- Page 1 SRP 9100 Series FM VHF/UHF Portable Radio Transceiver SERVICE MANUAL TNM-M-E-0012 ISSUE 1.24 January 2006...
-
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS..........................1.1 DECLARATION ............................1.3 COPYRIGHT ..............................1.3 ERRORS AND OMISSIONS........................1.3 DOCUMENT HISTORY..........................1.4 LIST OF ASSOCIATED PUBLICATIONS....................1.4 WARNINGS AND CAUTIONS........................1.5 GLOSSARY OF TERMS..........................1.5 GLOSSARY OF TERMS..........................1.6 INTRODUCTION..........................1.13 ............................1.13 ENERAL ............................1.13 COPE ..........................1.13 ESCRIPTION ...................1.14 RODUCT ARIANTS ACILITIES .....................1.16 OFTWARE ERSIONS AND AMING... - Page 4 ........................2.29 OFTWARE OLICY DISASSEMBLY ..........................3.30 TECHNICAL DESCRIPTION......................4.1 .............................4.1 ECEIVER 4.1.1 Front-End Filters and RF Amplifier..................4.1 4.1.2 First Mixer and IF Section ....................4.1 4.1.3 Quadrature Demodulator....................4.1 4.1.4 Receiver Audio Processing ....................4.2 ..........................4.3 RANSMITTER 4.2.1 Drivers and PA Stages .......................4.3 4.2.2 Power Control........................4.3 4.2.3 Antenna Changeover and Harmonic Filter.................4.3 4.2.4...
-
Page 5: Declaration
Copyright All rights reserved. No part of this publication may be reproduced in any form or by any means without the prior permission of TMC Radio. Errors and Omissions The usefulness of this publication depends upon the accuracy and completeness of the information contained within it. -
Page 6: Document History
Document History Issue Date Comments Draft A-1 2004-01-10 Initial issue for Review 1.21 2004-05-15 Official Release 1.22 2004-06-24 Replaceable parts BOM corrected 1.23 2005-01-31 Update Mute/Audio offset adjustment 1.24 2005-09-05 Updated for Rev 2. List of Associated Publications Document No. Description Issue TNM-U-E-0045... -
Page 7: Warnings And Cautions
Warnings and Cautions WARNING The Power Amplifier Module may use semiconductor devices containing Beryllium Oxide. Dust from this oxide is toxic and, if inhaled or skin contact is made, can be hazardous to health. No danger can arise from normal handling, but no attempt should be made to break open or tamper with these devices in any way. -
Page 8: Glossary Of Terms
GLOSSARY OF TERMS A summary of common radio terms and some other terms used in this document, and their meanings, are given below. Trunking Signalling Specification relating to trunked networks for shared use. Used primarily for networks in France. Analogue to Digital Converter. Automatic Frequency Control. - Page 9 CLIM Call Limit Time; time limit on calls made. Normally this is defined by the Call Time Limit parameter but can by overridden by the TSC depending upon the setting of TSCLIM. Emergency Call Limit Timer. CLIME Closed A state where transmit and receive are not allowed until a Selcall message to open the channel has been received.
- Page 10 Digital Signal Processor. Abbreviation of Dual Tone Multi-Frequency signalling. Used to dial into Telephone DTMF networks using tone dialling. Dual Watch A facility that enables the Radio to periodically monitor another channel for a signal above squelch. Typically applications are checking an emergency channel whilst on another channel.
- Page 11 Link Establish Time A delay incorporated into the start of every selective call or DTMF transmission that allows for the finite delay of the radio equipment in responding to any radio signal. This includes both the commencement time of the originating transmitter and the response time of the receiver.
- Page 12 If inhibited from transmitting a Selcall sequence because the channel is busy then the radio can queue the Send 1 / Send 2 sequence for later transmission. When a radio unit is in Queuing mode all incoming calls are stored automatically in a queue for later examination.
- Page 13 Simplex Mode of operation whereby the radio operates as a conventional fixed channel radio outside the Trunking network. System used to prevent weak, unintelligible signals and random noise from being Squelch heard by a radio operator while still allowing intelligible signals to be received normally.
