Control system for dough-retardes
Hide thumbs

Advertisement

Quick Links

Download this manual
PLUS 100 PAN
CONTROL SYSTEM FOR DOUGH-RETARDES
Use and maintenance manual
READ AND KEEP
REV. 01-16
ELECTRICAL BOARDS FOR REFRIGERATING INSTALLATIONS
ENG

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLUS 100 PAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pego PLUS 100 PAN

Summary of Contents for Pego PLUS 100 PAN

  • Page 1 PLUS 100 PAN CONTROL SYSTEM FOR DOUGH-RETARDES Use and maintenance manual READ AND KEEP REV. 01-16 ELECTRICAL BOARDS FOR REFRIGERATING INSTALLATIONS...
  • Page 2 PLUS 100 PAN...
  • Page 3 CHAP. 2 Page 6 Important information for installer Page 6 Standard assembly and use kit FUNCTIONS CHAP. 3 Page 7 Functions managed by the PLUS 100 PAN TECHNICAL CHARACTERISTICS CHAP. 4 Page 8 Technical characteristics Page 9 Warranty terms PARAMETER PROGRAMMING CHAP.

  • Page 4: General

    100 MASTER unit, on which all the electrical connections are made, and the PLUS 100 PAN control panel, which features a large LCD display to provide rapidly available, complete information on room status. The system allows the user to cool, heat and ventilate the room, switch the room light on/off, humidify it, effect an air changeover, dehumidify it, defrost it and control alarms.
  • Page 5 CHAP. 1 - Introduction PLUS 100 PAN OVERALL DIMENSIONS IDENTIFICATION DATA The unit described in this manual has, on its side, an ID plate showing all the relevant identification data: • Name of Manufacturer • Code and model of electrical board •...
  • Page 6 7. When it is necessary to make a probe/sensor extension, the wires must be of the correct cross-section, which in any case must be at least 1 mm STANDARD ASSEMBLY AND USE KIT The PLUS 100 PAN system is supplied with the following assembly and utilisation items: n°2 temperature sensors n°1 fixing bracket n°1 telephone plug lead...
  • Page 7 CHAP. 3 - Functions PLUS 100 PAN CHAPTER 3: FUNCTIONS FUNCTIONS CONTROLLED BY THE PLUS 100 PAN - Display and adjustment of temperature and humidity settings (neutral zone). - Activation/deactivation of stand-by mode. - Sensor alarm/warning signals. - Adjustment of differential temperature and humidity parameters.

  • Page 8: Technical Characteristics

    CHAP. 4 – Technical characteristics PLUS 100 PAN CHAPTER 4: TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS Power supply 230 V~  10% 50 Hz Voltage MAX power absorption ~ 8 VA Climatic conditions Working temperature -10 - 60°C Storage temperature -30 - 70°C...
  • Page 9  Damages caused by natural phenomena as lightning, natural calamities, etc. Warranty cover may be refused if the device is modified or changed. Under no circumstances Pego S.r.l. will be responsible for possible loss of data and information, costs of substitutive goods or services, damages to things, people or animals,...

  • Page 10: Control Panel

    CHAP. 5 - Parameter programming PLUS 100 PAN CHAPTER 5: PARAMETER PROGRAMMING CONTROL PANEL 1. LCD display. 2. Automatic cycle progress bar. 3. Cycle START/STOP (hold for a few seconds to start or stop an automatic cycle) / Timer (press once to show day and time of end of cycle in progress).
  • Page 11 CHAP. 5 - Parameter programming PLUS 100 PAN LCD DISPLAY 1. Progress of PHASE 1 (cooling duration set by final user, physically occupies sectors n° 1, 2, 3, 4, 5). 2. Progress of PHASE 2 (maintenance, so-called elastic phase, physically occupies sectors n°...
  • Page 12 17. Time / date / time parameter values. GENERAL To enhance safety and simplify the operator’s work, the PLUS 100 PAN system has two programming levels; the first level (Level 1) is used to configure the frequently-modified SET-POINT parameters. The second programming level (Level 2) is for general parameter programming of the various controller work modes.

  • Page 13: Page

    CHAP. 5 - Parameter programming PLUS 100 PAN LEVEL 1 PROGRAMMING (User level) To gain access to the Level 1 configuration menu proceed as follows: 1. Press the () and () keys simultaneously and keep them pressed for a few seconds until the first programming variable appears on the display.
  • Page 14 CHAP. 5 - Parameter programming PLUS 100 PAN LIST OF LEVEL 1 VARIABLES (User level) LABEL MEANING RANGE DEFAULT Temperature difference compared to main 1÷10 °C 2°C SET-POINT Differential for Humidification compared to 1÷10 rH% 5 rH% main SET-POINT Differential for Dehumidification compared to 1÷10 rH%...

