TA UVR 64 Operation And Installation Instructions Manual

Four - circuit universal controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

UVR 64
Version P5.3 EN
Manual Version 2
Four - Circuit Universal Controller
en
Operation
Installation instructions

Advertisement

Table of Contents
loading

Summary of Contents for TA UVR 64

  • Page 1 UVR 64 Version P5.3 EN Manual Version 2 Four - Circuit Universal Controller Operation Installation instructions...
  • Page 3 Informations The hydraulic diagrams of this manual are only diagrams in principle. They do not describe or replace a professional system development. There is no guarantee for function if directly cop- ied. The settings of the menu functions ex works can be restored at any time using the yellow key (“Eingabe”...

  • Page 4: Table Of Contents

    Table of contents Safety requirements ......................... 5 Maintenance ..........................5 Generally applicable rules ......................6 Hydraulic diagrams ........................ 7 Diagram 0: Solar power system with 2 consumers and 2 feed pumps ......... 7 Diagram 16: Solar power system with 3 consumers and feed pump function ...... 9 Diagram 32: Solar power system with 4 consumers ............

  • Page 5: Safety Requirements

    Safety requirements: All installation and wiring work on the controller must only be carried out in a zero-volts state. The opening, connection and commissioning of the device may only be carried out by competent personnel. In so doing, all local security re- quirements must be adhered to.

  • Page 6: Generally Applicable Rules

    Generally applicable rules for the proper use of this unit:  When used for floor and wall heaters: here, a safety thermostat must be used just as with conventional heater controllers. It has to switch off the heating loop pump if there is overheating regardless of the output from the controller to prevent indirect damage from excess temperatures.

  • Page 7: Hydraulic Diagrams

    Diagram 0 Hydraulic diagrams Diagram 0: Solar power system with 2 consumers and 2 feed pumps Sensors Outputs T1…. Collector A1…. Solar pump circuit 1 T2…. Tank 1 top A2…. Feed pump tank 2 T3…. Tank 1 bottom A3…. Feed pump tank 1 T4….
  • Page 8 Diagram 0 Program 1: Instead of the two solar pumps, one pump and a three-way valve are used (pump-valve system). The speed control (if activated) only operated when filling tank 1. Without a priority allocation, tank 2 is filled by priority. A1...

  • Page 9: Diagram 16: Solar Power System With 3 Consumers And Feed Pump Function

    Diagram 16 Diagram 16: Solar power system with 3 consumers and feed pump function. Sensors Outputs T1…. Collector A1…. Solar pump tank TK1 T2…. Tank 1 bottom A2…. Solar pump buffer TK2 T3…. Tank 2 bottom A3…. Solar pump pool TK3 T4….
  • Page 10 Diagram 16 Program 17: Pump-valve system between TK1 und TK2. TK1 and TK2 are fed by a com- mon pump A1 and a three-way valve A2. The speed control (if activated) only operated when filling tank 1. A1... common pump A2...

  • Page 11: Diagram 32: Solar Power System With 4 Consumers

    Diagram 32 Diagram 32: Solar power system with 4 consumers Sensors Outputs T1…. Collector A1…. Solar pump TK1 T2…. Tank 1 (TK1) A2…. Solar pump buffer TK2 T3…. Tank 2 (TK2) A3…. Solar pump buffer TK3 T4…. Tank 3 (TK3) A4….
  • Page 12 Diagram 32 Program 33: Pump-valve system between TK1 und TK2. TK1 and TK2 are fed by a com- mon pump A1 and a three-way valve A2. The speed control (if activated) only operated when filling tank 1. A1... common pump A2...

