Platecam SV-5130.IR Installation Instructions

Bar-type license plate camera

The SV-5130.IR is a bar-type license plate camera with a viewing angle of 120° and IR night

vision. The camera lens can be vertically adjusted to give the driver a better viewing angle. The

Camera is easy to install with no drilling required, requiring minimal installation time. This

uniquely designed product can be used for any passenger car, SUV and Van. It can also be

used on many large Semi Trucks, School Buses, and Transit Buses

FEATURES:

• Revolutionary design integrates a Color rear vision camera with your rear license plate

• Enhance the look of your Car, SUV, Truck or Van.

• The 120° angle CMOS color camera provides rear images in real time and eliminates the

dangerous "blind-spot" directly behind your vehicle when backing.

• Infra-red LED for night vision

• Reverse Image

• Parking assist lines to help the driver accurately judge distance behind the vehicle

• The plate cam easily connects with other SecurView monitor or aftermarket monitor that

uses an RCA input

• The PlateCam™ is designed for vehicles in which the license plate location is centered

and above the level of the rear bumper. The PlateCam™ may not perform well on

vehicles with low or offset license plate positions.

Installation INSTRUCTIONS:

Table of Contents

Do you have a question about the SV-5130.IR and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS: The SV-5130.IR is a bar-type license plate camera with a viewing angle of 120° and IR night vision. The camera lens can be vertically adjusted to give the driver a better viewing angle. The camera is easy to install with no drilling required, requiring minimal installation time. This uniquely designed product can be used for any passenger car, SUV and Van.
Page 2 INSTALLATION MOUNTING: 1. The SV-5130.IR Rear Vision System uses a super wide-angle lens for best all around performance. The Camera will display the full width of most parking spaces up to 8 feet or even wider. 2. These cameras are designed to work best on vehicles that have a license plate located at the center and above the rear bumper.
Page 3 RED WIRE Reverse Light MONITOR BLACK WIRE Chassis Ground YELLOW Connect to Monitor SV-5130.IR POWER CONNECTOR SPECIFICATIONS: 1/4 Inch Color CMOS Sensor Video Output: 1.0 V P-P composite (75 Ohm load) Dimension (MM): 1⅝"(L) × 9⅞"(W) × 1¼"(D) Supply Voltage: +12VDC Weight: 12 Oz.
Page 4 PlateCam™ Rear Vision System. The PlateCam™ is designed as a safety enhancement device and is in no way intended as a replacement for rear-view mirrors, side-view mirrors or physically checking the surroundings when backing a vehicle.
