Page 1 2017 G R A N D C A R A V A N USER GUIDE...
Page 2 I M P O R T A N T This Us er Guid e is intended to familiari ze yo u with the im portan t fea tu res of yo ur vehicle. Your Owner’s Manual , N avi gation/Uco nnec t Ma n ua ls , an d Warranty Booklets can be fo und o n your D VD (if applic able) o r b y vis itin g th e w ebsit e on t he back c o ve r of your Us er Guide.
Page 3: Table Of Contents
T A B L E O F C O N T E N T S INTRODUCTION/WELCOME UTILITY TRAILER TOWING WEIGHTS (MAXIMUM WELCOME FROM FCA US LLC ..2 TRAILER WEIGHT RATINGS) ..112 CONTROLS AT A GLANCE RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) .
Page 4: Welcome From Fca Us Llc
Owner's Manual www.dodge.com/en/owners/manuals. FCA US is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on...
Page 5 I N T R O D U C T I O N / W E L C O M E VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc.
Page 6: Controls At A Glance Driver Cockpit
C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Headlight Switch pg. 68 2. Instrument Cluster Display Controls — If Equipped pg. 106 3. Turn Signal/Wiper/Washer/High Beams Lever (Behind Steering Wheel) pg. 65 4.
Page 7 C O N T R O L S A T A G L A N C E 11. Glove Compartment 12. Feature Switch Panel 13. DVD Player 14. Tilt/Telescoping Steering Column pg. 63 15. Hood Release pg. 149 16. Emergency Brake Pedal 17.
Page 8: Instrument Cluster
C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Tachometer 2. Temperature Gauge 3. Instrument Cluster Display — If Equipped (See page 114 for more Instrument Cluster Warning Light information.)
Page 9 C O N T R O L S A T A G L A N C E 4. Speedometer 5. Fuel Gauge 6. Fuel Filler Door Location (See page 119 for more Instrument Cluster Indicator Light information.)
Page 10: Getting Started Key Fob
G E T T I N G S T A R T E D KEY FOB Locking And Unlocking The Doors And Liftgate Lock The Doors And Liftgate Push and release the lock button on the key fob to lock all doors and liftgate. The turn signal lights will flash, and the horn will chirp to acknowledge the signal.
Page 11 G E T T I N G S T A R T E D Power Liftgate Push the liftgate button twice within five seconds to power open/close the Power Liftgate. If the button is pushed twice while the liftgate is being power closed, the liftgate will reverse to the full open position.
Page 12: Remote Start — If Equipped
G E T T I N G S T A R T E D REMOTE START — IF EQUIPPED Push the remote start button on the key fob twice within five seconds. Pushing the remote start button a third time shuts the engine off. To drive the vehicle, push the Keyless Enter-N-Go START/STOP button to place the ignition in the ON/RUN mode.
Page 13: Occupant Restraint Systems
G E T T I N G S T A R T E D To Disarm The System Push the key fob unlock button or cycle the ignition to the ON/RUN position. The vehicle security alarm is designed to protect your vehicle. However, you can create conditions where the vehicle security alarm will give you a false alarm.
Page 14 G E T T I N G S T A R T E D 4. Never allow children to slide the shoulder belt behind them or under their arm. 5. You should read the instructions provided with your child restraint to make sure that you are using it properly.
Page 15 G E T T I N G S T A R T E D Initial Indication If the driver is unbuckled when the ignition switch is first in the START or ON/RUN position, a chime will signal for a few seconds. If the driver or outboard front seat passenger (if equipped with outboard front passenger seat BeltAlert) is unbuckled when the ignition switch is first in the START or ON/RUN position the Seat Belt Reminder Light will turn on and remain on until both outboard front seat belts are buckled.
Page 16 G E T T I N G S T A R T E D Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. The seat belt webbing retractor will lock only during very sudden stops or collisions. This feature allows the shoulder part of the seat belt to move freely with you under normal conditions.
Page 17 G E T T I N G S T A R T E D WARNING! • A seat belt that is too loose will not protect you properly. In a sudden stop, you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly. •...
Page 18 G E T T I N G S T A R T E D Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2.
Page 19 G E T T I N G S T A R T E D Second Row Center (If Equipped) and Third Row Center Seat Belt Operating In- structions The second row center (if equipped) and third row center seat belts features a seat belt with a mini-latch plate and buckle, which allows the seat belt to detach from the lower anchor when the seat is folded.
Page 20 G E T T I N G S T A R T E D 3. Route the shoulder belt to the inside of the left head restraint. Mini-Latch And Buckle Connected 4. When the seat belt is long enough to fit, insert the mini-latch plate into the mini-buckle until you hear a “click.”...
Page 21 G E T T I N G S T A R T E D 5. Sit back in seat. Slide the regular latch plate up the webbing as far as necessary to allow the seat belt to go around your lap. Rear Center Seat Belt Buckled 6.