  • Page 13: Diagram 48: Burner Requirement, 2 Feed Pumps And Simple Solar Power Unit

    Diagram 48 Diagram 48: Burner requirement, 2 feed pumps and simple solar power unit Burner requirement Sensors Outputs T1…. Collector A1…. Solar pump T2…. Tank top A2…. Feed pump solid fuel boiler T3…. Tank center A3…. Feed pump oil/gas boiler T4….
  • Page 14 Diagram 48 Program 49: If the tank has reached its maximum temperature due to the solar power sys- tem, solar pump A1 and feed pump A2 are switched on (reverse cooling function). A2 ... or T4 > max1 & T5 < T4 All Programs +2: Output A4 (burner requirement) switches on when T2 falls below threshold max4 and switches off when T3 exceeds max3.
  • Page 15 Diagram 48 All Programs +8: This program enables controlling of two generators to each one consumer. Output A4 is switched with the difference diff4 between T2 and T3 instead of burner re- quirement. T2 is available for an additional forth generator. In this case threshold max4 oper- ates at T3.
  • Page 16 Diagram 48 Program 61: Function similar to Program 60, but output A3 does not only switch by the origin function, but additionally, if T5 is increasing min1 and is greater than T3 by diff3 Required settings: diff1 …coll. T1 – TK T4 ...
  • Page 17 Diagram 48 Program 63: Output A3 switches as described in program 61 and A4 as per program 62. Required settings: diff1 …col. T1 – TK T4  A1 min1 min2 diff2 …boiler T5 – TK T4  A2 diff4 diff3 …boiler T5 – TK T3 ...

  • Page 18: Diagram 64: Solar Power System With Two Solar Panels And Two Consumers

    Diagram 64 Diagram 64: Solar power system with two solar panels and two consumers Note: Setting the time switch, the definition of the output corresponds to the actual output, but setting the priority it corresponds to the basic function of program 64. Program 64: Each tank is fed from each solar panel by 4 separate pumps.
  • Page 19 Diagram 64 Program 66: 2 stop valves and 2 pumps instead of the 4 pumps in program 64. No feed pump function! Attention! If both valves are closed, both pumps will be switched off. TK 2 TK 1 SP 2 SP 1 Sensors Outputs...
  • Page 20 Diagram 64 Program 68: Function according to diagram. The three-way valve A3 receives power when filling tank TK2. TK 2 TK 1 Sensors Outputs T1…. Collector 1 A1…. Solar pump collector panel 1 T2…. Collector 2 A2…. Solar pump collector panel 2 T3….

  • Page 21: Diagram 80: Layering Storage Tank, Feed Pump And Domestic Hot Water Preparation

    Diagram 80 Diagram 80: Layering storage tank, feed pump and domestic hot water preparation Sensors Outputs T1…. Collector A1…. Solar pumps T2…. Tank top A2…. Heat exchanger pump (hot water) T3…. Tank bottom A3…. Three-way valve layering storage T4…. Hot water (ultra-fast sensor) A4….
  • Page 22 Diagram 80 Program 80: Function according to diagram Both solar pumps are switched on by the difference diff1. The three-way valve A3 switches to the tank top, when T6 is increasing min2 or is greater than T2 by diff3, but T2 has not ex- ceeded the threshold max3.
  • Page 23 Diagram 80 Program 88: A1 gets additionally the threshold min1 at T1. The solid fuel boiler is not appli- cable. The domestic hot water preparation by A2 is also switching, if T4 is greater than T5 by diff2. T5 could be a volume flow switch. A4 is used for burner requirement. A4 switches when T2 has not exceeded max4.

  • Page 24: Diagram 96: Solar Power System With Two Consumers And Two Feed Pump Functions

    Diagram 96 Diagram 96: Solar power system with two consumers and two feed pump functions Sensors Outputs T1…. Collector A1…. Solar pump loop 1 T2…. Tank TK1 top A2…. Feed pump TK2 T3…. Tank TK1 center A3…. Feed pump TK3 T4….
  • Page 25 Diagram 96 Program 97: Instead of the two solar pumps, one pump and a three-way valve are used (pump-valve system). The speed control (if activated) only operated when filling loop 1 (T3). A1... common pump A4... Valve (A4/S receives power when filling tank TK1 bottom) All Programs +2: Instead of the two feed pumps, one pump and a three-way valve are used (pump-valve system).

