MERLIN 4
PROGRAMMING NOTES
1. To load factory default settings: Unplug the energizer from the mains and
disconnect one of the battery terminals. Reconnect the battery terminal and apply
mains to the energizer. Within 38 seconds of reconnecting the battery terminal, the
key sequence
2 3 8 9 # must be entered on the keypad. The energizer will turn off if the default
parameters were accepted.
2. After changing the Fence Alarm Voltage setting, make sure that a short and open
circuit fault can still activate the alarm.
3. The Fence Voltage setting is measured with no load on the energizer. It is possible
that the output voltage is lower or higher than indicated in the table if a fence is
connected to the energizer.

FAULT FINDING

General fault conditions:
Condition
Normal
Power Failure
Battery Low
Battery Flat
Low Voltage
Service
Service fault conditions:
There are 5 possible conditions that can cause a service alarm. To determine the cause of
the service alarm, open the lid of the energizer box while the service light is flashing. Make
sure that Jumper 4 (JP4) is NOT inserted. The following lights will indicate the cause of the
service condition:
Condition
Comms failure
Fence interference
Over temperature
Energizer faulty
Battery flat

COMPLIANCE WITH INTERNATIONAL STANDARDS

The Merlin 4 Energizer has been designed to comply with the latest International safety and
environmental standards. The manufacturer, IO Tech Manufacturing (Pty) Ltd., reserves the
right to make modifications and alter specifications without prior notice.
Compliance testing in accredited overseas laboratories is in the process of being finalized.
Power On Service
On On Off
Off On Off
Off On Pulse (5 sec)
Off Flash
On Flash Off
Flash
LEDS RHS (fence
terminals at bottom)
Closest battery
Bottom energizer

Installer Options

Siren Comment
Off Normal no fault
Off Check if charger is plugged in
Offf Check charger and fuses
On Check charger and fuses
Off Fence in low voltage mode
On Service fault see next table
Comments
Only if keypad detect enabled
Mains pickup, second energizer connected
Check battery/replace battery/unit faulty
Faulty or tampered with
Check fuses/mains/battery
15
