TMC Radio SRM9000X8 Service Manual

800mhz mobile radio transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SRM9000X8 800MHz Mobile
Radio Transceiver
Revision 2 Hardware
SERVICE MANUAL
TNM-M-E-0022
ISSUE 1.0
January 2008
ISO9001 Lic.QEC20848
SAI Global

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRM9000X8 and is the answer not in the manual?

Questions and answers

Related Manuals for TMC Radio SRM9000X8

Summary of Contents for TMC Radio SRM9000X8

  • Page 1 SRM9000X8 800MHz Mobile Radio Transceiver Revision 2 Hardware SERVICE MANUAL TNM-M-E-0022 ISSUE 1.0 January 2008 ISO9001 Lic.QEC20848 SAI Global...

  • Page 3: Table Of Contents

    SRM9000X8 800MHz SERVICE MANUAL TABLE OF CONTENTS APPENDICES ..............................III DECLARATION ............................IV COPYRIGHT ............................... IV ERRORS AND OMISSIONS........................IV DOCUMENT HISTORY..........................V WARNINGS AND CAUTIONS........................VI INTRODUCTION..........................1 ............................1 ENERAL .............................1 COPE ...........................1 ESCRIPTION ....................2 RODUCT ARIANTS ACILITIES 1.4.1 Filename Structure ........................4 1.4.2...
  • Page 4 SRM9000X8 800MHz SERVICE MANUAL 3.1.3 Quadrature Demodulator.....................21 3.1.4 Receiver Audio Processing ....................23 ..........................23 RANSMITTER 3.2.1 Drivers and PA Stages ......................23 3.2.2 Power Control........................24 3.2.3 Antenna Changeover and Harmonic Filter ................24 3.2.4 Transmitter Audio Processing .....................24 ......................26 REQUENCY YNTHESISER 3.3.1 General ..........................26 3.3.2...

  • Page 5: Appendices

    SRM9000X8 800MHz SERVICE MANUAL 4.1.21 CUSTOMERS RADIO PERSONALITY DATA ..............53 REPLACEABLE PARTS ........................54 ........................54 EPLACEABLE ARTS SCHEMATICS...........................55 SRM9000 800MH RADIO BOARD S : ..............55 CHEMATICS APPENDICES APPENDIX A ~ GLOSSARY © TMC Radio 2008 page iii TNM-M-E-0022 Issue 1...

  • Page 6: Declaration

    SRM9000X8 800MHz SERVICE MANUAL Declaration The performance figures quoted are subject to normal manufacturing and service tolerances. The right is reserved to alter the equipment described in this manual in the light of future technical development. Copyright All rights reserved. No part of this publication may be reproduced in any form or by any means without the prior permission of TMC Radio.

  • Page 7: Document History

    SRM9000X8 800MHz SERVICE MANUAL Document History Issue Date Comments January 2008 Initial issue List of Associated Publications Document No. Description Issue TNM-I-E-0005 SRM9000 Series Installation Instructions TNM-P-E-004 Selcall Product Manual 2.56 TNM-U-E-0055 SRM9022 P25 Operating Instructions TNM-U-E-0074 SRM9030 P25 Operating Instructions ©...

  • Page 8: Warnings And Cautions

    SRM9000X8 800MHz SERVICE MANUAL Warnings and Cautions WARNING Compliance with RF Energy Exposure Standards: To minimise exposure to RF fields during equipment service and repair, the antenna terminal of the SRM9000 radio should be connected to a suitable non-radiating RF load when the transmitter is in use.

  • Page 9: Introduction

    SRM9000X8 800MHz SERVICE MANUAL INTRODUCTION ENERAL The SRM9000X8 800MHz mobile transceiver is designed for PMR operation in analog systems or P25 in digital systems. The SRM9000X8 transceiver can be used with either the SRM9022 Graphics Display Handset or the SRM9030 System Level Remote Control Head with Alpha capability.

  • Page 10: Product Variants And Facilities

    SRM9000X8 800MHz SERVICE MANUAL RODUCT ARIANTS ACILITIES Product variants and facilities are detailed in Tables 1-1, 1-2 and 1-3. Table 1-1 Features for Control Variants Feature: Model: 9022 9030 Control Controller Control Unit with Microphone Microphone Display 8x14 char LCD...
  • Page 11 SRM9000X8 800MHz SERVICE MANUAL Table 1-2 Conventional-PMR Variants Feature: Model: 9022 9030 Channels 1000 1000 CTCSS/DCS CTCSS/DCS Signalling Selcall Selcall Attack Operation DTMF Encode PTT Limit Timer with warning beeps Busy Channel Lockout PTT Inhibit on Busy Scanning 124 groups of up to 16 channels per group, 4 user defined scan groups.