  • Page 26: Diagram A0: Solar System With Two Consumers, Feed Pump, Burner Requirement

    Diagram A0 Diagram A0: Solar system with two consumers, feed pump, burner requirement Sensors Outputs T1…. Collector A1…. Solar pump loop 1 T2…. Tank TK1 top A2…. Solar pump loop 2 T3…. Tank TK1 bottom A3…. Feed pump TK1 T4…. Tank TK2 bottom A4….
  • Page 27 Diagram A0 All Programs +1: Instead of the two solar pumps, one pump and a three-way valve are used (pump-valve system). The speed control (if activated) only operated when filling TK 1 (T3). A1... common pump A2... Valve (A2/S receives power when filling tank TK2) All Programs +2: Output A4 is used for burner requirement with separated on and off thresholds instead of feed pump function.

  • Page 28: Diagram B0: Solar Power System, 2 Feed Pump Functions, Burner Requirement

    Diagram B0 Diagram B0: Solar power system, 2 feed pump functions, burner requirement Burner requirement Sensors Outputs T1…. Collector A1…. Solar pump T2…. Tank TK2 bottom A2…. Feed pump TK2 T3…. Tank TK1 center A3…. Feed pump TK1 T4…. Tank TK1 bottom A4….
  • Page 29 Diagram B0 All Programs +1: The feeding of the hot water tank is normally done by the difference buffer T5 – hot water tank T2. This program considers also the boiler temperature T6. Burner A4 Required settings: diff1 …coll. T1 – TP1 T4 ...

  • Page 30: Diagram C0 Solar Power System With 3 Consumers, Bypass Function

    Diagram C0 Diagram C0: Solar power system with 3 consumers, bypass function Sensors Outputs T1…. Flow solar loop A1…. Primary solar pump T2…. Tank TK1 A2…. Solar pump TK1 T3…. Tank TK2 A3…. Solar pump TK2 T4…. Tank Tk3 A4…. Solar pump TK3 T5….
  • Page 31 Diagram C0 All Programs +1: Instead of both pumps A2 and A3 one pump A2 and a three-way valve A3 are deployed. (pump-valve system between TK1 and TK2). A2... common pump or bypass valve A3... Valve (A3/S receives power when filling tank TK2 (T3)) All Programs +2: Instead of both pumps A2 and A4 one pump A2 and a three-way valve A4 are deployed.

  • Page 32: Tank

    Diagram D0 Diagram D0: Simple solar power system, 2 feed pumps, feed pump for domestic hot water tank E.g. heat recovery Sensors Outputs T1…. Collector A1…. Solar pump T2…. Heat source A2…. Feed pump TK1 T3…. Boiler A3…. Feed pump TK1 T4….
  • Page 33 Diagram D0 Program D1: Threshold min2 is active at sensor T6 and switches output A4. Program D2: instead of the independent temperature difference between T6 and T5 the dif- ference between T6 and T4 applies. Hence it is possible to heat one consumer from four generators.
  • Page 34 Diagram D0 Program D5: Instead of the independent temperature difference T6 – T5 the controller com- pares the sensors T6 and T3. Required settings: min2 diff1 …coll. T1 – TK1 T4  A1 diff4 diff2 …heat source. T2 – TK1 T4  A2 diff3 …sensor T3 –...

  • Page 35: Installing Instructions

    Installing instructions Installing instructions Installing the sensor(s): The sensors must be arranged and installed properly for the system to function correctly. To this end, make sure that they are completely inserted in the immersion sleeves. The threaded cable connections provided can be used to provide strain relief. The clip-on sensors must be insulated to protect them from being influenced by the ambient temperature.
  • Page 36 Installing instructions Hot water sensor: When the control system is used in hot water systems with an ex- ternal heat exchanger and variable-speed pump, changes in the amount of tempera- ture have to be reacted to quickly. Hence, the hot water sensor has to be put directly on the heat exchanger’s outlet.

  • Page 37: Installing The Unit

    Installing instructions Installing the unit CAUTION! ALWAYS PULL THE MAINS PLUG BEFORE OPENING THE CASE! Unscrew the 4 screws at the edges of the case. The controlling electronic is situated in the cover plate and is connected by a ribbon cable to the mains module, which is set in the basin of the case.

  • Page 38: Data Line (Dl)

    Installing instructions W..root C S..make contact NO Ö..break contact NC Note: The system has to be grounded properly to protect it from damage due to lightening. Sensor failures due to storms and static electricity are usually the result of improper ground- ing.

