FireWire 800 1-port ExpressCard/34
Quick Installation Guide
Introducing the FireWire 800 1-port
ExpressCard/34
The FireWire 800 1-port ExpressCard/34 adds FireWire 800
(1394b) interface to your ExpressCard equipped
computer.

Features and Benefits

Provides 1 FireWire 800 (9-pin) & supports up to 63
devices
Supports data transfer rates of 100, 200, 400 and
800Mbps
Supports hot-swapping and Plug-n-Play connection
of peripheral devices
Works with FireWire devices including DV
camcorders, CD-RW/DVD-ROM drives, portable
hard disks, digital cameras and other audio/video
devices

System Requirements

ExpressCard-enabled notebook with an available
ExpressCard slot
Windows 2000/XP/Server 2003
04-0427A
1