  • Page 12: Filename Structure

    SRM9000X8 800MHz SERVICE MANUAL Software Versions and Naming There are various associated items of Software (SW) required for the SRM9000 radio and programmer to operate. This section simply defines the naming rules of the SW files to allow identification and conformity. This allows different versions of SW to be distributed and co-exist without confusion.
  • Page 13 SRM9000X8 800MHz SERVICE MANUAL 9022 PMR with ASI-G Map27option board Transceiver Boot-code Transceiver Boot-Backup-code Transceiver PLA-code Transceiver PLA-Backup-code Note. The above file names are not stored within the code. As a consequence, when the radio is read by the FPP, the FPP will display version numbers and release dates for the Backup, Startup, PMR and DMAP codes.

  • Page 14: Version Number

    SRM9000X8 800MHz SERVICE MANUAL Version Number 1.4.4 This is a 3-digit number allocated by Engineering to identify the SW version. e.g. Version 1.03 Exclusions 1.4.5 The Programmer SW does not follow the above rules as it is a PC based Program and its version number can be easily identified by starting the SW.

  • Page 15: Automatic Version Upgrade Prompting

    SRM9000X8 800MHz SERVICE MANUAL For Software loaded in the radio, information can be read from the Transceiver and displayed via the Programmer function: Options : Radio_Information SRM9030 Control Head SW can be displayed on the Control Head by holding the ‘3’ button down when the radio is switched on.

  • Page 16: Transceiver Sw Description, Start-Up And Backup-Software

    SRM9000X8 800MHz SERVICE MANUAL Transceiver SW Description, Start-up and Backup-Software 1.4.8 The SRM9000 Transceiver software is split into the following separate modules: • Bootloader and Backup Software • Start-Up Software • PLA and PLA-Backup Software • Mainline PMR Software When the Transceiver starts, it basically performs the following steps: •...

  • Page 17: Chassis Assembly

    SRM9000X8 800MHz SERVICE MANUAL HASSIS SSEMBLY Important Note! Torque Settings 1.6.1 Assembly of 'Chassis' (Inner Extrusion) to 'Outer Extrusion': 1.4 Nm (PA x 2), 1.25Nm (Others x 3) Assembly of 'Front' and 'Rear' end-caps to 'Outer Extrusion': 1.4 Nm. Thermal Compound Application 1.6.2...

  • Page 18: Specification

    SRM9000X8 800MHz SERVICE MANUAL PECIFICATION General 1.7.1 Operation Single frequency simplex or two-frequency simplex (half-duplex). Modulation Frequency modulation (phase) F3E and F1E. Operational Temperature Range -30°C to +60°C Storage Temperature Range -40°C to +80°C Supply Voltage Requirements 10.8V to 16.32V DC negative earth (13.8V nom.)

  • Page 19: Transmitter

    SRM9000X8 800MHz SERVICE MANUAL FCC ID: STZSRM9000X8 Regulatory Approvals IC: 7068A-M9000X8 Transmitter 1.7.2 Power Output Any two levels are programmable: High Power: Adjustable down to 1W Low Power: Adjustable up to 25W Less than 50 ms Carrier Attack Time 1 minute transmit: 4 minutes receive...

  • Page 20: Receiver

    SRM9000X8 800MHz SERVICE MANUAL Receiver 1.7.3 Sensitivity Analog < -117.5dBm for 12dB SINAD C4FM < -116dBm for 5% BER Adjacent Channel Rejection Analog 25kHz >70dB C4FM >60dB >20dB Offset Channel Rejection (NPSPAC) Intermodulation Rejection >70dB Spurious Response Rejection >70dB Blocking >90dB...

  • Page 21: Signalling

    SRM9000X8 800MHz SERVICE MANUAL Signalling 1.7.4 1.7.4.1 CTCSS 38 standard CTCSS Tones and 13 non-standard tones are supported as per the table below: Standard Standard Standard Non-Standard Frequencies Frequencies Frequencies Frequencies 67.0 107.2 167.9 69.3 71.9 110.9 173.8 150.0 74.4 114.8...