- Page 14 Trunked Mobile Radio. An audio tone is transmitted at the start of transmission to inform a relay (repeater) Tone Burst station to switch itself on to relay the transmission. Transpond An Acknowledge identity sent as a response to an individual call. TRAXYS Air Interface for the PTT Telecom Trunked Radio Network, used in the Netherlands.
-
Page 15: Introduction
INTRODUCTION ENERAL The SRP9100 series of FM portable radio transceivers are designed for conventional PMR and Trunked operation in VHF and UHF radio systems. The transceiver is available in three functional variants. The variants are as follows: Description PMR/Trunked Portable Transceiver with no Keypad SRP9120 Portable Transceiver with Keypad SRP9130... -
Page 16: Product Variants And Facilities
RODUCT ARIANTS ACILITIES Product variants and facilities are detailed in Table 1-1, Table 1-2 and Table 1-3. Table 1-1 Common Features for All Variants Feature: Model: 9120 9130 9130+ Keys 7 Function keys. All keys 7 Function keys. All keys 7 Function keys. - Page 17 Table 1-3 Trunked Variants Feature: Model: 9120 9130/9130+ Channels 1024 channels in 50 sub-bands Specifically: 136-174MHz, 400-450MHz (and possible in all other bands) Frequency Bands Background Hunt and Vote-Now MPT1343 dial strings ANN Numbering Phonebook Memories User Phonebook Recall entries configured by FPP only. Recall and edit.
-
Page 18: Software Versions And Naming
OFTWARE ERSIONS AND AMING There are various associated items of Software (SW) required for the SRP9100 radio and programmer to operate. This section simply defines the naming rules of the SW files to allow identification and conformity. This allows different versions of SW to be distributed and co-exist without confusion. The SRP9100 Transceiver has three items of SW for digital and analogue PMR, Trunking and Alignment. -
Page 19: Version Number
Version Number 1.5.4 This is a 3-digit number allocated by Engineering to identify the SW version. Version 1.03 Exclusions 1.5.5 The Programmer SW does not follow the above rules, as it is a PC based Program and its version number can be easily identified by starting the SW. -
Page 20: Automatic Version Upgrade Prompting
For Software loaded in the radio, information can be read from the Transceiver and displayed via the Programmer function: Options : Radio_Information The portable software version can be read from the portable display if required by accessing the Set-up menu and then choosing Radio Info and selecting the software version on the radio. Automatic Version Upgrade Prompting 1.5.7 When a configuration is downloaded to the Transceiver, the Programmer performs a brief check on the SW... -
Page 21: Transceiver Sw Description, Start-Up And Backup-Software
Transceiver SW Description, Start-up and Backup-Software 1.5.8 The SRP9100 Transceiver software is split into the following separate modules: • Bootloader and Backup Software • Start-Up Software • PLA and PLA-Backup Software • Mainline PMR Software • Mainline Trunk Software When the Transceiver starts, it basically performs the following steps: •... -
Page 22: Adjustment And Alignment
DJUSTMENT AND LIGNMENT There are no internal adjustments in the SRP9100. Re-programming and alignment is performed using software tools. For testing, a special test jig is required so that the radio PCB can be powered and input/output accessible. This test jig has a dummy battery and a connector that plugs into the top of the radio so that the jig controls PTT and provides access to audio in and out. -
Page 23: Transmitter
Radio only 210g Battery NiCad 1600mAH 250g Battery NIMH 2150mAH 230g Battery Li 3000mAH 180g Battery NiMH 2700mAH 280g Antenna E0 Antenna UW > 10 hours, high transmit power, 2700mAh battery, 90:5:5 duty Battery Endurance cycle Conformance Approvals EN 300 086 * EN 300 113 * * Pending in some cases EN 300 489 *... -
