- Page 1 TR100-A / TR200-A Temperature / Humidity Data Loggers Users Manual • Mode d’emploi • Bedienungshandbuch • Manuale d’uso • Manual de uso • Användarhandbok...
-
Page 2: Temperature / Humidity Data Loggers
TR100-A / TR200-A Temperature / Humidity Data Loggers Users Manual TR100-A_200-A_Rev002 © 2009 Amprobe Test Tools. All rights reserved. - Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 TR100-A ➊ USb port ➋ Recording indicator LeD ➌ Alarm indicator LeD ➍ LCD display ➎ external temperature probe jack TR200-A...
-
Page 5: Table Of Contents
TR100-A / TR200-A Temperature / Humidity Data Loggers CoNTENTS introduction ............................5 Unpacking and inspection ........................5 features ...............................5 LeD indicators ............................5 ALM ..............................5 ReC ..............................6 LCD Display ............................6 battery Replacement ...........................6 Software operation ..........................8 Specifications ............................9 Troubleshooting ..........................9 error Codes ............................10... -
Page 6: Introduction
Congratulations on your purchase of this temperature or temperature/relative humidity data logger. please, read the manual completely before using the meter. Use the unique Amprobe Download Suite software to setup the meter to record, download the recorded data, and analyze the data. -
Page 7: Rec
Ext Com Rec Batt LCD DISpLAy ➊ Display Temperature reading (TR100-A) or Temperature and Humidity (TR200-A) ➋ Rec - ”Rec” is displayed during the logging process. when logger stops logging and in monitoring mode, ”ReC” will not appear on LCD. - Page 8 follow these steps to remove and replace battery: Unscrew the rear cover of data logger. Do not remove o-ring and make sure the o-ring is in its place (groove). Remove the expired battery. insert a new battery Cr2 battery with correct polarity. Re-screw the rear cover .
-
Page 9: Software Operation
SoFTWARE opERATIoN -insert the software CD into CD-RoM driver -install the USb driver first -install the software follow the on-screen instructions -open the program -Click the “Comm.Set” from main screen and input the right comm. port. -Click the “Logger Set” from main screen to program the logger Set date and time: Click oK to use the pC date and time non-Sleep, Sleep: Click oK to turn sleep mode on and off Unit: Click up and down arrows to select °f, °C, or %... -
Page 10: Specifications
12. Click to exit the program - Click the “START” from main screen to download the memory from logger SpECIFICATIoNS Description TR100-A TR200-A Temperature range -40 to 85°C(-40 to 185°f) Humidity range 0 to 100 %RH Accuracy: ± 0.6°C / 1°f (-20 to 50°C / -4 to 122°f), Temperature ±1.2°C / 1.2°f all others... -
Page 11: Error Codes
Cannot stop the downloading before completing all sample points Ans: Make sure the sample rate is greater than 1-sec ERRoR CoDES Error Code Description probe is disconnected Value under the lower limit Value over the upper limit Value fails because of the relative original data error. RH Calibration error The humidity sensor accuracy cannot be calibrated by the end user due to special equipment requirements.
