- Page 1 TR300 Temperature and Relative Humidity Data Logger Users Manual • Mode d’emploi • Bedienungshandbuch • Manual d’Uso • Manual de uso • Användarhandbok...
-
Page 2: Temperature And Relative Humidity Data Logger
TR300 Temperature and Relative Humidity Data Logger Users Manual TR300_Rev001 © 2008 Amprobe Test Tools. All rights reserved. - Page 3 ➊ Sensor ➋ 2.5”x 2.0” LCD display ➌ Speaker ➍ Alarm LeD ➎ Record LeD ➏ Start/Stop to turn on and off the unit .8 °C ➐ Mode .5 % ➑ ➒ Y-M-D 08-02-13 Up scroll ➓ Down scroll 9V DC adaptor (>= 500mA. Depth:9mm inner: 1.35mm.
-
Page 4: Table Of Contents
TR300 Temperature and Relative Humidity Data Logger CoNTENTS introduction ............................5 Unpacking and inspection ........................5 operation ............................5 Setting Mode ..........................5 Sample point: ..........................6 Start Mode: ............................6 Start Time: ............................7 Sample Rate ...........................8 Alarm Set ............................9 Real Time ............................10 Switch from °f to °C........................10 Dew point measurement: Dp ......................10... -
Page 5: Introduction
INTRoDUCTIoN The TR300 Temperature and humidity logger is well suitable to monitor indoor air quality. it is designed with a wall-mounted hook in the back for easy installation. it has a very large LCD display, an audible and visible alarm, and a quick response sensor to help monitor easily the air temperature and humidity. -
Page 6: Sample Point
Sample point: • from ‘pts’ & ‘p1’, press SeT key • press up and Down pushbuttons to select the sample point from 1h(1000)…….16h(16000). The sample point will be divided in half: ½ for temperature and ½ for humidity. example: 16000 points= 8000 Temp + 8000 RH •... -
Page 7: Start Time
• Key Start: ‘hey’ is displayed on the bottom of the screen. in this mode, the meter will start recording when you press Start/Stop for more than 2 seconds. from ‘Stn’ & ‘p2’, press SeT key ■ ■ press Up or Down key to select ‘hey’ ■... -
Page 8: Sample Rate
Y-M-D Y-M-D Y-M-D H:M:S H:M:S H:M:S Sample Rate • press SeT key to enter sample rate mode • press Up or Down key to select ‘Sr & p4’ • press SeT to enter edit mode for HoUR ‘Hor’ • press Up or Down key to adjust the hour •... -
Page 9: Alarm Set
Alarm Set • press SeT key to enter the alarm setting • press Up or Down key to select ‘AL & p5’ • press set key to edit HigH temperature ‘tH’ • press Up or Down key to adjust the high temperature •... -
Page 10: Real Time
Real Time • press SeT to enter real time setting • press Up or Down key to select ‘rTC & p6” • press SeT to edit YeAR ‘yer’ • press Up or Down key to adjust the year • press SeT to edit MonTH ‘non’ •... -
Page 11: Rs232 Pc Interface Capabilities
Download Suite icon. Click on work “with instrument” and then “next” Select TR300 and click on “next” Select program device and click on nexT . Click on nexT again to open the programming screen (see figs 1&2) Setup the parameters and click oK to start recording To download file from the device, repeat steps 1 and 2. -
Page 12: Specifications
SPECIFICATIoNS Mode Range RH % 0.0 ~ 100.0% Resolution 0.1% Accuracy +/-3% @ 10~90%;+/-5% @ others Temperature -20°C to 70°C (-4°f to 158°f) Resolution 0.1°C (0.1°f) Accuracy ±0.6°C (±1°f) @ 0–50°C (32–122°f); ±1.2°C (±2°f) @ others Memory Up to 16K (Temp: 8K + RH: 8K) Real Time USb port... - Page 13 Supporting Figure Diagrams figure 1 figure 2...
- Page 14 figure 3 DISPLAY ALPHABET LIST Display Meaning Display Meaning figure 4...
