- Page 1 Easy Wireless Controller (EWC) 無線控制器 EWC-100 & EWC-100-62W EWC-100 & EWC-100-62W 系列 Quick Installation Guide 快速安裝指南 Rev. 1.0 Aug. 2017...
-
Page 2: Contents Of Packing
Contents of Packing Open the shipping carton and carefully unpack its contents. The carton should contain the following items. 1. EWC-100 series device x 1 2. DC Power adapter (w/ AC power cord): Power adapter (AC input:100-240v/0.5A, 50/60Hz, DC output: 12V/1A) for EWC-100 Power adapter (AC input: 100-240v/1.2A, 50/60Hz,... -
Page 3: Led Indicators
LED Indicators Front Panel EWC-100 EWC-100 POWER / SYSTEM EWC-100-62W EWC-100-62W The LEDs of the switch are located on the front panel. LED Indicator Color Status Description Solid light Power on Green Power Blinking System boot up Light off Power off... - Page 4 There is no PoE power device (EWC-100-62W) Light off (PD) connection When the total PoE output Amber Solid light power achieve Guard Band PoE Max (EWC-100-62W) System still have power for Light off new PD Please check the detailed specification from http://www.soarnex.com if necessary.
-
Page 5: Rear Panel
12V/1A. EWC-100-62W DC power socket accepts unput power 54/1.67A. On/ Off Power switch (for EWC-100)- Push the controller On/ Off push button to turn your controller “On” (Inner position) or “Off” (Outer position). Reset button- Press and hold this button for 15 seconds and release to reset the controller to factory defaults. -
Page 6: Side Panel
Side Panel The left and right side panel of the EWC device have heat vents to dissipate heat. • Do not block these openings, and leave at least 10cm to make sure that the environment is well ventilated. -
Page 7: Hardware Installation
Hardware Installation 1. Attach the rubber footpads to the recessed area on the bottom of the EWC device. EP100-05-31 EWC-100 POWER POWER / SYSTEM 2. Place the EWC device on a flat desk or shelf. EP100-05-31 EWC-100 POWER POWER / SYSTEM 3. - Page 8 6. Keep enough ventilation space between the EWC device and the surrounding objects. 7. Connect your wireless access points. RADIUS DHCP w/ DHCP Server w/ DHCP Server EWC-100 EWC-100-62W PoE Switch Access Point Access Point...
- Page 9 Configuration How to configure the EWC device via WEB brower is shown as below: • Please make sure the computer MUST be set on the same IP Subnet (same as the IP address of tyhe EWC device) • For example, the default IP address of the EWC device is 192.168.1.100 with subnet mask 255.255.255.0, then the computer should be set 192.168.1x (where x is a number between 1-254, expect 100)with subnet mask...
- Page 10 Configuration 1. Login the EWC device via browser Open your web browser and enter http://192.168.1.100 (the factory-default IP address) to access the WEB platform. Default User Name and Password of the EWC device are “admin”. Note,You can configure the EWC device by entering the User Name/Password and IP Address via WEB platform.
-
Page 11: Declaration Of Conformity
Declaration of conformity FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this user’s guide, may cause harmful... - Page 12 中...
- Page 13 中...
- Page 14 QIG Download Page www.soarnex.com 29072466E1062W0...
