Do not block the air ventilation openings. Only mount the equipment per Intelix’s instructions. » Use only with the cart, stand, table, or rack specified by Intelix or sold with the equipment. When/if a cart is used, use caution when moving the cart/equipment combination to avoid injury from tip-over.
INT-HD52 Owners Manual Table of Contents Product Overview ��������������������������������������������������������������������������������������������������������������������������������������� Package Contents ��������������������������������������������������������������������������������������������������������������������������������������� Front and Rear Panels ��������������������������������������������������������������������������������������������������������������������������������� Front Panel ���������������������������������������������������������������������������������������������������������������������������������������������������� Rear Panel ����������������������������������������������������������������������������������������������������������������������������������������������������� IR Remote ��������������������������������������������������������������������������������������������������������������������������������������������������� Installation Instructions ���������������������������������������������������������������������������������������������������������������������������� Quick Start �������������������������������������������������������������������������������������������������������������������������������������������������� Mount the Switching Scaler ������������������������������������������������������������������������������������������������������������������������ Connecting Sources �������������������������������������������������������������������������������������������������������������������������������������...
Page 5
INT-HD52 Owners Manual Web Graphical User Interface (GUI) Control ���������������������������������������������������������������������������������������������� Control Menu ���������������������������������������������������������������������������������������������������������������������������������������������� Source ��������������������������������������������������������������������������������������������������������������������������������������������������������� VGA ............................... DP ................................. VOLUME ............................... POWER FUNCTIONS ..........................Configuration Menu ������������������������������������������������������������������������������������������������������������������������������������ Configuration; Setting ��������������������������������������������������������������������������������������������������������������������������������� Output Resolution ..........................Update ..............................Shutdown Timer (No Input) ........................
The INT-HD52 can be controlled in many different ways. When the VGA input is defined as a PC signal input, the INT-HD52 can be configured to automatically switch to an input once connected to the switcher; once a device is removed, INT-HD52 will switch to the first active input with HDMI inputs taking priority.
INT-HD52 Owners Manual Front and Rear Panels Front Panel Built in IR Receiver Power Indicator - GREEN when device is in standby mode, RED when device is powered on and no indicator when there is no power to device 1-HDMI/MHL input selector and activity LED / Left Key for On screen display control (OSD)
• FIRMWARE - Type-A USB port for updating firmware • RS232 - Serial port, connect a control device to control the INT-HD52 • TCP/IP - Ethernet port, connect a control device or computer to control INT-HD52 AUDIO OUTPUT • Stereo balanced L/R audio output DC 24V •...
Enter / Exit audio switching mode Audio mute Volume - After pressing this button a volume adjustment screen will shown on display connected to INT-HD52, then press UP/DOWN to adjust volume Navigation. OK = enter or confirm Exit: terminates current operation...
Apply power Mount the Switching Scaler At least 2 inches of free air space is required on both sides of the INT-HD52 for proper side ventilation. Avoid mounting the INT-HD52 near a power amplifier or any other source of significant heat.
Set the MIC switch to the proper setting for the microphone input source. 48V phantom power No phantom power LINE No gain needed Connect Audio Output Insert the removable 5-pin phoenix connector block to the audio output. The INT-HD52 supports a stereo balanced left and right output.
An IR signal may be passed to a remote display location through the HDBaseT connection. In order to control the INT-HD52 via IR or extend an IR signal to a remote display, the included IR receiver must be connected to the IR input port (IR IN) of the switcher / scaler.
INT-HD52 Owners Manual On Screen Display (OSD) Menu Navigation The menu system of the INT-HD52 provides a wide array of options to customize the installation of the product regardless of customer needs. Upon entering the menu, navigating left or right will provide three different sub-menus: Options, Picture and Setup.
INT-HD52 Owners Manual Picture Menu Picture Mode Selecting Picture Mode will open another menu which will change the contrast, brightness, color, and sharpness of the input image. The default value is Standard. Values range from 0 to 100. Pressing MENU will exit the sub- menu.
OSD duration. OSD Language Selecting OSD Language will open another menu which will change the menu language of the INT-HD52. The available languages are: English, German, Russian, Chinese, French, Spanish, and Swedish. The default language is English. Pressing MENU will exit the sub-menu.
