Potential incorrect use and fault conditions

No signal on one or both channels:

No connection between headphone and headphone amplifier or amplifier. This could be due

to a faulty plug, broken wire or solder joint or simply loose plug/socket connection.

Headphone does not work:

Headphone volume control is at minimum.

Amplifier Tape-Monitor circuit is not activated.

Technical specifications Pro-Ject Head Box DS2 B

Power output:

Headphone connection:

Signal to noise:

Frequency response:

THD:

Gain for balanced input:

Gain for unbalanced input:

Headphone jack:

Line-level input:

Bypass output:

Trigger output/input:

Outboard power supply:

Power consumption:

Dimensions W x H x D with sockets:

Weight:

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,

please contact your dealer for further advice. Only when the problem cannot be resolved there should the

unit be sent to the responsible distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use. Modification or change to any part of the product by unauthorized persons, release the

manufacturer from any liability over and above the lawful rights of the customer.

Copyright, trademarks

Pro-Ject Audio Systems is a Registered Trademark of

H. Lichtenegger.

This guide was produced by: Pro-Ject Audio Systems

250mW/8ohms, 550mW/33ohms, 290mW/300ohms

>8ohms

98dB (A weighted) at full output

20Hz - 20kHz/- + 0,2dB

0,02%

6, 9, 15, 18 dB without load

0, 3, 9, 12 dB without load

Unbalanced: 3-pole ¼" (6,3mm ∅) co-axial jack

Balanced: 4pin XLR female

1 pair RCA/phono sockets, 1 pair XLR

12V (2,5mm jack)

18V/1A DC, suitable for your country's mains supply

<1W in standby

Aluminium 206 x 71 x 218mm

Wood 240 x 72 x 218mm

Aluminium1461g, Wood 1940g (without power supply)

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.
