- Page 1 CHRONOGRAPH WATCHES...
- Page 2 SETTINGS...
- Page 3 SCREWED-DOWN POSITION [position A] Your TUDOR watch is equipped with a screw-down crown. Once this is fully screwed down against the case, your watch is guaranteed waterproof. MANUAL WINDING [position B] A watch equipped with a self-winding mechanical movement is wound automatically by wrist movements alone.
- Page 4 RAPID DATE-SETTING [position C] In order to adjust the date, unscrew the crown and pull it out to the second notch. Then turn it clockwise for MT calibres or anticlockwise for other calibres (see the calibres listed at the end of this document), until the desired date appears in the window.
- Page 5 TIME-SETTING [position D] In order to adjst the time, unscrew the crown and pull it out to the last notch. Then turn it in either direction until the hands indicate the correct time. The small seconds hand is stopped during this operation, allowing the time to be set accurately.
- Page 6 DATE-SETTING FOR FASTRIDER [at 9 o’clock] In order to adjust the date, we advise you to use only the TUDOR tool as depicted in the diagram on the following page. It is supplied with your watch, and serves to handle the date corrector situated at 9 o’clock.
- Page 8 CHRONOGRAPH FUNCTION...
- Page 9 The chronograph function enables you to measure times to fractions of a second, thanks to the centre seconds hand. On some models, to be enabled for use, the pushers must be unscrewed; lock the pushers after use. To measure longer intervals, a chronograph with two counters has an additional 45-minute counter.
- Page 10 PUSHER AT 2 O’CLOCK start/stop Pressing the start/stop pusher a first time will start the chronograph. Pressing it again will stop the chronograph. Pressing a third time will start it again. In this way you can measure several times in succession.
- Page 11 PUSHER AT 4 O’CLOCK reset Resetting is only possible when the chronograph has stopped. To reset the chronograph counters, press the reset pusher; the chronograph will be ready for use again.
-
Page 12: Tachymeter Function
TACHYMETER FUNCTION... - Page 13 The bezel on your watch has a tachymeter function used to measure a speed or a flow rate using the chronograph function. Select the desired unit of measurement (metre, kilometre, mile, litre, etc.], activate the chronograph and stop it when the desired unit is reached.
- Page 14 SECOND TIME-ZONE FUNCTION [12-hour graduated rotatable bezel] The second time-zone function is used to display two time zones simultaneously. The time of the second time zone is read by means of the hour hand, the minute hand and the bidirectional rotatable bezel.
- Page 15 When you move westward, for example from Geneva to Mexico, turn the bezel clockwise, then turn it anticlockwise when you move eastward, for example from Geneva to Tokyo. The triangle engraved on the bezel serves as a benchmark; in neutral position, it stands at 12 o’clock.
- Page 16 RECOMMENDATIONS Bronze: Your Black Bay Bronze is designed in bronze, in this case a high-performance aluminium bronze alloy, which guarantees the development of a subtle and unique patina to match its user’s habits. Cleaning: Use a microfibre cloth and wash the metal, rubber, fabric bracelets and waterproof cases from time to time with a soft brush and soapy water.
- Page 17 Guarantee: Refer to the guarantee manual supplied with your watch. Leather: To preserve your leather strap, we recommend protecting it from water and moisture. PVD: Your Black Bay Dark is finished with a black coating obtained using a Physical Vapour Deposition (PVD) process.
- Page 18 Salt water: Always rinse your watch with fresh water. Screw-down winding crown: After each operation, remember to push the crown back in and screw it back down carefully against the case, in order to preserve your watch’s waterproofness.
- Page 19 Expert TUDOR servicing can be carried out via any of the Official Retailers and Service Centres in the extensive ROLEX or TUDOR service network. Visit TUDORWATCH.COM to view the list of Official TUDOR Retailers and Service Centres in your area.
- Page 20 REFERENCE MODEL 42000CN/CR FASTRIDER BLACK SHIELD 70330B/N HERITAGE CHRONO & CHRONO BLUE 79350 HERITAGE BLACK BAY CHRONO...
- Page 21 CALIBRE POWER RESERVE WATERPROOFNESS 7753 46 h 150 m 2892 42 h 150 m MT5813 70 h 200 m...
- Page 22 Montres TUDOR SA reserves the right to modify the © Montres TUDOR SA models illustrated in this publication at any time. Rue François-Dussaud 3-5-7 1211 Geneva 26, Switzerland TUDORWATCH.COM 587.52 EN – 6.2017...
- Page 23 VISIT TUDORWATCH.COM AND EXPLORE MORE...
