OPERATING INSTRUCTIONS
1. Front Adjustable Armrests (Rotate knob to set arm resting point)
2. Backrest Adjuster (Rotate to adjust to comfortable position – lay flat)
3. ICP- Install tetherbelt system here
4. Side Bolster Adjustment (Press and hold "+" to tighten back cushion side
bolsters, Press and hold "-" to widen back cushion side bolsters)
5. Air-Lumbar Controls (Press and hold "+" to increase lumbar support, Press
and hold "-" to decrease lumbar support)
6. Seat Height adjustment control
a. Press on arrow tip to raise seat.
b. Press on arrow origin to lower seat
7. Isolator Lockout Control (Push left to Lock; Push right to unlock) {NOTE:
Isolator does not work when there is no air in the suspension system}
8. Cushion Extension and Angle Adjustment (Lift up and pull out to adjust in 3
positions, Lift up and push in to shorten cushion)
9.
Seat fore and Aft Adjustment (Pull lever to left to unlock and slide seat to
desired position. Please make sure seat is locked into position after
Customer Service: 800-550-1150, www.knoedler.com, info@knoedler.com
AIR-CHIEF-
"LOW-RIDER"
Fax: 450-445-0086
adjusting.)