Page 24: Receiver
Receiver AS4295 1.7.3 ≤0.5µV PD (-113dBm) for 20dB ≤0.3µV PD (-117.5dBm) for 12dB SINAD Sensitivity SINAD ≤0.5µV PD (-113dBm) for 20 dB Quieting. 25kHz Channel Spacing: >73dB 25kHz Channel Spacing: >73dB Adjacent Channel Selectivity 12.5kHz Channel Spacing: >60dB 12.5kHz Channel Spacing: >65dB Intermodulation Rejection >65dB >70dB... -
Page 25: Signalling
Signalling 1.7.4 1.7.4.1 CTCSS All 38 standard CTCSS Tones are supported as per the table below. Identifier Frequency Identifier Frequency Identifier Frequency 67.0 107.2 167.9 71.9 110.9 173.8 74.4 114.8 179.9 77.0 118.8 186.2 79.7 123.0 192.8 82.5 127.3 203.5 85.4 131.8 210.7... -
Page 26: Ffsk
Decoder Not greater than ±3.0% Bandwidth Deviation Sensitivity Less than 6.0% of system deviation (for decode with full RF quieting) Noise Immunity Less than 500ms dropout per minute at 10dB SINAD (CTCSS tone deviation 10% of system deviation. RF deviation 60% at 1000Hz). - Page 27 Selcall Tone Frequency Table Tone ST500 SIGTEC SIGTEC SEPAC ST500 SIGTEC CCIR CCIR CCIR CCIRH CCIR 1981 1981 1981 1981 1981 1981 1981 1981 1124 1124 1124 1124 1124 1124 1124 1124 1197 1197 1197 1197 1197 1197 1197 1197 1275 1275 1275...
-
Page 28: Dtmf
Tone SEPAC ST500/CML ST500 SIGTEC SIGTEC SEPAC ST500 ZVEI-3 ZVEI-3 DZVEI DZVEI NATEL 2200 2400 2200 2200 1633 1060 1060 1160 1060 1060 1160 1270 1160 1160 1023 1023 1023 1270 1400 1270 1270 1164 1164 1164 1400 1530 1400 1400 1305 1305... -
Page 29: Dcs
1.7.4.5 DCS Data rate 134 bits per second, frequency modulated 7.46ms/bit 171.6ms per codeword continuously repeating Deviation 0.5kHz for 12.5kHz systems 1kHz for 25kHz systems Codeword size 23 bits comprising: 8 bits - DCS code (3 octal digits 000-777) 3 bits - Fixed octal code 4 11 bits - CRC (error detection) code Available Codes 104 codes from 512 theoretically possible codes –... -
Page 30: Environmental
Environmental 1.7.5 Note: Operation of the equipment is possible beyond the limits stated but is not guaranteed. Operational Temperature -30°C to +60°C Storage Temperature -40°C to +80°C Vibration Specification IEC 68-2-6 with additional frequency acceleration from 60 – 150Hz Cold IEC 68-2-1 Test 5 hours at -30°C Dry Heat IEC 68-2-2 Test 5 hours at +60°C... -
Page 31: Service Concept
OFTWARE OLICY Software provided by TMC Radio shall remain the Company's property, or that of its licensors and the customer recognises the confidential nature of the rights owned by the Company. The customer is granted a personal, non-exclusive, non-transferable limited right of use of such software in machine-readable form in direct connection with the equipment for which it was supplied only. -
Page 32: Disassembly
The customer undertakes not to disclose any part of the software to third parties without the Company's written consent, nor to copy or modify any software. The Company may, at its discretion, carry out minor modifications to software. Major modifications may be undertaken under a separate agreement, and will be charged separately. - Page 33 Remove the Metal Frame Assembly (1) Use a small, flat bladed screwdriver to release the cast metal frame assembly from the bottom of the front casing. This action releases the radio PCB from the MMI PCB. (2) Gently ease the frame assembly out of the front casing taking care not to damage the two flexi-circuits. (lift the bottom of the frame so that it just clears the plastic casing, then gently slide the frame away from the top of the casing until it is released from the casing).
- Page 34 Remove the Speaker and Microphone (1) Remove the speaker retaining clip. (2) Lift the speaker / microphone assembly away from the front casing taking care not to damage the flexi- circuit. Figure 3 Removal of Speaker and Microphone Remove the MMI PCB The MMI PCB is held in place by four plastic lugs on the front casing.
