JL Audio MicroSub+ Owner's Manual page 5

Model
ACP108LG-W3v3 (1) 8W3v3-0.40
ACP208LG-W3v3 (2) 8W3v3-0.40
ACP110LG-TW1 (1) 10TW1-0.25
ACP112LG-TW1 (1) 12TW1-0.25
ACS110LG-TW1 (1) 10TW1-0.25
ACS112LG-TW1 (1) 12TW1-0.25
Input Filter Type, Range,
Voltage Range
70 mV – 1.40 V (Low)
or
280 mV – 5.4 V (High)
Warning - Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products.
Doing so will void the warranty and may cause severe damage/injury.
MicroSub+ / PowerWedge+ with DCD™ Amplifier Technology
Enclosure Specifications
Nominal
Driver(s)
Impedance
0.40 Ω
0.20 Ω
0.25 Ω
0.25 Ω
0.25 Ω
0.25 Ω
DCD™ Amplifier Specifications (All Models)
Output
Slope Polarity
Low-Pass,
0 or 180
50 – 200 Hz,
degrees
12 dB/Octave
RMS Power
@ 14.4V, Dimensions
<1% THD+N
18.5 in x 11.125 in x 5.125 in
250 W
470 mm x 283 mm x 130 mm
36.625 in x 11.125 in x 5.125 in
500 W
905 mm x 283 mm x 130 mm
21 in x 13.5 in x 6.625 in
400 W
533 mm x 343 mm x 168 mm
23.75 in x 15.75 in x 9.25 in
400 W
603 mm x 400 mm x 235 mm
18.5 in x 11.125 in x 5 in
400 W
470 mm x 283 mm x 127 mm
21 in x 13.5 in x 6.625 in
400 W
533 mm x 343 mm x 168 mm
Remote Bass
Power/GND Wire
Controller
RBC-1 (sold 8 AWG
separately) (recommended)
Fuse
Rating
30A
5