  • Page 15: Page

    CHAP. 5 - Parameter programming PLUS 100 PAN LEVEL 2 PROGRAMMING (Installer level) To access the second programming level press the UP () and DOWN () keys and the LIGHT key simultaneously for a few seconds. When the first programming variable appears the system automatically goes to stand-by.
  • Page 16 CHAP. 5 - Parameter programming PLUS 100 PAN LIST OF LEVEL 2 VARIABLES (Installer level) LABEL MEANING RANGE DEFAULT 0= NO Door switch input status 1= NC Minimum time between compressor shutdown and 0...15 min 0 min subsequent switching on Network address for connection 031...
  • Page 17 CHAP. 5 - Parameter programming PLUS 100 PAN Third leavening step duration 00:00…2:00 hh:mm 00:30 hh:mm Fourth leavening step 0…+45 °C 16 °C temperature set-point 50…99 rH% Fourth leavening step humidity (50%= humidity not 80 rH% set-point controlled) Fourth leavening step duration 00:00…2:00 hh:mm...
  • Page 18 CHAP. 6 - Using the unit PLUS 100 PAN CHAPTER 6: USING THE UNIT COLD/HEAT: MAINTAINING AMBIENT TEMPERATURE Heating/cooling is neutral-zone controlled on the basis of the temperature set-point (key 6 ) and the temperature differential (parameter d-t). Cooling is activated when the set + differential threshold is passed and stays on until the set-point is reached.
  • Page 19 CHAP. 6 - Using the unit PLUS 100 PAN greater value shuts down to prevent any overheating or over-cooling which could damage the product. 3. Separated dehumidification (dehumidification output activated only but without cold/heat call). (*) if the humidity set point is set to the minimum (50%) neither dehumidification nor...
  • Page 20 PLUS 100 PAN MANUAL CYCLES The controller recognises the manual cycles (only hot or only cold) from the temperature setting only when in stop mode, not in stand-by. If the set-point is less than or equal to 10°C the controller recognises the manual cold cycle.

  • Page 21: Page

    CHAP. 6 - Using the unit PLUS 100 PAN AUTOMATIC CYCLES It is possible to set four automatic pause-leavening cycles each with fully independent automatic programmed leavening, and a maintenance-only cycle (riC 0) with cooling start. The four cycles have the following characteristics: cycle n°1 is carried out the same day (12 hrs);...
  • Page 22 CHAP. 6 - Using the unit PLUS 100 PAN CYCLE PROGRAMMING DATA: DISPLAY Default Default DISPLAY RH% DISPLAY TIME TEMP. recipe 1 recipe 2 Cooling temperature -20°C…..0°C. Cooling time 04:00:00 05:00:00 00:00:00….29:59:00 Maintenance temperature -5°C…..15°C. Hr% Maintenance 50%….99.0% Final leavening temp.
  • Page 23 PLUS 100 PAN indicate erroneous programming. To switch off the buzzer press key 7 . The progress of the cycle is highlighted at the top of the unit as follows: Phase 1: cooling n° 5 segments; Phase 2 maintenance n° 5 segments;...
  • Page 24 PLUS 100 PAN The cooling phase is characterised by:  Temperature set-point  Duration of the phase The maintenance phase is characterised by:  Temperature set-point  Humidity set-point The leavening phase is characterised by:  Temperature set-point  Humidity set-point ...
  • Page 25 TWMT (temperature acquisition module). In this way the TeleNET supervision program can simultaneously display temperature and relative humidity as measured by the PLUS 100 PAN and build up a record of both parameters. Example: if parameter Ad is set to 3, relative humidity can be displayed on the TeleNET by assigning the TWMUR module to address 3;...

  • Page 26: Alarms: Description And Procedures

    CHAPTER 7: TROUBLESHOOTING ALARMS: DESCRIPTION AND PROCEDURES In the event of any anomalies the PLUS 100 PAN system warns the operator by displaying alarm codes and sounding the warning buzzer inside the control panel. If an alarm is tripped the display will show one of the following messages:...
  • Page 27 Connection between Control Panel and display reads En Control Board interrupted for continuity.  Check all connections.  Check Control The PLUS 100 PAN Board connection system generates false Sensor(s) connected incorrectly or faulty leads for continuity.  If the problem alarms...
  • Page 28 CHAP. 7 - Troubleshooting PLUS 100 PAN  Check the The PLUS 100 PAN Connection of PLUS 100 PAN system to connection to the system does not the TeleNET module network has not TeleNET network. dialogue with the  Check attributed...
  • Page 29 PLUS 100 PAN APPENDICES CE DECLARATION OF CONFORMITY COSTRUTTORE / MANUFACTURER PEGO S.r.l. Via Piacentina, 6/b 45030 Occhiobello (RO) – Italy – Tel. (+39) 0425 762906 Fax. (+39) 0425 762905 DENOMINAZIONE DEL PRODOTTO / NAME OF THE PRODUCT MOD.: PLUS 100 PAN IL PRODOTTO E’...
  • Page 30 Appendices PLUS 100 PAN PLUS100 PAN CONNECTIONS DIAGRAM Power section Outputs section (free-voltage contacts) 1-2 Power supply 230VAC 50/60 Hz 21-22 Alarm 23-24 Defrost Analogic inputs section 25-26 Dehumidification / air changeover 29-30 Evaporator sensor NTC 15-16 Stand-by 31-32 Humidity sensor 4-20 mA (0-...
  • Page 31 PLUS 100 PAN NOTES USE AND MAINTENANCE MANUAL Pag. 31 Rev. 01-16...
  • Page 32 PLUS 100 PAN PEGO S.r.l. Dealer: Via Piacentina, 6/b 45030 OCCHIOBELLO –ROVIGO- Tel: 0425 762906 Fax: 0425 762905 www.pego.it USE AND MAINTENANCE MANUAL Pag. 32 Rev. 01-16 e-mail: info@pego.it...