- Page 35 Remove the Switch Mat The switch mat is held in place by the MMI PCB. Lift the switch mat clear of the casing. RE-ASSEMBLY Re-assembly is the reverse of disassembly. However: (1) Examine the various seals before re-assembly and replace with new items if necessary. (2) Slight outward deflection of the case walls will ease re-assembly of the MMI PCB behind the retaining lugs.
-
Page 37: Technical Description
TECHNICAL DESCRIPTION ECEIVER Refer to Figure 4-1. Description based on UW band Front-End Filters and RF Amplifier 4.1.1 The receiver input signal from the antenna passes through the harmonic filter and antenna switch. With the portable in receive mode, diodes D580, D540a and D541a in the antenna switch are reverse biased allowing the receiver input signal to be coupled through to the receiver front-end with minimal loss. -
Page 38: Receiver Audio Processing
Synthesiser RX VCO VCO Buffer SYNTH Buffer to U701 Control Volts Q600 Q604/Q605 Q607 ACK_LO2 to U701 90 MHz RX VCO TX/RX AUX_CP Switch Switch Q402 RX_PSU from U701 Q601 D610/D611 Antenna 4 Pole Harmonic Switch Bandpass RF Amp BandPass Mixer IF Amp 45MHz IF... -
Page 39: Transmitter
RANSMITTER Refer to Figure 4-2. Drivers and PA Stages 4.2.1 The RF output level from the VCO T/R switch D611a is typically +8dBm. Tx buffers Q550/Q560 increase this level by approximately 6dB (136-530MHz), 9dB (66-88MHz) and also provide a high degree of VCO isolation from the Tx output. - Page 40 PWM TX Power Thermal Set from PLA Integrator TX_PWR Shut Back R308/C307 R532 Power Control Antenna Comparator Switch Power To RX Mixer PA_ON U520A Control from PLA Control Q541/ Detector Q542 D510 LO1_RX Antenna TX/RX TX Buffer Antenna Switch TX_MOD TX VCO Buffer Switch...
-
Page 41: Frequency Synthesiser
REQUENCY YNTHESISER General 4.3.1 Refer to Figure 4-3. The frequency synthesiser consists of one transmitter and two receiver voltage controlled oscillators, loop filters, varactor negative bias generator, reference oscillator and an integrated dual phase locked loop device U701. 4.3.2 The PLL device contains two prescalers, programmable dividers and phase comparators to provide a main and auxiliary PLL. -
Page 42: Reference Oscillator
Tool. Adjustment of the ramp slope effectively changes the Phase Modulator gain by modification of the Schmitt Trigger switching points after modulation from the Integrator is combined to the saw tooth ramp. The divided reference signal is differentiated and discharges C744 via Q711 after which Q711 is turned off allowing C744 to recharge via constant current source Q712/Q713. -
Page 43: Control
ONTROL Refer to Figure 4-4. DSP and PLA 4.4.1 The SRP9100 transceiver operates under the control of a DSP (U201) and PLA (U300) combination that together with a number of other dedicated devices perform all the operational and processing functions required by the radio. -
Page 44: Memory
Analogue voltages to be monitored such as PLL Loop Voltage (LOOP_VOLTS), key detect (KEY_DET), battery voltage (BAT_SENSE), transmitter current (TC_CURRENT), volume level (VOLUME) and external sense (EXT_SENSE) are connected to the inverting inputs. The analogue voltages are compared with the ramp voltage as they increase and the comparator switches at the point where the input voltage exceeds the ramp. -
Page 45: Regulator U900
The Power-off operation requires the On-Off switch to be turned off for more than 2 seconds. If the On-Off switch is sensed going low by the DSP via the PWR_SENSE line, the DSP will save radio settings and then lower the PWR_OFF line, thereby turning Q900 off. Power Supplies 4.6.2 The following is a list of the SRP9100 power supplies and some of the devices and circuits they supply. -
Page 46: Eyboard And Isplay (Mmi)
(MMI) EYBOARD AND ISPLAY Keypad Press Detection Electronically, the keypad keys are arranged in a matrix of 3 rows and 7 columns. The rows are driven directly by two processor port signals KEY_ROW1 and KEY_ROW2 that are normally in the low state. Transistors TR910-916 generate a unique voltage on KEY_DET3 for each column. Any key in the same column generates the same voltage. - Page 47 Figure 5 Keypad Layout Backlighting The LCD and keypad backlighting LED’s, D904 to D918, are turned on by the processor port signal, BLITE, via driver TR909. 3 ~ TECHNICAL DESCRIPTION Page 4.11...
