SkyStream 3.7 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Skystream 3.7
Owner's Manual
TM
I N S TA L L AT I O N
O P E R AT I O N
M A I N T E N A N C E
Southwest Windpower, Inc.
1801 West Route 66
Flagstaff, Arizona 86001
Phone: 928.779.9463
Fax: 928.779.1485
Web: www.skystreamenergy.com
© August 2006 Southwest Windpower, Inc. All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Skystream 3.7 and is the answer not in the manual?

Questions and answers

Summary of Contents for SkyStream Skystream 3.7

  • Page 1 Skystream 3.7 Owner’s Manual I N S TA L L AT I O N O P E R AT I O N M A I N T E N A N C E Southwest Windpower, Inc. 1801 West Route 66 Flagstaff, Arizona 86001 Phone: 928.779.9463...
  • Page 2 Before going any further, please complete and return the enclosed Warranty Registration Card. The conditions of your warranty are dependent upon the proper installation of Skystream. Furthermore, this will assure you of being kept up-to-date with the latest developments from Southwest Windpower.These include new options, performance tips, updated software to maximize output and user notices.

  • Page 3: Important Safety Instructions

    Always obtain a building permit before construction. Warning: Risk of injury or When moving Skystream or any heavy objects to the site, use a cart to prevent back injury. death - proceed with extreme If unusual noise or abnormal operation is observed from Skystream, turn off the caution machine and contact authorized service personnel.

  • Page 4: Table Of Contents

    1-2 Recommended Tools __________________________ 6 1-3 Skystream Options ____________________________ 7 1-4 Skystream Project Preparation ____________________ 8 1-4-1 Finding the Best Location for Your Skystream ____ 8 1-4-2 Tower Types ____________________________ 9 1-4-3 Working With Your Utility __________________ 9 1-4-4 Working With Your Local Zoning Authority ______ 9...
  • Page 5 Skystream 3.7 Technical Specifications PERFORMANCE GRAPH 2400 Southwest binned 20-sec average 2100 1800 Skystream 3.7 Model 1500 1.8 kW rated 2.4 kW peak Rated Capacity 1200 NWTC 170 lbs. / 77 kg Weight 1-min averages 12 feet / 3.72 meters Rotor Diameter 115.7 ft...

  • Page 6: Before Installation

    Weight: 40 lbs (18 kg) Upon opening, carefully inspect each of the blades to make sure there are no fractures or cracks in the surfaces. Although the Skystream rotor blades are comprised of a durable compression molded fiberglass, damage can occur to the blades during shipping. Once inspected, be sure to set them away from the construction site and protect them from any damage until they are ready for assembly.

  • Page 7: Recommended Tools

    Your Skystream shipment includes: Your Skystream shipment includes the following components. A spare of each fastener (bolt, washer or nut) is included.The quantities indicated below are quantities required to assemble Skystream: RF Antenna Yaw vibration isolators with mounting hardware Vibration Isolators (quantity 8) ®...

  • Page 8: Skystream Options

    1-3 Skystream Options There are a number of options that can enhance the experience of using a Skystream wind appliance. Although your Skystream will operate without them, we suggest reviewing this chapter. Contact Southwest Windpower or your dealer if you have questions.

  • Page 9: Skystream Project Preparation

    Proper siting is essential to a well performing wind generator. The taller the tower, the more energy your Skystream will produce but keep in mind, this will also increase the cost of the installation. It is extremely important to balance performance (tower height) to installed cost in order for you to achieve the lowest cost of energy and quickest payback.

  • Page 10: Tower Types

    Like your utility, the local planning and zoning authority may or may not have experience with an individual installing a small wind generator at their home or small business.The most important issue is the height of the tower. Prior to purchasing your Skystream tower, check for local zoning limitations.

  • Page 11: Installation

    You will notice the rotor shaft on Skystream is extremely difficult to turn.This is normal. As a safety precaution, the default position of Skystream is in brake mode when the inverter is disconnected from the utility-supplied power.The reason is if there is a fault in the utility line, Skystream must shut down to prevent back feeding of electricity into the line while it is being repaired.
  • Page 12 AC Service Panel Yaw ground wire Main disconnect Yaw connectors. See Fig. 4 (page 12) Optional kilowat-hour 2 2 0 0 A A meter 2 2 0 0 A A G N L2 L1 N N L L 2 2 L L 1 1 White Black...

  • Page 13: Electrical Connections

    2-1-3 Wire Sizing test, check all connections and repeat test.Test must be passed before proceeding. Measure distance from AC Service panel to Skystream (be sure to Caution: Make sure AC Turn power off and secure include tower height). Refer to the accompanying wire chart and strain relief cover using select the appropriate gauge wire.

  • Page 14: Grounding

    Again, it is extremely important to install in accordance with local and national zoning regulations. Note: Only 20 Amp circuit breakers may be used to connect Skystream to AC service panel. Refer to Fig. 3, wiring diagram. 2-1-6 Checking correct grid connectivity Fig.