  • Page 22: 1.7.4.2 Selcall

    SRM9000X8 800MHz SERVICE MANUAL CTCSS Decoder Bandwidth Complies with TIA-603 part 3.4.6 Deviation Sensitivity Less than 6.0% of system deviation (for decode with full RF quieting) Noise Immunity Less than 500ms dropout per minute at 10dB SINAD (CTCSS tone deviation 10% of system deviation. RF deviation 60% at 1000Hz).
  • Page 23 SRM9000X8 800MHz SERVICE MANUAL Selcall Tone Frequency Table Tone ST500 SIGTEC SIGTEC SEPAC ST500 SIGTEC CCIR CCIR CCIR CCIRH CCIR 1981 1981 1981 1981 1981 1981 1981 1981 1124 1124 1124 1124 1124 1124 1124 1124 1197 1197 1197 1197...

  • Page 24: 1.7.4.3 Dtmf

    SRM9000X8 800MHz SERVICE MANUAL Tone SEPAC ST500/CML ST500 SIGTEC SIGTEC SEPAC ST500 ZVEI-3 ZVEI-3 DZVEI DZVEI NATEL 2200 2400 2200 2200 1633 1060 1060 1160 1060 1060 1160 1270 1160 1160 1023 1023 1023 1270 1400 1270 1270 1164 1164...

  • Page 25: 1.7.4.4 Dcs

    SRM9000X8 800MHz SERVICE MANUAL 1.7.4.4 DCS Data rate 134 bits per second, frequency modulated 7.46ms/bit 171.6ms per codeword continuously repeating Deviation 500 to 1000Hz for 25kHz channel spacing 400 to 800Hz (NPSPAC) Codeword size 23 bits comprising: 8 bits - DCS code (3 octal digits 000-777)

  • Page 26: Environmental

    SRM9000X8 800MHz SERVICE MANUAL Environmental 1.7.5 Note: Operation of the equipment is possible beyond the limits stated but is not guaranteed. Operational Temperature -30°C to +60°C MIL-STD-810F Methods 501.4 and 502.4, Proc II Storage Temperature -40°C to +80°C MIL-STD-810F Methods 501.4 and 502.4 Proc I Vibration Stability MIL-STD-810F Method 514.5C-1, Proc I, Cat 4 and USFS Vibration Standard...

  • Page 27: Service Philosophy

    The SRM9000 series has been designed to provide low cost analog and digital speech mobile transceivers, using common core electronics, software and interfacing. It is a requirement that once the customer has purchased equipment, TMC Radio can follow this by providing an ongoing, high level of customer support together with a competitive and professional servicing activity.
  • Page 28 SRM9000X8 800MHz SERVICE MANUAL The customer undertakes not to disclose any part of the software to third parties without the Company's written consent, nor to copy or modify any software. The Company may, at its discretion, carry out minor modifications to software.

  • Page 29: Technical Description

    SRM9000X8 800MHz SERVICE MANUAL TECHNICAL DESCRIPTION ECEIVER Refer to Figure 3-1. Front End Filters and RF Amplifier 3.1.1 The receiver input signal from the antenna passes through the harmonic filter and antenna T/R switch. With the mobile in receive mode, diodes D580, D582 and D583 in the antenna switch are reverse biased allowing the receiver input signal to be coupled through to the receiver front-end with minimal loss.
  • Page 30 SRM9000X8 800MHz SERVICE MANUAL Figure 3-1 Receiver Block Diagram © TMC Radio 2008 page 22 TNM-M-E-0022 Issue 1...

  • Page 31: Receiver Audio Processing

    SRM9000X8 800MHz SERVICE MANUAL Receiver Audio Processing 3.1.4 The baseband audio from the IQ Demodulator is applied to a differential amplifier (U941A/ U941B) that converts the balanced demodulator I and Q output signals to unbalanced inputs for the CODEC (U800).

  • Page 32: Power Control

    SRM9000X8 800MHz SERVICE MANUAL Power Control 3.2.2 The final output power is stabilised by a power control feedback loop. A printed circuit transmission line, L561, resistor R560, diodes D561A and D561B, and other associated components, form the power detector. Comparator U551A and associated components provide the power setting and power control functions.
  • Page 33 SRM9000X8 800MHz SERVICE MANUAL Figure 3-2 Transmitter Block Diagram © TMC Radio 2008 page 25 TNM-M-E-0022 Issue 1...

