- Page 1 Toucan Surveillance Kit Camera & Smart Socket USER’S MANUAL Model: TSK100KU Toucan user manual24_wo.indd 1 31/3/2016 10:30 AM...
-
Page 2: Table Of Contents
Table of Contents Key Features What is Included Positioning Toucan Installation Status LED Indicators Specifications Troubleshooting & FAQ Regulations & Compliance Toucan user manual24_wo.indd 1 31/3/2016 10:30 AM... -
Page 3: Key Features
Wide Angle Adjustable Lens · Clear HD LIVE video feed and event recording capture Weatherproof Design · Withstands rain, snow, Passive Infrared Sensor humidity, and house · Detects change in motion maintenance year-round Toucan user manual24_wo.indd 2 31/3/2016 10:30 AM... - Page 4 • Provides power to camera Remote Light Control · Turn on and off the lights Schedule dusk-to-dawn • Timer feature to schedule light to turn on at dust and off at dawn through cloud system Toucan user manual24_wo.indd 3 31/3/2016 10:30 AM...
- Page 5 · Turn ON/OFF the lights Play Message · Pre-recorded messages Hold to talk · 2-way communication LIVE Camera Camera setting View Recorded Videos App and Contact Info *User interface is subject to change without prior notice. Toucan user manual24_wo.indd 4 31/3/2016 10:30 AM...
-
Page 6: What Is Included
2. What is Included Before installing Toucan, make sure all parts are present. If any part is missing, please contact VuPoint Solutions at support@vupointsolutions.com. Mount Camera on Mount Plate Toucan Camera Smart Socket Mount Plate Cover Conduit Cover · Mount camera under ·... -
Page 7: Cable Management
Mount of Wall Mount Screws (2pcs) Washers (2pcs) Wall Inserts (2pcs) Hexagonal Wrench · Wall mount purpose · Wall mount purpose · Wall mount purpose · Lock and unlock the camera on mount plate Toucan user manual24_wo.indd 6 31/3/2016 10:30 AM... - Page 8 Toucan Surveillance Kit Camera & Smart Socket USER’S MANUAL Model: TSK100KU Power Sticker Secure Stickers (3pcs) User’s Manual Warranty Card · Stick on main power · Alert intruder that home switch is secured by Toucan Toucan user manual24_wo.indd 7 31/3/2016 10:30 AM...
-
Page 9: Positioning
5” beneath the lamp base against the wall, please install the conduit to manage the cables. *Placement recommendations may vary based on different light fixture’s designs, style, and size. Toucan user manual24_wo.indd 8 31/3/2016 10:30 AM... -
Page 10: Toucan Installation
Screw lamp shade back in and Attach USB Cable to Reattach lamp drag out USB cable through the Smart Socket. shade if necessary. shade then adjust Silicon Pipe from USB cable to protect cable. Toucan user manual24_wo.indd 9 31/3/2016 10:30 AM... - Page 11 Positioning Sticker to mark the camera to the wall. the center of the plate. Toucan user manual24_wo.indd 10 31/3/2016 10:30 AM...
- Page 12 After using the Leveler to adjust the balance Drill holes for screws placement. of the plate, you can use a pencil to mark the placement for the screws. Install Wall Inserts. Mount back plate with Washers and Screws. Toucan user manual24_wo.indd 11 31/3/2016 10:30 AM...
- Page 13 Position camera and use Attach Visor to the top of the Tighten the security screw with Cable Clips to manage the hexagonal wrench. Do not camera lens. cable if necessary. over-tighten the security screw. Toucan user manual24_wo.indd 12 31/3/2016 10:30 AM...
-
Page 14: Status Led Indicators
5. Status LED Indicators In order to set up your Toucan, please make sure it’s successfully installed, and the status LED on the bottom left side of your Toucan camera is flashing red. This means that your Toucan is ready to be set up! -
Page 15: Specifications
DC5V, 1A Input AC120V, 60Hz Lighting Control On/Off/Scheduling through BLE Mesh Network Bluetooth® Bluetooth® BLE 4.0 Light bulb Support maximum 75W standard bulb; recommended 10W LED light bulb; not included Dimensions 2”(Dia.) x 3” Toucan user manual24_wo.indd 14 31/3/2016 10:30 AM... -
Page 16: Troubleshooting & Faq
Toucan, or adding a Range Extender in between. Note: If you need to change the router or ownership of your Toucan, please contact Kuna Customer Service to reset the Toucan. Toucan user manual24_wo.indd 15... -
Page 17: Regulations & Compliance
Use only the USB cable packaged with the product from Toucan. The Smart Socket and USB cable may become warm during normal use. Always allow adequate ventilation around the smart socket and USB cable and use care when handing. - Page 18 RF Exposure Statement To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. Toucan user manual24_wo.indd 17 31/3/2016 10:30 AM...
- Page 19 Corporation, Bluetooth® word mark and logo are registered trademarks owned by Bluetooth SIG, Inc. All trademarks are the property of their respective owner. Camera FCC ID: 2ABT4TC100KU Socket FCC ID: 2ABT4TS100WU U.S. Patent Pending TSK100KU_Manual_16-0226 Toucan user manual24_wo.indd 18 31/3/2016 10:30 AM...