-
Page 49: Alignment (Level 3 Service Only)
TNM-M-E-0012 Issue 1.23 ALIGNMENT (LEVEL 3 SERVICE ONLY) This procedure is applicable to all versions of SRP9100 portable transceivers. Caution Preparing the radio for alignment will erase from the radio all customer PMR and Trunking configuration data (channel, signalling information etc). The only data retained by the Alignment Tool is the factory alignment data for the radio (DAC settings for Tx power, front-end tuning etc). - Page 50 Zener 5v6 RxD In 330R 1% DB9F TXD Out to PC 3.5mm 1uF Bipolar TX AF 470u P1761 2.5mm RX AF 680R 470u Figure 5-1 SRP9100 Radio Test Interface Unit Notes for test jig: 1. The PTT switch activates transmit on the portable. 2.
-
Page 51: Test Set
TNM-M-E-0012 Issue 1.23 Communications Test Set Antenna Accessory Connections To Power Supply RX Audio To PC Serial Port TX Audio Test Interface Box Figure 5-2 Test Set-up Notes: Connect the radio to the test equipment as shown in Figure above. Use an adaptor (P/N PA-ACON) to provide a coaxial socket termination for the antenna. - Page 52 Go to the Options menu and choose Comms Setup. The Comms Setup dialogue box is displayed. Select the Comms Port setting appropriate to the configuration of your PC and choose (Usually COM1) 6 ~ CIRCUIT DIAGRAMS Page 5.4...
-
Page 53: Radio Preparation
TNM-M-E-0012 Issue 1.23 Radio Preparation 5.2.2 Radio parameters are to be aligned sequentially as detailed in this procedure. At the Opening Menu, select the Align Menu and choose Prepare/Read Radio. The WARNING is displayed. Choose No if you want to save the configuration and use the FPP software to read and save the data to a file. -
Page 54: Alignment Procedure
Alignment Procedure 5.2.3 Radio alignment must be done in the sequence detailed in the following paragraphs. This alignment assumes that the radio is functioning normally. 5.2.3.1 VCO DAC Alignment Select the VCO DAC page. Select Auto Align. The Synth DAC Rx slider will automatically adjust its value for each receiver alignment frequency to set the VCO loop filter value between 140 and 150. -
Page 55: Tcxo (Radio Netting Adjustment)
TNM-M-E-0012 Issue 1.23 5.2.3.2 TCXO (Radio Netting Adjustment) Select the Mute/TCXO page. Select PTT. Adjust the TCXO slider to ensure that the transmit frequency error is within 50Hz for the selected channel (to be measured on the RF Test Set frequency counter). 6 ~ CIRCUIT DIAGRAMS Page... -
Page 56: Rx Front End
5.2.3.3 Rx Front End Ensure that the TCX0 Alignment has been done before proceeding with this section. Select the Rx Front End Page Select Open Mute. Set the Volume slider to 15. Speaker audio should now be visible on the Scope. If required readjust the Volume slider to a suitable level. -
Page 57: Mute/Audio Balance Adjustment
TNM-M-E-0012 Issue 1.23 5.2.3.4 Mute/Audio Balance Adjustment Note. This adjustment has default setting of 1000/2600 and should not need changing except for specific requirements. Select the Mute/TCXO page and select Open Mute. Set the RF signal generator to the receiver alignment frequency, and adjust the RF level such that the desired mute opening SINAD (typically 10dB SINAD) is achieved. -
Page 58: Rssi
