- Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com BVX-100 Fume Extraction System 7100-0070_B...
- Page 2 50mm arms, and ESD safe materials. The BVX-100 consists of a 12” wide (300mm) plenum, with your choice of two, high-quality, filtration methods. For clean room quality filtration, use the 99.997% efficient HEPA filter. In addition, for light duty organic solvent and adhesive applications, a deep bed carbon filter is also available.
-
Page 3: Filter Replacement
ARM OPERATION If you need the flexibility to move the fume collection device to the source of the fumes, the BVX-100 easily converts for use with an arm. An arm and adapter come with the BVX-100 system for easy conversion to arm use. Make sure the system is “Off” and unplugged. Slide the adapter into the plenum till it stops and secure it to the top of the plenum with the lock. - Page 4 No air flow Blower does not No electrical power work Interlock switch No filter installed open Housing not closed correctly Please call METCAL if: your system is still not working properly, or if the LED is green with no air flow.
- Page 5 If the product should become defective within the warranty period, Metcal Inc. will repair or replace it free of charge at its sole option. The replacement item(s) will be shipped, freight prepaid, to the original purchaser.