  • Page 34: Frequency Synthesiser

    SRM9000X8 800MHz SERVICE MANUAL REQUENCY YNTHESISER General 3.3.1 Refer to Figure 3-3. The frequency synthesiser consists of the RX VCO, the second local oscillator VCO (90MHz), loop filters, varactor positive bias generator, reference oscillator, external divider and an integrated fractional N phase locked loop IC (U721).

  • Page 35: Reference Oscillators

    SRM9000X8 800MHz SERVICE MANUAL The divided reference signal is differentiated and discharges C778 via Q771, after which Q771 is turned off allowing C778 to recharge via constant current source Q772. The Schmitt Trigger comprising Q774, Q775 and Q776, converts the modulation combined with the sawtooth ramp, to a square wave output, the duty cycle of which is controlled by the ramp slope and modulation.
  • Page 36 SRM9000X8 800MHz SERVICE MANUAL Figure 3-3 Synthesiser, Block Diagram © TMC Radio 2008 page 28 TNM-M-E-0022 Issue 1...

  • Page 37: Control

    SRM9000X8 800MHz SERVICE MANUAL ONTROL Refer to Figure 3-4. DSP and PLA 3.4.1 The SRM9000 transceiver operates under the control of a DSP (U201) and PLA (U300) combination that, together with a number of other dedicated devices, perform all the operational and processing functions required by the radio.

  • Page 38: Memory

    SRM9000X8 800MHz SERVICE MANUAL Analog voltages to be monitored such as PLL Loop Voltage (LOOP_VOLTS), battery voltage (BAT_SENSE), transmitter current (CURRENT_SENSE) and external sense (EXT_SENSE) are connected to the inverting inputs. The analog voltages are compared with the ramp voltage as they increase, and the comparator switches at the point where the input voltage exceeds the ramp.
  • Page 39 SRM9000X8 800MHz SERVICE MANUAL Figure 3-4 Controller Block Diagram © TMC Radio 2008 page 31 TNM-M-E-0022 Issue 1...

  • Page 40: Ower Upplies

    SRM9000X8 800MHz SERVICE MANUAL OWER UPPLIES Power On Function 3.6.1 The unregulated 13.8V DC input (13V8_UNSW_F) is routed directly to all high current devices and is then switched via FET (Q900) to provide BAT_SW supply for all other circuits. The output from Q900 feeds three low dropout series regulators and switched battery voltage.

  • Page 41: 3.6.2.4 2.5V Regulator U903

    SRM9000X8 800MHz SERVICE MANUAL • PLA U300 • DSP U201 • Flash U202 • Digital supply for CODEC U800 Regulated 3.3V supply (3C3) • Analog supply for CODEC U800 Regulated 3.3V supply (3Q3) • I/Q demodulator U481 Regulated 3.3V supply (3P3) •...

  • Page 42: Alignment (Level 3 Service Only)

    SRM9000X8 800MHz SERVICE MANUAL ALIGNMENT (LEVEL 3 SERVICE ONLY) GENERAL Caution Preparing the radio for alignment will erase from the radio all customer PMR and Trunking configuration data (channel, signalling information etc). The only data retained by the Alignment Tool is the factory alignment data for the radio (DAC settings for Tx power, front-end tuning, etc).

  • Page 43: Test Equipment

    SRM9000X8 800MHz SERVICE MANUAL Calibration sequence On a set that has not previously been calibrated or in which the calibration has been corrupted, preset parameters should be initially loaded into the radio for optimum alignment, after which the calibration steps must be carried out in the following order.