5.2.3.5 RSSI Select the RSSI Cal page. Set the Signal Generator for a RF output level of –90dBm and 2kHz deviation at the specified frequency. Activate the Store RSSI button. The receiver RSSI threshold setting is calibrated. Monitor the battery voltage at the simulated battery terminals with an accurate multimeter. Adjust the power supply so that the voltage reads exactly 7.2V ±5mV. -
Page 59: Tx Power
TNM-M-E-0012 Issue 1.23 5.2.3.6 Tx Power Select Tx Power/Mod page. Select Channel 0. Select the 0.5W power level. Press the PTT button. Adjust the Tx Final Value slider for a power output of 0.5W. Repeat step 5 for the remaining 3 Channels (1, 2, & 3). Select the 1W power level. -
Page 60: Modulation
5.2.3.7 Modulation Select Tx Power/Mod page. Select Channel 0. Select the 0.5W power level. Set the microphone input signal from the Audio Generator to 1000Hz at 100mV RMS. Adjust the VCO Modulation Limit slider for a maximum peak deviation of ±2.3kHz Reduce the microphone input level to 10mV RMS and check that the deviation is within the range ±1.25 kHz to ±1.75 kHz. -
Page 61: Programming
TNM-M-E-0012 Issue 1.23 5.2.3.8 Programming When all channels have been aligned the radio is programmed with the new alignment data: Select Align and choose Write Alignment. A warning message is displayed. Choose Yes. New alignment data is written to the radio. 5.2.3.9 Customers Radio Configuration Data If the Customers Radio Personality Data was saved as a separate file, use the FPP Programmer to write this data to the radio. -
Page 62: Replaceable Parts
REPLACEABLE PARTS The parts listed in this section are considered to those most likely to need replacement due to physical damage to the radio. Figure 6-1 Replaceable Parts OMMON ARTS Ident Description Quantity per Part Number Assembly ACTUATOR PTT BLACK 6102 310 00131 ACTUATOR SIDE KEY B BLACK 6102 310 00121... -
Page 63: Ccessories
TNM-M-E-0012 Issue 1.23 CCESSORIES Description Part Number ACCESSORY CORD STRAIGHT (UNTERMINATED) SRP9100 PA-LDST ANTENNA HELICAL E0 BAND (66-88 MHz) SRP9100 PA-AHE0 ANTENNA HELICAL HIGH PERFORMANCE E0 BAND (66-88 MHz) SRP9100 PA-AHE0-HIGH ANTENNA HELICAL AC BAND (136-174 MHz) SRP9100 PA-AHAC ANTENNA HELICAL K1/KM BAND (174-245 MHz) SRP9100 PA-AHAK ANTENNA WHIP R1 BAND (335-375 MHz) SRP9100 PA-AWR1... -
Page 64: Accessory Connector
APPENDIX A - ACCESSORY CONNECTOR The following table details the connections on the accessory connector. Connection Signal Name Signal type Direction 2.5mm Tip MIC1 Multi-function, audio in, 0-5V To Radio ancillary type voltage and key press voltage. 2.5mm Ring EXT_LS1A Balanced Speaker Drive Nominal Mid Supply To Accessory... -
Page 65: Accessories
TNM-M-E-0012 Issue 1.23 APPENDIX B - ACCESSORIES Lapel Speaker Microphone Figure 2 Lapel Speaker Microphone Introduction The lapel loudspeaker / microphone is a robust, lightweight, unit with an integral press-to-talk (PTT) switch and a headset socket. The unit connects to the portable radio via a 1.5m ‘curly’ cable with a 2.5mm (J1) and 3.5mm (J2) stereo jack plugs mounted in a single moulding. - Page 66 Headset socket 3.5mm - loudspeaker disconnected when jack inserted Environmental: Operating temperature range –20°C to +55°C Storage temperature range –40°C to +80°C Figure 3 Lapel Speaker Microphone Circuit OPERATION Ancillary Type R3 defines the ancillary as a Lapel Speaker / Microphone. Microphone The microphone connects to the radio via the tip of the 2,5mm stereo jack (J1) and is powered via the ring and sleeve of the 3.5mm stereo jack (J2) on the cord assembly.