  • Page 15: Installing Skystream On A Tower

    2-2 Installing Skystream on a Tower There are several types of towers that can be used with Skystream. It is essential that Skystream is installed on a properly engineered tower. One of the leading causes of wind generator failure is use on a poorly designed tower.

  • Page 16: Mounting Skystream To The Tower

    Though Skystream is thoroughly tested at the factory, it is very important to conduct one more test prior to erecting the tower. Skystream should be wired and mounted to the top of the tower.The blades should not be attached.To do this test, you must have all wires and breakers installed with at least one disconnect switch open (off).
  • Page 17 2-4 Blades, Nosecone and Antenna Assembly Refer to Fig. 8 (page 17) for visual aid. The Skystream blades may be bolted to the blade hub and mounted on Skystream as a complete assembly by performing the following steps. Remove the blade mounting hub and plate from Skystream by “unscrewing”...
  • Page 18 Fig. 9 Completed assembly Yaw Components Description Qty. RF Antenna M12x1.75x90mm Hex Bolt grade 10.9 Snubbing Washer 4, 5 Vibration Isolation Ring (4) and Bushing (5) Strain Relief Cover Assembly Shield M5x.8x12mm Button Head grade 8.8 M5 Lock Washer A2 stainless steel M5x.8x12mm Bolt SHCS grade 8.8 Flat Washer (M12) A2 stainless steel Lock Washer (M12) A2 stainless steel...

  • Page 19: Key Operating Characteristics

    Skystream will begin producing power in a wind of approximately 8 mph (3.5 m/sec). At that speed the blades will rotate at approxi- mately 120 rpm. As the wind speed increases the blade speed will also increase until at about 20 mph (9 m/sec) wind speed the blade speed achieves a rotational speed of 325 rpm.This is Skystreams rated speed.

  • Page 20: Frequently Asked Questions

    3) What should I do if I’m expecting a severe storm? The Skystream is designed for very high winds, but it is always a good idea to shut Skystream down if there is going to be a severe storm to protect against any flying debris.
  • Page 21 Appendix A Electrical Connection Diagram Options...

  • Page 22: Junction Box At Tower Base

    REFER TO SWWP Flagstaff, Arizona U.S.A. tolerances are : FOUDATION DWG. distances angles APPROVALS DATE Skystream home grid X. ± .5 ± 30 ' DRAWN N.Agrawal interconnect 1" DIA. SCHED. 40 18 Aug '06 .X ± .2 RIGID PVC CONDUIT;...

  • Page 23: Direct Run To Home

    REQUIRED) FOUDATION DWG. Flagstaff, Arizona U.S.A. USE COPPER WIRES ONLY AT TURBINE TERMINALS 1" DIA. SCHEDULE 40 Skystream home RIGID PVC CONDUIT; ALUMINUM WIRES MAY BE USED FOR HOME / UTILITY CONNECTION IF TRANSITION grid interconnect SUNLIGHT RESISTANT; WERE DONE IN A JNC. BOX. 14AWG WIRE MUST BE COPPER ONLY.
  • Page 24 Appendix B Foundation Installation Guidelines S O U T H W E S T W I N D P O W E R , I N C . - 1 8 0 1 W E S T R O U T E 6 6 - F L A G S T A F F , A R I Z O N A 8 6 0 0 1 - P H : 9 2 8 . 7 7 9 . 9 4 6 3 - F A X : 9 2 8 . 7 7 9 . 1 4 8 5 www.skystreamenergy.com ©...
  • Page 25 Skystream 3.7 Owner’s Manual Appendix B: Foundation Installation Guidelines Important Safety Instructions _______________________________ 1 1) INTRODUCTION __________________________________ 2 1-1 Founcation Bolt Kits ____________________________ 2 2) PIER FOUNDATION ______________________________ 2-4 2-1 Forming & Reinforcing Bar ______________________ 5 2-2 “J” Bolts & Template ____________________________ 5...

  • Page 26: Important Safety Instructions

    Failure to comply with the manual and local codes caution will affect and possibly void your warranty. Skystream uses high voltage and is potentially dangerous. Be sure to use all safety precautions at all times.

  • Page 27: Introduction

    This guideline provides directions for the construction of two tower foundations – the Pier and Mat foundations. Either foundation is suitable to mount the Southwest Windpower 33-foot monopole tower and Skystream 3.7 wind turbine. Please read and understand the entire installation guideline before proceeding. Local building codes and regulations shall have precedence over this installation guideline.
  • Page 28 8-1/2" 45° 17" 1-1/4" DIA HOLE 8X Fig. B1 Bolt template...
  • Page 29 2" 6" 2" TIP: Because special equipment is required to cut and GRADE bend the reinforcing bar it may be most economical to CIRCULAR TIES contract with a local concrete company to manufacture the reinforcement structure for the pier foundation. VERTICAL REINFORCEMENT 9"...

  • Page 30: Forming & Reinforcing Bar

    2-1 Forming and Reinforcing Bar Position reinforcing bar per F F i i g g . . B B 2 2 . Circular ties require a minimum 29 inch (73.6 cm) overlap and a minimum 3 inch (7.62 cm) clear- ance from outside diameter edge of pier.