  • Page 39: Selector Switch

    Selector switch Selector switch The selector switch has 16 different positions. Each position has two functions (e.g. switch position diff2 / T2). The value, which is nearer to the selector switch, will be displayed without pressing of the yellow key “Eingabe” (e.g. T2). By pressing the yellow key “Eingabe” (= in- put) the second value will be displayed (e.g.
  • Page 40 Selector switch diff: The output will be released, when the temperature difference between two set sensors exceeds this value. diff is the basic function (differential control) of this unit for most programs. Recommendation: In solar applications, diff should be set to 7 - 10K. Somewhat lower values suffice for the feed pump program.

  • Page 41: Assignment Of Time Windows (F>A)

    Selector switch Uhr: Setting of the actual time, important for correct function of time windows. The controller has a power reserve of approx. 24 hours, i.e. when blackout longer than 24 hours oc- curs, time must be set again. F>A: Menu for assignment of each time window to one of the 4 outputs. Assignment of time windows (F>A) Position of selector switch: Uhr / F>A Pressing the yellow „Eingabe“...

  • Page 42: Program Selection (Progr.), Assignment Of Priority (Vorr.)

    Selector switch Program selection (Progr.), assignment of priority (Vorr.) Position of selector switch: Prog. / Vorr. Pressing the yellow „Eingabe“ key for 2 seconds causes entry or exit to/from the sub menu normal (short) pressing switches from one position to the next The value can be changed with the blue keys ab/auf (down/up).

  • Page 43: Additional Functions

    Additional functions Additional functions Programming procedure („Menü“) Position of selector switch: Vers. / Menü Pressing the yellow „Eingabe“ key for 2 seconds causes entry or exit to/from the sub menu normal (short) pressing switches from one position to the next The value can be changed with the blue keys ab/auf (down/up).
  • Page 44 Additional functions  Entry to sub menu „ after-running time “ HSt – hystereses: Setting of the hystereses for exact balancing of the system ew = all hystereses at 3K per 64°C  Entry to sub menu „ hystereses “ Pd1 –...

  • Page 45: Sensor Type

    Additional functions Sensor type Solar collectors reach standstill temperatures of 200 to 300°C. No value above 200°C is expected due to the sensor installation point and physical properties (dry steam does not conduct heat well, for instance). The standard Pt1000 series sensors can be permanently exposed to 250°C and briefly to 300°C.

  • Page 46: Function Control

    Additional functions Function control Function control allows detection of sensor interruption or short circuit (error code FF1 – FF6), missing circulation caused by too high temperatures (>40K) between solar panel and consumer after 10 minutes pump-run (error code FF7) and circulation error (error code FF8) of the solar power system.

  • Page 47: Collector Excess Temperature Limit

    Additional functions Collector excess temperature limit Steam builds up when the system is not circulating. When it automatically switches on again, the pump does not have the pressure to lift the fluid level above the highest point in the system (collector feed line). If there is no circulation, the load on the pump is enormous. This function allows the pump to be blocked above a set collector temperature threshold until a second set threshold is fallen short of.

  • Page 48: Start Function (Ideal For Tube Collectors)

    Additional functions Start function (ideal for tube collectors) In the morning, solar power systems sometimes do not “start” quickly enough because the warm heat transfer medium does not reach the collector sensor. Flat collector panels and forced-circulation vacuum tubes generally lack sufficient gravitational force.

  • Page 49: Priority Menu

    After the rinsing time (1, 3), the computer calculates the increase in collector temperature. It detects whether the set waiting time tA has been reached to heat the collector to the priority temperature. In the second case, the unit waits until the priority has been reached to switch.

  • Page 50: After-Running Time

    I.e. a thermostat with hysteresis 10K, which is set to 70°C, switches off at 70°C and switches on again at 60°C. Hystereses in UVR 64 are not constant, but they change accord- ing to the temperature and can be set from 1 to 9 K per 64°C.

