 2017... - Page 6 Connection Description Pin 1 Connect to +12V of battery Pin 2 Connect to ground of battery Pin 3 Connect to SPST momentary switch (positive activation) Pin 4 Connect to SPST momentary switch (ground activation) Pin 5 Connect to the vehicle siren speaker Pin 6 Connect to the vehicle siren speaker Pin 7...
-
Page 7: Dip Switch Setting
Dip Switch Setting Configure Tone Duration To select tone duration, set dip switch position 3, 4 and 5 to the position base on the table below: 15 second tone FIGURE 4 Dip switch sw3,4&5 configuration SWITCH 3 SWITCH 4 SWITCH 5 TONE DURATION 7 seconds (default) 10 seconds... - Page 8 Configure Tone Mode FIGURE 5 Dip switch sw6,7&8 configuration To select tone mode, set dip switch position 6, 7 and 8 to the position base on the ta- ble below: SWITCH 6 SWITCH 7 SWITCH 8 TONE MODE 1/4 primary siren tone frequency (default) 1/2 primary siren tone frequency Mix Frequency tones System Operation...
- Page 9 MANUAL AND INSTALLATION PROCEDURE FOR THUNDER LFA SIREN BOX SEE TABLE BELOW VEHICLE SPECIFIC MOUNTING BRACKET 189-0200 THUNDER SPEAKER 1 (OR 2) 655-0010-01-01 THUNDER - LOW FREQUENCY AMPLIFIER SIREN BOX - REV 0 VEHICLE SPECIFIC BRACKET LIST PART NUMBER DESCRIPTION 935-0082A Explorer2013+ Thunder Speak Mount Brkt...
- Page 10 Notes: 212-0100 10 MAR...
- Page 11 Notes: 212-0100 10 MAR...
- Page 12 WARRANTY WARRANTY D & R Electronics warrants its new products to be free from defects in material and workmanship, under normal use and service for a period of one year on parts replacement. This warranty applies only to original purchasers acquiring the product directly from D&R Electronics, or its authorized dealers.
