DK25/R
Specifications for SR25
Frequency response: 50Hz to 25kHz ±2dB at 30cm
Polar Pattern: Cardioid
Sensitivity: 10mV/Pa (Typical)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 145dB SPL
Output: XLR-3
Minimum Load: 600Ω btw. pins 2 & 3
Noise: 20dB, A equivalent
Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
Weight: 160g (.35lb)
Specifications for TC25
Frequency response: 9Hz to 25kHz +1/-3dB
Polar Pattern: Omnidirectional
Sensitivity: 8mV/Pa (Typical)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 150dB SPL
Output: XLR-3
Minimum Load: 600Ω btw. pins 2 & 3
Noise: 26dB, A equivalent
Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
Weight: 160g (.35lb)
Made in U.S.A.
Earthworks, Inc.
37 Wilton Rd.
Milford, NH 03055
603-654-2433, ext. 114
www.earthworksaudio.com
Printed in U.S.A.
DK25/L
SR25 Polar Pattern
TC25 Polar Pattern
User's Guide
DK25/L
Live DrumKit™
DK25/R
Recording
DrumKit™
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Earthworks DK25/L
Summary of Contents for Earthworks DK25/L
- Page 1 DK25/R DK25/L Specifications for SR25 Frequency response: 50Hz to 25kHz ±2dB at 30cm Polar Pattern: Cardioid Sensitivity: 10mV/Pa (Typical) Power Requirements: 24-48V Phantom, 10mA Peak Acoustic Input: 145dB SPL Output: XLR-3 Minimum Load: 600Ω btw. pins 2 & 3 Noise: 20dB, A equivalent Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
- Page 2 Congratulations on your purchase of the Earthworks DrumKit™ System. You will be thrilled with the results you will be able to obtain using Earthworks High Definition Microphones™ for miking drum sets. If you have any questions, you may contact us using the contact information on the back page of this manual.
- Page 3 Earthworks: the New Science in Microphones David Blackmer, the brilliant engineer who invented the technologies of dbx, is also the inventor and founder of Earthworks. In the last few years of his life, David developed a number of revolutionary technologies that dramatically im- prove the quality and performance of microphones.
- Page 4 Important Please Read The Earthworks SR25 supplied for miking kick drum is a precision condenser microphone and is sensitive to large bursts of air. However, this microphone used properly will produce an incredible kick drum sound.
