Page 1: Induction Cooktop
USER GUIDE Induction Cooktop NS-IC2ZBK7 Before using your new product, please read these instructions to prevent any damage. -
Page 2: Table Of Contents
Table of Contents Safety information Features Package contents Cooktop Control panel Cookware compatibility Assembling your cooktop Installing your cooktop Positioning your cooktop Installing your cooktop Using your cooktop Checking pan compatibility Using touch controls Cooking with your cooktop Using the timer Locking the control panel Cleaning and maintenance Troubleshooting... -
Page 3: Safety Information
Induction Cooktop Safety information Important - Save for the local electrical inspector's use. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your cooktop. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your cooktop. - Page 4 NS-IC2ZBK7 10. Do not place on or near a hot gas or electric burner, or in a heated oven. 11. To disconnect, turn any control to “off,” then remove the plug from the wall outlet. 12. Do not use the appliance for other than its intended use.
- Page 5 Induction Cooktop 3. To avoid affecting product performance and to prevent injury, do not heat empty pots. When in use, do not leave the appliance without supervision for a long time. When leaving the appliance without supervision, make sure that there is enough water in the pot.
- Page 6 NS-IC2ZBK7 15. This cooktop should be kept clean during and after use. Protect the cooktop from bugs, dust, and humidity. Avoid letting anything fall into the interior of the cooktop, which could result in a short circuit of the electrical components.
- Page 7 Induction Cooktop 29. Wear proper apparel. Loose-fitting or hanging garments should never be worn while using the appliance. 30. Never leave surface units unattended at high heat settings. Boilover causes smoking and greasy spillovers that may ignite. 31. Storage on appliance. Flammable materials should not be stored near surface units.
-
Page 8: Features
NS-IC2ZBK7 Features Glass cooktop evenly distributes heat 10-stage power levels and 3-hour timer for versatile use Feather-touch controls for easy operation Temperature protection and child lock provide added safety Package contents Induction Cooktop Fan covers (2) User Guide Cooktop www.insigniaproducts.com... -
Page 9: Control Panel
Induction Cooktop Control panel Cookware compatibility Hold a magnet to the bottom of your cookware. If it clings, it will usually work with your cooktop: Works Does not work Cast iron, iron, Glass, ceramic, aluminum, steel/stainless steel, copper, and other non- enameled iron magnetic materials Use a pan with a flat bottom. -
Page 10: Assembling Your Cooktop
NS-IC2ZBK7 Assembling your cooktop 1. Carefully turn the cooktop upside down. 2. Push the fan cover connectors into the holes next to the fans until you hear a click. Note The connectors are different sizes. If they don't fit in the holes, turn the fan cover 180°. -
Page 11: Installing Your Cooktop
Induction Cooktop Installing your cooktop Follow these instructions to install the cooktop into your counter. Make sure that your cooktop is properly installed by a qualified technician. Positioning your cooktop Before cutting, make sure that your cooktop will have: At least 30” (76.2 cm) between the cooktop and overhead surfaces At least 6”... -
Page 12: Installing Your Cooktop
NS-IC2ZBK7 Installing your cooktop Note When cutting, use tools that are appropriate for your counter and cupboard. 1. Cut a 23.4 × 14.3 in. (59.4 × 36.6 cm) hole into the top of your counter. 2. Cut a 8 × 1 in. (20.3 × 2.5 cm) hole into the front of your cupboard to vent your cooktop. - Page 13 Induction Cooktop 3. Cut a 20 × 1.2 in. (50.8 × 3.0 cm) hole into the back wall of your cupboard to vent your cooktop. Make sure that the cut is centered and 1 in. (2.5 cm) from the surface of your counter. 4.
-
Page 14: Important Instructions
NS-IC2ZBK7 IMPORTANT INSTRUCTIONS Using your cooktop Note After the first use, it is normal for white spots to appear on the bottom of your pan. See Cleaning and maintenance (on page 17) for more information. Checking pan compatibility Hold a magnet to the bottom of your cookware. If it clings, it will usually work with your cooktop. - Page 15 Induction Cooktop 2. Plug the power cord into a power outlet. Note Do not use an extension cord to connect your cooktop. If the power cord is too short, have a qualified electrician or serviceman install an outlet near the appliance. 3.
-
Page 16: Using The Timer
NS-IC2ZBK7 Using the timer Use timer mode with temperature or heat mode to select how long you want the cooktop to run. 1. While in temperature mode, press TIMER. The “timer” indicator lights up and “0:00” blinks on the screen. -
Page 17: Cleaning And Maintenance
Induction Cooktop Cleaning and maintenance Cleaning your pans After the first use, it is normal for white spots to appear on the bottom of your pan. To remove the spots, pour vinegar into your cookware, heat it to about 140-176°F (60-80°C), then wipe the spots away with a brush. Cleaning your cooktop Before cleaning, turn off the cooktop, unplug the power cord, and wait until the cooktop is cool. - Page 18 NS-IC2ZBK7 Problem Solution Make sure that you are using a compatible pan. Cookware compatibility (on page 9). Make sure that the pan's bottom is flat, centered, and large enough for the cooking zone. The cooktop cannot detect smaller pans. Make sure that the pan's diameter is at least 4.7 in. (12 cm).
- Page 19 Induction Cooktop Problem Solution The main sensor has an open circuit. If the error persists, bring your cooktop to a repair technician to be fixed. The main sensor has short circuited. If the error persists, bring your cooktop to a repair technician to be fixed. The main sensor is too hot: If the cooktop is hot, wait for it to cool.
-
Page 20: Specifications
NS-IC2ZBK7 Specifications Dimensions 24.4 × 15 × 2.8 in. (62.0 × 38.1 × 7 cm) Weight 14.1 lbs. (6.4 kg) Voltage 12V AC, 60 Hz Left burner: 1500W Wattage Right burner: 1500W Both burners: 1750W Country of origin China Legal Notices... -