INT-HD52 Owners Manual Web Graphical User Interface (GUI) Control The INT-HD52 can be controlled by web-based GUI which allows users to interact the INT-HD52 through graphical icons and visual indicators. Connect a computer and the INT-HD52 to a Ethernet switch using the Ethernet ports on your computer and the INT-HD52.
Click the corresponding MUTE button to mute / unmute microphone or source audio input. POWER FUNCTIONS Click SOURCE to turn on/off source device Click DISPLAY to turn on/off display device Click LOCAL to put the INT-HD52 into standby mode...
Output Resolution Select the desired output resolution and click CONFIRM Update Insert a portable USB drive containing the EDID / firmware file into the FIRMWARE port on the INT-HD52 then click EDID or FIRMWARE to update Shutdown Timer (No Input) If the INT-HD52 does not detect a present video signal it will automatically shut down after the preset time interval has passed.
Configuration; Network In this menu you can change the IP address of the INT-HD52. Select DHCP if you desire the IP to be set automatically based on your DHCP network settings or select STATIC IP mode to manually enter in the IP Address, Subnet Mask and Gateway.
INT-HD52 Owners Manual RS232 Control Menu Port Select the receiving control port by choosing LOCAL for the INT-HD52 RS232 port or HDBT for a compatible HDBaseT receiver with RS232 through port. Baud Rate The baud rate of the LOCAL port cannot be changed however the HDBT port can be modified. The compatible baud rates for the HDBaseT port are 2400, 4800, 9600, 19200, 38400, 57600 and 115200.
Web Graphical User Interface (GUI) Update Connect a computer and the INT-HD52 to a Ethernet switch using the Ethernet ports on your computer and the INT-HD52. Type http://192.168.0.178:100 in a web browser on the computer to access the web GUI update portal.
INT-HD52 Owners Manual RS232 Commands RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None There are no spaces between any of the characters in the command string. = Carriage return (Hex 0D) <CR> = Line Feed (Hex 0A) <LF>...
INT-HD52 Owners Manual Video Input Customization Description Command Response Aspect Ratio : 16:9<CR><LF> OR Aspect Ratio : 4:3<CR><LF> OR Aspect Ratio : auto<CR><LF> OR 50608% Cycle aspect ratio Aspect Ratio : panorama<CR><LF> OR Aspect Ratio : justscan<CR><LF> OR Aspect Ratio : zoom2<CR><LF> OR Aspect Ratio : zoom1<CR><LF>...
INT-HD52 Owners Manual System Query (continued) Front Panel Lock<CR><LF> OR 50754% Check front panel lock status Front Panel Unlock<CR><LF> Volume Icon: enable<CR><LF> OR 50651% Check volume bar display status Volume Icon: disable<CR><LF> Embedded Audio Output: enable<CR><LF> OR Check HDMI embedded audio output...
INT-HD52 Owners Manual Troubleshooting Presentation Switcher does not power on » Verify power outlet is active. » Verify the power supply connector is secured to the rear of the switcher. No video from HDBaseT output » Verify the green link LED on the HDBaseT output is lit solid.
INT-HD52 Owners Manual Technical Specifications Input Connections HDMI Inputs Three (3) HDMI type A Display Port Inputs One (1) Display Port VGA Inputs One (1) HD15-F Microphone / Line Input One (1) 3-Pole/3.5mm Euroblock Control (Front Panel) Push Button Control (Rear Panel) RS232 via 3-Pole/3.5mm Euroblock, RS232 via HDBaseT Output (8P8C-F), IR via 3.5...
Page 32
INT-HD52 Owners Manual Control Parameters RS232 Baud 9600 baud HDBaseT Signal Characteristics Maximum Distance 70 m Cable Requirements Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B crimp pattern Bandwidth 10.2 Gbps Gain 0 dB – 10 dB at 100 MHz Signal to Noise Ratio (SNR) >...
Page 33
Thank you for your purchase. For Technical Support please call our toll free number at 800-530-8898 or email us at supportlibav@libav.com www.intelix.com www.libav.com Intelix is a brand of: 11675 Ridgeline Drive Colorado Springs, Colorado 80921 USA Phone: 719-260-0061 Fax: 719-260-0075...
