Summary of Contents for KRain Pro EX 2.0
- Page 1 MODUL R CONTROLLER REMOTE CONTROL Residential/Light ommercial Remote ontrol System OWNER’S M NU L ND INST LL TION INSTRUCTIONS...
-
Page 2: Table Of Contents
SYSTEM COMPONENTS - REMOTE SYSTEM COMPONENTS - RF MODULE LCD DISPLAY INSTALLING THE RF MODULE INSTALLING THE REMOTE BATTERIES POWERING UP/DOWN THE REMOTE CHANGING REMOTE PIN CODE STATION OPERATIONS PROGRAM OPERATION SPECIFICATIONS OPTIONAL EXTENDED RANGE ATENNA TROUBLESHOOTING WARRANTY www krain com... -
Page 3: Introduction
Pro EX 2.0 Remote You can now start and stop manual water from anywhere • Status indicators including Battery and Signal on the job with the new Pro EX 2.0 Remote System.* • Auto power-off (battery saving feature) Season start ups, routine •... -
Page 4: System Components - Remote
LCD DISPLAY Station Station Helpful Number Number transportation Decrease Run Times ACTIVATION BUTTON Used to execute BATTERY DOOR commands Access to four AAA CONTROL BUTTONS Alkaline batteries Used to increase or decrease station run times and number www krain com... -
Page 5: System Components - Rf Module
Listed below are options to consider to Icon Icon Icon Letter Icon assure you experience the maximum range possible. 1.Do not install Pro EX 2.0 near large sources of metal such PROG as power meters, water pipes, and aluminum siding. Battery A B C Strength 2.Do not install Pro EX 2.0 in a basement or underground location. -
Page 6: Installing The Rf Module
NO WIRING INST LL TION OF THE RF MODULE The Pro EX 2.0 Remote Control System was designed to Installation is a simple three step process which only requires work right out of the box. Its “plug and play” installation a screwdriver. -
Page 7: Installing The Remote Batteries
Owner’s Manual and Installation Instructions INST LLING REMOTE B TTERIES Your remote requires four AAA alkaline batteries. To install the batteries, remove the Belt Clip by gently pulling either side freeing it from the remote. Next, slide the battery cover down and lift to expose the battery compartment. -
Page 8: Powering Up/Down The Remote
1.) The default pin code is 1111. Any and all controllers within signal range with matching pin codes will accept remote commands. 2.) After installation we recommend changing your code to avoid interference with other like controllers in the area. See page 8. www krain com... -
Page 9: Changing Remote Pin Code
Owner’s Manual and Installation Instructions PIN CODE DIFFERENT PIN CODE CH NGING THE PIN CODE ON THE REMOTE After powering up the remote if no The Pin Code default setting (out of the box) controllers with matching pins codes is factory set at 1111 but can be changed to are found within the signal range the any combination between 0001 –... - Page 10 MANUAL START/NEXT 1. Turn the controller dial to the Remote/Pin location. buttons simultaneously. One of the the digits will START flash indicating that it is ready to be changed. p i n p i n SELECT www krain com...
- Page 11 Owner’s Manual and Installation Instructions 4. Press either the UP or DOWN button 5. Once the desired pin code has been to change the flashing digit. entered the user can confirm the new p i n 2 pin code by pressing the BACK and MANUAL START/NEXT buttons simultaneously.
-
Page 12: Station Operations
SELECT • Activate any station on the controller with and remaining run time. a programmed run time. • Activate any station on the controller whether the controller dial is in the “AUTO” or “OFF” position. www krain com... -
Page 13: Program Operation
OPEN ND SHORT DETECTION STOP ST TION One of the many features found in the Pro EX 2.0 Controller To stop a station during operation, just touch the ON/OFF is it’s advanced electrical diagnostics. The Pro EX 2.0 looks Select Button . - Page 14 PROG DOWN BUTTON Once the program is switched, the LCD will display for a second the program the user is on. PROG PROG PROG PROGR M PROGR M B PROGR M C www krain com...
-
Page 15: Specifications
Owner’s Manual and Installation Instructions SPECIFIC TIONS OPER TING SPECIFIC TIONS DEF ULT SETTINGS • Pin code range: 0001-9999 • Pin Code: 1111 • Maximum number of stations: 16 • Number of stations: Up to 16 • Run times: 1 second – 99 minutes (all stations with a programmed run time) •... -
Page 16: Optional Extended Range Atenna
STEP #1 STEP #2 STEP #3 Coax (17/64”) Cable Drill Bit STEP #4 Using the 7mm drill bit drill a hole on the top of the housing in the area indicated. STEP #4 before drilling after drilling www krain com... - Page 17 Owner’s Manual and Installation Instructions INST LL TION OF OPTION L LONG R NGE NTENN STEP #5 Remove the plastic caps from the RF Module cavity. STEP #9 Introduce the male end connector (C) of the coax cable into the previously drilled hole on the top of STEP #6 Place the RF Module in the cavity, press down the housing.
-
Page 18: Troubleshooting
No station run time in controller Add station run time in controller Can’t run correct program “ LL” Controller program switch Press up / down arrow buttons Incorrect program selected simultaneously until desired program has been selected. SELECT SELECT www krain com... - Page 19 Owner’s Manual and Installation Instructions NOTES...
-
Page 20: Warranty
Hereby, K-Rain Manufacturing Corporation declares that this Pro EX 2.0 RF Module/Remote is in compliance with the essential other parts of any installation of which this product is part.