  • Page 31: Pier Foundation

    17" bolt circle template 7"- 8" above foundation 2-3 Pier Foundation Specifications: D D i i a a m m e e t t e e r r 24 inches (61 cm) D D e e p p t t h h Depends on soil conditions 17"...

  • Page 32: Mat Foundation

    Three - MAT Foundation The MAT foundation is presented in F F i i g g . . B B 6 6 .The foundation is a 6 foot by 6 foot (1.8 m x 1.8 m) square with a depth of 3 feet (.9 m). The MAT foundation is designed for an allowable vertical bearing pressure of 1,500 PSF (IBC Class 5 Soil per Table 1804.2).

  • Page 33: Mat Foundation

    3-2 “J” Bolts and Template Note:Take the time to prepare an accurate and strong template to position and secure the J bolts.This will save much time and difficult rework. • Before pouring the foundation the “J” bolts M M U U S S T T be S S E E C C U U R R E E L L Y Y locked in position. •...

  • Page 34: Electrical Conduit

    Four - Electrical Conduit Electrical conduit may be cast into the foundation such that the conduit continues below grade to electrical panel. Alternately wire may be routed between tower base plate and foundation. Refer to local building codes B B E E F F O O R R E E pouring concrete. Building codes typically require direct burial cables be buried to a minimum depth of 24 inches (61 cm) while cables in conduit may be buried at a depth of 18 inches (46 cm).
  • Page 35 Appendix C Tower Installation Instructions Southwest Windpower, Inc. 1801 West Route 66 - Flagstaff, Arizona 86001 Phone: 928.779.9463 - Fax: 928.779.1485 Web: www.skystreamenergy.com © October 2006 Southwest Windpower, Inc. All Rights Reserved...
  • Page 36 Skystream 3.7 Owner’s Manual Appendix C: Skystream Tower Installation Instructions Important Safety Instructions _______________________________ 1 1) INTRODUCTION __________________________________ 2 1-1 Required Tools & Equipment ______________________ 2 2) SET UP & PREPARATION__________________________ 3-5 3) RAISING THE TOWER ____________________________ 6 4) LOWERING THE TOWER __________________________ 7...

  • Page 37: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ THESE INSTRUCTIONS IN THEIR ENTIRETY BEFORE INSTALLING. Professional installation highly recommended SAVE THESE INSTRUCTIONS. This manual contains important instructions for raising, lowering and leveling the tower that must be followed. In this guide Read these instructions in their entirety before beginning the installation. TIP: Helpful information Be extremely careful of overhead power lines.

  • Page 38: Introduction

    One - Introduction These instructions require use of Southwest Windpower’s Hinge and Gin Pole Kits, which were specifically designed for this application. Additionally, these instructions assume a bolt kit was purchased and the correct foundation nuts, bolts and washers are available. Once the tower is raised into position the hinge and gin pole are removed.

  • Page 39: Set Up & Preparation

    Two - Set Up & Preparation Carefully read and perform the following steps to prepare for raising the tower. TIP: Approximately 90 feet • Determine the three foundation bolts to be used to mount the hinge.The hinge (43 meters) are required to raise the tower vertically is installed in the direction the tower will be “tilted down”.
  • Page 40 • Tighten the hinge plate nuts such that the top of the hinge plate is 4 1/4” (10.8 cm) from the top of the foundation bolts. WARNING: The 4 1/4” height adjustment is VERY important to insure the foundation bolts will clear 4.25”...
  • Page 41 • Using an M16 nut and bolt install one of the gin pole cables on the lever arm of TIP: The tower is now set to be the gin pole. Using a shackle supplied with the gin pole secure the opposite end raised.

  • Page 42: Raising The Tower

    Three - Raising the Tower Refer to your Skystream Owner’s Manual for directions on mounting Skystream on the tower. If you have not raised a tower before it is also recommended to first raise the tower without the turbine. Raising the tower without the turbine provides the opportunity to prac- tice the procedure without risking damage to the turbine.

  • Page 43: Lowering The Tower

    Four - Lowering the Tower WARNING: Use extreme caution Lowering the tower is essentially the reverse of raising the tower.The same pre- when lowering the tower. Keep well cautions should be observed, including positioning the hinge so the tower base away and to sides of tower and cable.

  • Page 44: Leveling The Tower

    To level the tower: • Level the tower on a calm day to minimize movement of Skystream. Start by loosening all the upper foundation nuts about a full turn. • Loosen and lower the four nuts on the “sides” of the foundation base plate. In other words the tower should be supported by the four “corner”...

  • Page 45: Gin Pole Instruction Sheet

    Six - Gin Pole instruction Sheet 6-1 Package Contents Before you begin, inspect the contents to make sure there is no damage or missing parts. Gin Pole Kit (includes): - gin pole - two M16 nuts - two aircraft cables - three M24 (metric 24 mm) bolts - two shackle - three M24 nuts...
