MiDRONE AIR 55 User Manual

R/c drone

Advertisement

Quick Links

* Picture for example only , please refer to the real unit.
INTRODUCTION
We thank you for purchasing this product. This drone is equipped with an HD camera that lets you take
pictures and video during the flight. It can be controlled either with the remote control up to a distance of
about 80 meters. It can also be controlled via WiFi directly from your smartphone with a range of about
30 meters and transmit real-time images captured by the camera.
To take full advantage of this product and use it safely, please read this manual before use. Please also
keep this manual for future reference.
WARNING
This product is not a toy. It is a high-tech device that requires accurate assembly and proper use to prevent
any accidents. The user of this device must use it responsibly and ensure not cause any damage to third
parties or to objects belonging to third parties.
This product is not suitable for children under 14 years.
Please use this product only in places where it is legally permitted.
Please refer to the legislation on the use of drones in your country.
Midrone can not be held responsible for any damage, loss, injury or death caused directly or indirectly
by the use of this product, part of the product or the information contained in this manual.
Please refer to our website www.midrone.eu for more information.
SAFETY INSTRUCTIONS
The propellers in movement can cause more or less serious injuries, which is why you should never use
the drone near the crowd or flying too close to other people or animals.
Accidents can be caused by improper assembly of the drone or a lack of control, and also by the use of a
drone and / or damaged remote.
Users of this product should be aware of the risks of potential damage and should therefore use it with
great caution.
1. Avoid the crowds and obstacles: the speed and behaviour of the drone can sometimes be unstable,
it is strongly advised to use it in places away from the crowds, tall buildings or trees, high voltage
cables, to prevent injury to the user or other persons or damages to the drone.
2. Do not fly the drone in bad weather (rain, wind, and storm) to prevent damages or lost. Keep away
from wet places to avoid dis-functioning of electronic parts.
3. Do not use the drone if you're tired because the control requires maximum concentration. Be very
careful during learning until your control of the drone is acquired.
4. Keep the drone and the battery away from heat: this product is made of metal and plastic parts,
and electrical parts. Therefore it should not be exposed to high temperatures such as near fire, near
a heating radiator or exposed too long to direct sunlight.
5. Never leave small parts of drone to reach of children to avoid the risk of suffocation.
MiDRONE AIR 55
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIR 55 and is the answer not in the manual?

Questions and answers

Summary of Contents for MiDRONE AIR 55

  • Page 1 Please refer to the legislation on the use of drones in your country. Midrone can not be held responsible for any damage, loss, injury or death caused directly or indirectly by the use of this product, part of the product or the information contained in this manual.
  • Page 2: Description Of The Remote Control

    The drone may be controlled in two ways. Or via the supplied remote control with a range of about 80 meters, or directly through the MiDrone APP on your smartphone in WiFi with a range of about 30 meters. This feature will be detailed later in this manual.
  • Page 3: Battery Installation

    Unlock the drone: Push the left handle Up, then put it back in the middle, And then pull it all the way down. Emergency stop of propellers If the drone is blocked in an obstacle and you want to stop the propellers in an emergency, push the two shifters at the same time downwards and to the left, at an angle of 45°.
  • Page 4: Flying Controls

    NOTE: To better balance the drone and have better flight performance, or if the drone receives shock or fall violently to the ground, it is recommended to make another synchronization procedure like this: Push together the two levers towards the inside within 45 degrees as shown in the image on the right. AUTO TAKE OFF / LANDING / HOVER AT FIXED ALTITUDE After pairing successfully, press AUTO TAKE OFF button on the remote control, the aircraft will rise automatically to the preset height.
  • Page 5: Speed Control

    SIDEWARD FLY (right stick) Push right joystick to the left to fly leftward Push right joystick to the right to fly rightward SPEED CONTROL The drone has 3 speed levels. The first one is for beginners, second and third is for skilled people. At the beginning the drone is set on the first speed level, press the speed control button, hear one beep from R/C, then enter the second speed level.
  • Page 6 WIFI CONNECTION BETWEEN THE DRONE AND SMARTPHONE Download and install the application The app Midrone Air55 is needed to control the drone through the smartphone. It is available free for download on Google Play for Android phones and on the App Store for iPhones.
  • Page 7: Flight Preparation

    FLIGHT PREPARATION First synchronize the drone with the remote control as explained earlier in this manual. Then start the Midrone Air 55 app on the smartphone and press the camera button on the welcome screen of the APP. You can now control the drone with the remote control and enjoy the video transmission on the screen of...
  • Page 8: Troubleshooting

    24 months ** (consisting of an initial period of six months and a second period of 18 months) from the date of original purchase. Midrone sole obligation in the event of such defects during this period is to repair or replace the defective product or part with a comparable product or part at the sole discretion of Midrone.
  • Page 9: Technical Specifications

    3. Return Product The product can be returned to your dealer or directly at Midrone after asking in advance a return number on the site www.MiDrone.eu. If the unit is out of warranty, no refund or exchange will be allowed.
  • Page 10: Ce Declaration Of Conformity

    Brand : MiDRONE Item code: MIDR_AIR55 Product description: R/C Drone MiDRONE AIR 55 Complies with the essential requirements and other relevant provisions of the European Directive RED 2014/53/EU. This product has been tested with the indicated standards and found conform to the following European Directives: ETSI EN300440 V2.1.1 : 2017-03...
