DK25/R
Specifications for SR25
Frequency response: 50Hz to 25kHz ±2dB at 30cm
Polar Pattern: Cardioid
Sensitivity: 10mV/Pa (Typical)
Power Requirements: 48V Phantom, 10mA
Peak Acoustic Input: 145dB SPL
Output: XLR-3
Minimum Load: 600Ω btw. pins 2 & 3
Noise: 20dB, A equivalent
Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
Weight: 160g (.35lb)
Specifications for TC25
Frequency response: 9Hz to 25kHz +1/-3dB
Polar Pattern: Omnidirectional
Sensitivity: 8mV/Pa (Typical)
Power Requirements: 48V Phantom, 10mA
Peak Acoustic Input: 150dB SPL
Output: XLR-3
Minimum Load: 600Ω btw. pins 2 & 3
Noise: 26dB, A equivalent
Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)
Weight: 160g (.35lb)
Made in U.S.A.
Earthworks, Inc.
37 Wilton Rd.
Milford, NH 03055
603-654-2433, ext. 114
www.earthworksaudio.com
Printed in U.S.A.
DK25/L
SR25 Polar Pattern
TC25 Polar Pattern
User's Manual
DK25/L
Live DrumKit™
DK25/R
Recording
DrumKit™
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Earthworks DRUM KIT
Summary of Contents for Earthworks DRUM KIT
- Page 1 Noise: 26dB, A equivalent Dimensions L x D: 165 x 22 mm (6.5 x .860 in.) TC25 Polar Pattern Weight: 160g (.35lb) Made in U.S.A. Earthworks, Inc. 37 Wilton Rd. Milford, NH 03055 603-654-2433, ext. 114 www.earthworksaudio.com Printed in U.S.A.
- Page 2 Congratulations on your purchase of the Earthworks DrumKit™ System. You Miking the Kick Drum and using the KickPad™ will be thrilled with the results you will be able to obtain using Earthworks High A good kick drum microphone must be designed and optimized for that specific Definition Microphones™...
- Page 3 Earthworks: the New Science in Microphones David Blackmer, the brilliant engineer who invented the technologies of dbx, is also the inventor and founder of Earthworks. In the last few years of his life, David developed a number of revolutionary technologies that dramatically im- prove the quality and performance of microphones.
- Page 4 If you do not have a drum booth or are in also the inventor and founder of Earthworks. In the last few years of his life, David a larger room, you can also use another variation of the X/Y pattern by facing developed a number of revolutionary technologies that dramatically improve the the microphones straight down (see Figure 2).