  • Page 44: Preset Parameters

    SRM9000X8 800MHz SERVICE MANUAL Preset Parameters 4.1.3 The table below defines the preset alignment settings for the radio DAC’s. These will be programmed into the radio prior to performing an initial alignment. The Fixed values are not altered by the alignment adjustments whereas the Adjustable values are used as starting points for alignment where the radio has not been calibrated previously, or where the calibration has been corrupted.
  • Page 45 SRM9000X8 800MHz SERVICE MANUAL Variable Name DAC Value Alignment Adjustable Alignment Fixed VCO_Mod_Limit_Low_RP 14000 VCO_Mod_Limit_High_RP 16500 VCO_Mod_Limit_Low_TA 18300 VCO_Mod_Limit_High_TA 19000 Modulation_Bal_Low_RP Modulation_Bal_High_RP Modulation_Bal_Low_TA Modulation_Bal_High_TA VCO_ALC_Low_RP VCO_ALC_High_RP VCO_ALC_Low_TA VCO_ALC_High_TA Sq_Upper_Threshold 2600 Sq_Lower_Threshold 1000 TCXO 14800 Alternate TCXO 6000 CGF_Current CPG_Current CPT_Timer 6.666...
  • Page 46 SRM9000X8 800MHz SERVICE MANUAL Variable Name DAC Value Alignment Adjustable Alignment Fixed Power_Ramp_High_Power_Up_8 Power_Ramp_High_Power_Up_9 Power_Ramp_High_Power_Down_0 Power_Ramp_High_Power_Down_1 Power_Ramp_High_Power_Down_2 Power_Ramp_High_Power_Down_3 46(abs) Power_Ramp_High_Power_Down_4 Power_Ramp_High_Power_Down_5 Power_Ramp_High_Power_Down_6 Power_Ramp_High_Power_Down_7 Power_Ramp_High_Power_Down_8 Power_Ramp_High_Power_Down_9 Power_Ramp_Low_Power_Up_0 10(abs) Power_Ramp_Low_Power_Up_1 Power_Ramp_Low_Power_Up_2 Power_Ramp_Low_Power_Up_3 Power_Ramp_Low_Power_Up_4 Power_Ramp_Low_Power_Up_5 Power_Ramp_Low_Power_Up_6 Power_Ramp_Low_Power_Up_7 Power_Ramp_Low_Power_Up_8 Power_Ramp_Low_Power_Up_9 Power_Ramp_Low_Power_Down_0 Power_Ramp_Low_Power_Down_1 26(abs) Power_Ramp_Low_Power_Down_2...

  • Page 47: Alignment Limits

    SRM9000X8 800MHz SERVICE MANUAL Alignment Limits 4.1.4 TEST NAME HIGH LIMIT LOW LIMIT UNIT TCXO Alignment TX POWER 1.0W 1.06 0.94 TX POWER 5W 5.20 4.80 TX POWER 27.5W 28.0 27.0 VCO MOD LIMIT (Max peak) 2300 2250 MOD BALANCE...

  • Page 48: Test Setup

    SRM9000X8 800MHz SERVICE MANUAL 600R 1:1 SRM9000 P2 Line Matching Noise & Distortion Meter Pins 6 & 13 Transformer & Oscilloscope R = Audio power Load (set as appropriate) Resistor 4R 4W for ½ Bridge Speaker option 9000_49/3b Resistor 8R 12W for full Bridge Speaker option Test Setup 4.1.7...

  • Page 49: Comms Setup

    SRM9000X8 800MHz SERVICE MANUAL COMMS Setup 4.1.8 Copy the SRM9000 Alignment Tool Computer Software file to the PC hard drive and run the program The Alignment Tool Opening Menu is displayed. Go to the Options menu and choose Comms Setup.

  • Page 50: Band Preparation

    SRM9000X8 800MHz SERVICE MANUAL Band Preparation 4.1.9 Go to the Options menu and choose Band. Select appropriate band and choose Hardware Options Select 4.1.10 Options menu choose Hardware Mods. Press Read Radio. Tick the box according to the revision as desired as in the table below.

  • Page 51: Alignment Procedure

    SRM9000X8 800MHz SERVICE MANUAL The WARNING is displayed. Choose No if you want to save the configuration and use the FPP software to read and save the data to a file. Choose Yes if you want to proceed and go to step 3.
  • Page 52 SRM9000X8 800MHz SERVICE MANUAL Calibration procedure Select the VCO DAC page. Select PTT with no modulation. Select Auto Align. The Synth DAC Tx slider will automatically adjust its value for each transmitter alignment frequency to set the VCO loop filter value between 87 and 93.

  • Page 53: Tcxo Dac Alignment

    SRM9000X8 800MHz SERVICE MANUAL TCXO DAC Alignment 4.1.14 General The optimum radio case temperature for TCXO alignment is around 25°C although a temperature between 20°C and 30°C is permissible. If the radio has been allowed to exceed this range during previous transmit cycles, it should be allowed to cool until it is within the permissible range.

  • Page 54: Rx Front End Dac Alignment

    SRM9000X8 800MHz SERVICE MANUAL Rx Front End DAC Alignment 4.1.15 Calibration procedure Ensure that the TCX0 Alignment has been done before proceeding with this section. Select the Rx/Tx Filter page. Select Open Mute. Set the Volume slider to 15. Speaker audio should now be visible on the Scope. If required readjust the Volume slider to a suitable level.

