- Page 1 7116 Duo BURG-WÄCHTER KG Altenhofer Weg 15 58300 Wetter Germany www.burg.biz www.burg.biz...
- Page 2 7116 Duo User and assembly manual Assembly and user manuals Instruction de montage et mode d’emploi Montage- en gebruiksaanwijzing www.burg.biz...
- Page 3 Download: www.burg.biz Download: www.burg.biz Download: www.burg.biz Download: www.burg.biz Ladattava tiedosto: www.burg.biz λήψη: www.burg.biz İndir: www.burg.biz Descărcare: www.burg.biz Pobieranie pliku: www.burg.biz Stáhnout: www.burg.biz Letölthető: www.burg.biz Download: www.burg.biz Download: www.burg.biz загрузка: www.burg.biz Download (зареди): www.burg.biz 2 | English secuENTRY pro 7116 Duo...
- Page 4 Please read the operating instructions carefully before starting the assembly and programming. Keep in a safe place. We hope you enjoy your new locking system. The secuENTRY pro 7116 Duo cylinder can be used with the following opening media: • Keyboard PINCODE •...
- Page 5 The manufacturer assumes no liability for any injuries or damage that may occur during installation or through improper handling. Assembly The installation of the secuENTRY pro 7116 Duo cylinder is described below. Please read this Assembly Manual carefully prior to the assembly. Remarks: The base size of the cylinder is 30 mm per side.
- Page 6 7116 Duo...
- Page 7 –: not provided 54 – 60 Tab. 1: Space detent bolt/mounting [mm] on the outer side and the required adapter. 2.9 × 16 Adapter 2 M2 × 10 Adapter 1 Systematic illustration of adapter fixing secuENTRY pro 7116 Duo English | 5...
- Page 8 4 Move the secuENTRY pro 7116 Duo cylinder from inside to outside through the mortise lock into the door and then tighten the detent bolt. 5 Shift the inner knob over the shaft until attaining the required dimension. Please make sure that the clearance between the rotary knob and the door mounting is at least 1mm.
- Page 9 M4x25 M4x30 M4x35 M4x40 M4x45 L = 7 L = 11 L = 16 L = 21 L = 26 L = 31 L = 36 Adapter ( L = length in mm) secuENTRY pro 7116 Duo English | 7...
- Page 10 Dimensions secuENTRY pro 7116 Duo Diameter 34 Outer side 1-29 1-31 Inner side Diameter 30 Dimensions in mm 8 | English secuENTRY pro 7116 Duo...
- Page 11 Registration via the secuENTRY software Please refer to the operating instructions of the respective software. Attention! For the registration of the secuENTRY pro 7116 Duo profile cylinder, please use only the QR code of the internal knob in the PC software. This is provided with the administrator code. It is not necessary to register the external connector in the PC software.
- Page 12 Opening The secuENTRY pro 7116 Duo can be operated with fingerprint, the passive transponder or the active transponder, depending on the equipment variant, using a 6-digit number code, the BURG-WÄCHTER KeyApp. Opening with Pincode • Activate the keypad using the key •...
- Page 13 Maximum Transmit Output Power 7.5dBm Frequency usage range 2,402GHz ... 2.483GHz Additional functions available using the optional secuENTRY Software, for example: • Setup User • Timer and calendar functions • Assignment of authorisations secuENTRY pro 7116 Duo English | 11...
- Page 14 • Using the attached hex key, loosen the top locking screw on the cylinder cover. It can be turned out only up to the opening of the cover and will not fall out. • Open the cover. 12 | English secuENTRY pro 7116 Duo...
- Page 15 • Replace the battery with the correct polarity. • Carefully push the knob again. Please note: Latching is only possible in one position! Attention! Be careful not to nip the cable. Make sure that the O-ring is correctly placed. secuENTRY pro 7116 Duo English | 13...
-
Page 16: Warranty
In the case of returns due to your right of withdrawal all parts of the device must be in the factory setting and the seals on the cylinder and the knob must be undamaged. If these conditions are not met, the warranty expires. 14 | English secuENTRY pro 7116 Duo... - Page 17 This can lead to interference, which causes errors or interrupts communication. In such cases devices that are not required should be de-energized. Print and typesetting errors as well as technical changes reserved. BW_pro 7116 Zylinder_BA_sE_020100 HBG/SDS 07/2017 secuENTRY pro 7116 Duo English | 15...