  • Page 51: Pump Speed Control

    Additional functions Pump speed control The pump speed control can be used to change the delivered quantity - i.e. the volume flow - of usual commercial circulating pumps in 30 steps. This provides constant levels of (differen- tial) temperatures in the system. Setting of optional sensors and temperatures is possible.

  • Page 52: Differential Control F

    Additional functions Differential control F = keeps the temperature constant between two sensors. Keeping the temperature difference constant between T1 and T2, for instance, allows for “shifting” operation of the collector. If T1 drops due to lower irradiation, the difference be- tween T1 and T2 thus drops.

  • Page 53: Pump Standstill

    Additional functions Pump standstill The wave packet method (standard) allows for variations in the volume flow by a factor of 10 in 30 increments. If the flow rate is too low, flap valves may cause a system standstill. In addition, low power stages at low speeds may cause the rotors to stop. Such a standstill may sometimes be desired, which is why stage 0 is allowed as the lowest stage.

  • Page 54: Pump Speed Processor

    Additional functions Pump speed processor A 2 – absolute value control: Sensor T2 being kept constant by pump speed. The speed increases as temperature T2 does. A-2 means that speed increases as temperature T2 drops (= inverse mode) ew = A 0 (switched off) c60 –...
  • Page 55 Additional functions di0 = no differential part, ew = 5 u6 – Lower speed limit: Limiting the speed for avoiding a rotor stand- still. The controller varies the speed between step 30 and down to “u” (e.g. 6) ew = 1 n18 –...

  • Page 56: Auxiliary Output A5

    Additional functions Auxiliary output A5 The auxiliary output can be linked via “AND” ( ) (German: und) resp. “OR” ( ) conditions with the outputs 1 to 4 or/and the time windows 1 to 3. Inverse mode is possible ( ): Auxiliary output is linked with the switched off output resp.
  • Page 57 Additional functions Example: (using all linking symbols): Aut – Automatic mode. Three possibilities: Aut – Aux. output is switched according to the links. AUS (OFF) – Aux. output is switched off perma- nently. Ein (On) – Aux. output is switched on permanently. ew = AUS A1o –...

  • Page 58: Instructions For Troubleshooting

    Instructions for troubleshooting: In general, all of the settings in the menus and the terminals should be checked if there is an error. Malfunction, but “realistic” temperatures:  Check the program number.  Check the thresholds for on/off (min/max) and the set differential temperatures (diff). Have the thermostat and differential thresholds been (resp.

  • Page 59: Table Of Settings

    Table of settings: If the control system fails unexpectedly, all of the settings should be reset for initial configura- tion. In this case, problems are inevitable if all of the setting values are entered in the follow- ing table. If there are questions, this table has to be provided. Only then is a simulation possible to reproduce the error.
  • Page 60 Function control FCo Sensor T1 Difference temperature Sensor T2 Circulation error Sensor T3 Value L °C Sensor T4 Sensor T5 Sensor T6 Collector excess temperature Utb Start function StF Switch-off temperature 140°C °C Start function active Switch-on temperature 100°C °C Connection radiation sensor Radiation threshold W/m²...

  • Page 61: Technical Data

    Technical data 230V +-10%, 50- 60Hz, Power supply: max. 3 VA Power input: 3.15 a fast acting (device & output) Fuse: 3x 1mm² H05VV-F conforming to EN 60730-1 Supply cable: IP40 Protection class: Allowed ambient 0 to 45°C temperature: Pt1000, accuracy between 0 and 1000°C: +-0.35K Sensors: Tank sensor BFPT1000: Diameter 6 mm, according to immersion sleeves, incl.
  • Page 62 EU Declaration of conformity Document- Nr. / Date: TA17010 / 02/02/2017 Company / Manufacturer: Technische Alternative RT GmbH Address: A- 3872 Amaliendorf, Langestraße 124 This declaration of conformity is issued under the sole responsibility of the manufacturer. Product name: UVR64 Product brand: Technische Alternative RT GmbH Product description:...
  • Page 64 5. The defective parts must be sent to our factory with an enclosed copy of the proof of purchase and a precise description of the defect. Processing is accelerated if an RMA number is applied for via our home page www.ta.co.at. A prior clarification of the defect with our technical sup- port is necessary.