  • Page 55: Tx Filter Dac Alignment

    SRM9000X8 800MHz SERVICE MANUAL Tx Filter DAC Alignment 4.1.16 General This filter should be set so that the Tx spurious emission at 180MHz above the carrier frequency is adequately notched. Calibration procedure Note. This step is only required if Tx Filter DAC values have been corrupted.

  • Page 56: Rssi Calibration

    SRM9000X8 800MHz SERVICE MANUAL RSSI Calibration 4.1.17 Calibration procedure Select the RSSI Cal page. Set the Signal Generator for a RF output level of -90dBm and 3kHz deviation at the specified frequency. Activate the Store RSSI button. The receiver RSSI threshold setting is calibrated.

  • Page 57: Mute Dac Adjustment

    SRM9000X8 800MHz SERVICE MANUAL Mute DAC Adjustment 4.1.18 Note. This adjustment has default setting of 1000/2600 and should not need changing except for specific requirements. Calibration procedure Select the Mute/TCXO page and select Open Mute. Set the RF signal generator to the receiver alignment frequency, and adjust the RF level such that the desired mute opening SINAD (typically 10dB SINAD) is achieved.

  • Page 58: Tx Power Dac Alignment

    SRM9000X8 800MHz SERVICE MANUAL Tx Power DAC Alignment 4.1.19 General The transmitter output power can be programmed to three power ranges: 1W, 5W and 27.5W by the appropriate setting. Note 1: Care should be taken not to set the output power and hence supply current to excessive levels, ie.

  • Page 59: Tx Modulation Dac Alignment

    SRM9000X8 800MHz SERVICE MANUAL Select the 5W power level. Adjust the Tx Final Value slider for a power output of 5W. Repeat step 8 for the remaining 3 Channels (2, 1& 0). Select the 27.5W power level. Adjust the Tx Final Value slider for a power output of 27.5W.
  • Page 60 SRM9000X8 800MHz SERVICE MANUAL Calibration procedure Select Tx Power/Mod page. Select Channel 0. Select the 1W power level. Set the microphone input signal from the Audio Generator to 1000Hz at 400 mV RMS. Select PTT and adjust the VCO Modulation Limit DAC to give a maximum peak deviation of 2.30kHz.

  • Page 61: Programming Alignment Data

    SRM9000X8 800MHz SERVICE MANUAL PROGRAMMING ALIGNMENT DATA 4.1.20 When all channels have been aligned the radio is programmed with the new alignment data: Select Align and choose Write Alignment. A warning message is displayed. Choose Yes. New alignment data is written to the radio.

  • Page 62: Replaceable Parts

    SRM9000X8 800MHz SERVICE MANUAL REPLACEABLE PARTS Figure 5-1 Replaceable Parts EPLACEABLE ARTS Ident Description Quantity per Part Number Assembly Radio Board Assembly X8 Band 6102 359 6232 Extrusion Main Body Macom 6102 310 01452 End Cap, Rear, P25 Option 6102 310 00532...

  • Page 63: Schematics

    SRM9000X8 800MHz SERVICE MANUAL Ident Description Quantity per Part Number Assembly Gasket D Connector 3513 902 1082A Gasket Antenna Connector 3513 902 10651 MAB-2 Option Board- Programmed 6102 359 6213 Screw Option Board M3 x 6 6102 700 00071 Dust Cap P25 Option Connector...
  • Page 64 5V_D CURRENT_SENSE 5V_TX RF_DETECT CLRC 5V_RF CCLK 8V_RX 8V_RF SRM9000 RADIO BOARD C 2006 TMC Radio Pty Ltd ACN 099 952 977 PWR_ON -12V 1270 Ferntree Gully Rd Scoresby Australia 3179 13V8_UNSW 13V8_UNSWF 800 MHz BLOCK DIAGRAM 5V_D 13V8_SW All Rights Reserved...
  • Page 65 09.10.06 U089 UPDATED TO REV B 06.02.07 U128 UPDATED TO REV C 21.06.07 C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 TITLE: DSP MODULE All Rights Reserved 6102 349 6232 2 of 12 ©...
  • Page 66 21.06.07 TP368 U167 UPDATED TO REV 2 07.12.07 Error : SIMOCO-1.WMF file not found. C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 PROG LOGIC ARRAY All Rights Reserved...
  • Page 67 06.02.07 U128 UPDATED TO REV C 21.06.07 U167 UPDATED TO REV 2 07.12.07 C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 RECEIVER All Rights Reserved 6102 349 6232 4 of 12 ©...
  • Page 68 SHIELD SHIELD 21.06.07 SHIELD E501 E502 E503 E505 SHIELD TRAY C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD E506 SHIELD COVER 1270 Ferntree Gully Rd Scoresby Australia 3179 TRANSMITTER All Rights Reserved 6102 349 6232 5 of 12 ©...
  • Page 69 U128 UPDATED TO REV C 21.06.07 U167 UPDATED TO REV 2 07.12.07 C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 PRIMARY VCO All Rights Reserved 6102 349 6232 6 of 12 ©...
  • Page 70 21.06.07 SHIELD SHIELD C768 E701 E700 SRM9000 RADIO BOARD C 2006 TMC Radio Pty Ltd ACN 099 952 977 SYNTHESIZER 1270 Ferntree Gully Rd Scoresby Australia 3179 6102 349 6232 7 of 12 All Rights Reserved © TMC Radio 2008...
  • Page 71 U089 UPDATED TO REV B 06.02.07 U128 UPDATED TO REV C 21.06.07 C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 AUDIO PRCCESSING All Rights Reserved 6102 349 6232 8 of 12 ©...
  • Page 72 Note 1. Currents indicated are typical for radio only in Rx squelched mode U128 UPDATED TO REV C 21.06.07 C 2006 TMC Radio Pty Ltd ACN 099 952 977 SRM9000 RADIO BOARD 1270 Ferntree Gully Rd Scoresby Australia 3179 POWER SUPPLIES...
  • Page 73 UPDATED TO REV C 21.06.07 L3M_B DEEMPH_AUDIO CCLK MIC AUDIO AUDIO_IN1 AUDIO_OUT_4 220R C 2006 TMC Radio Pty Ltd ACN 099 952 977 D17A D17B SRM9000 RADIO BOARD BAV99W CLRC 1270 Ferntree Gully Rd Scoresby Australia 3179 BAV99W I/O CONNECTIONS...
  • Page 74 6102 309 62322 6102 309 6232 800MHz RADIO BOARD 114 - 301 U167 TOP COMPONENT OVERLAY C 2006 TMC Radio Pty Ltd ACN 099 952 977 1270 Ferntree Gully Rd Scoresby Australia 3179 All Rights Reserved © TMC Radio 2008 page 66...
  • Page 75 TP349 6102 309 6232 800MHz RADIO BOARD BOTTOM COMPONENT OVERLAY 114 - 302 U167 C 2006 TMC Radio Pty Ltd ACN 099 952 977 1270 Ferntree Gully Rd Scoresby Australia 3179 All Rights Reserved © TMC Radio 2008 page 67...
  • Page 76 SRM9000X8 800MHz SERVICE MANUAL APPENDIX A - GLOSSARY OF TERMS A summary of common radio terms and some other terms used in this document, and their meanings, are given below. Analog to Digital Converter. Automatic Frequency Control. Automatic Gain Control.
  • Page 77 SRM9000X8 800MHz SERVICE MANUAL A communications set-up whereby different groups of radios can operate by using only Community Repeater one base station. This is achieved by the use of CTCSS tone signalling such that each group has a different CTCSS tone (encode and decode) and radios can only communicate with other radios in their group.
  • Page 78 SRM9000X8 800MHz SERVICE MANUAL Fast Frequency Shift Keying. This is a signalling system for the transfer of digital FFSK information. It works by using one of two audio tones to represent transmit data.. Fleet A group of units formed such that only a shortened form of dialling (2 or 3 digits) is required between them.
  • Page 79 SRM9000X8 800MHz SERVICE MANUAL Normally this is generated from a high stability crystal oscillator reference and is divided Reference Frequency digitally in a frequency synthesiser for comparison with other frequency sources, e.g. a VCO. Repeat Tone A selcall tone that is used to replace repeated tones. Fixed at tone E.
  • Page 80 SRM9000X8 800MHz SERVICE MANUAL through status digits in Selcall identities. Either in Encode Identities or Decode Identities as follows: Encode Identities: Status digits within the identity are used to transmit the current situation of the radio's user (e.g. "Out To Lunch").