Page 22 G E T T I N G S T A R T E D 10. To disengage the mini-latch plate from the mini-buckle for storage, insert the regular latch plate into the center red slot on the mini-buckle. The seat belt will automatically retract to its stowed position.
Page 23 G E T T I N G S T A R T E D Seat Belts And Pregnant Women Seat belts must be worn by all occupants including pregnant women: the risk of in- jury in the event of an accident is reduced for the mother and the unborn child if they are wearing a seat belt.
Page 24 G E T T I N G S T A R T E D Switchable Automatic Locking Retractors (ALR) The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) which is used to secure a child restraint system. For additional information, refer to “Installing Child Restraints Using The Vehicle Seat Belt”...
Page 25 G E T T I N G S T A R T E D How To Engage The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire seat belt is extracted. 3.
Page 26 G E T T I N G S T A R T E D Active Head Restraint (AHR) Components: Active Head Restraint (AHR) Components 1 — Head Restraint Front Half (Soft Foam And Trim) 2 — Seatback 3 — Head Restraint Back Half (Decora- tive Plastic Rear Cover) 4 —...
Page 27 G E T T I N G S T A R T E D Resetting Active Head Restraints (AHR) If the Active Head Restraints are triggered during a collision, the front half of the head restraint will be extended forward and separated from the rear half of the head restraint (see image).
Page 28 G E T T I N G S T A R T E D Air Bag Warning Light The ORC monitors the readiness of the electronic parts of the air bag system whenever the ignition switch is in the START or ON/RUN position. If the ignition switch is in the OFF position or in the ACC position, the air bag system is not on and the air bags will not inflate.
Page 29 G E T T I N G S T A R T E D Front Air Bags This vehicle has front air bags and lap/shoulder belts for both the driver and front passenger. The front air bags are a supplement to the seat belt restraint systems. The driver front air bag is mounted in the center of the steering wheel.
Page 30 G E T T I N G S T A R T E D This vehicle may be equipped with a driver and/or front passenger seat belt buckle switch that detects whether the driver or front passenger seat belt is buckled. The seat belt buckle switch may adjust the inflation rate of the Advanced Front Air Bags.
Page 31 G E T T I N G S T A R T E D Knee Impact Bolsters The Knee Impact Bolsters help protect the knees of the driver and front passenger, and position the front occupants for improved interaction with the front air bags. WARNING! •...
Page 32 G E T T I N G S T A R T E D WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury.
Page 33 G E T T I N G S T A R T E D WARNING! Occupants, including children, who are up against or very close to Side Air Bags can • be seriously injured or killed. Occupants, including children, should never lean on or sleep against the door, side windows, or area where the side air bags inflate, even if they are in an infant or child restraint.
Page 34 G E T T I N G S T A R T E D Rollover Events Side Air Bags are designed to activate in certain rollover events. The ORC determines whether the deployment of the Side Air Bags in a particular rollover event is appropriate, based on the severity and type of collision.
Page 35 G E T T I N G S T A R T E D If A Deployment Occurs The front air bags are designed to deflate immediately after deployment. NOTE: Front and/or side air bags will not deploy in all collisions. This does not mean something is wrong with the air bag system.
Page 36 G E T T I N G S T A R T E D Enhanced Accident Response System Reset Procedure In order to reset the Enhanced Accident Response System functions after an event, the ignition switch must be changed from ignition START or ON/RUN to ignition OFF. Carefully check the vehicle for fuel leaks in the engine compartment and on the ground near the engine compartment and fuel tank before resetting the system and starting the engine.
Page 37 G E T T I N G S T A R T E D NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded.
Page 38 G E T T I N G S T A R T E D Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight or Recommended Type of Child Restraint Children who are two years Either an Infant Carrier or a old or younger and who have Convertible Child Restraint, Infants and Toddlers...
Page 39 G E T T I N G S T A R T E D WARNING! Do not install a rear-facing car seat using a rear support leg in this vehicle. The floor of this vehicle is not designed to manage the crash forces of this type of car seat. In a crash, the support leg may not function as it was designed by the car seat manufac- turer, and your child may be more severely injured as a result.
Page 40 G E T T I N G S T A R T E D WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child re- straint.
Page 41 G E T T I N G S T A R T E D Recommendations For Attaching Child Restraints Restraint Combined Use Any Attachment Method Shown With An “X” Below Type Weight of the LATCH – Seat Belt LATCH – Seat Belt + Child + Child Lower An-...
Page 42 G E T T I N G S T A R T E D LATCH Positions For Installing Child Restraints In This Vehicle 2nd Row Bench Seat – Non-Stow ‘n Go LATCH Positions 2nd Row Quad Seating – Same For Stow ‘n Go And Non Stow ‘n Go Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit...
Page 43 G E T T I N G S T A R T E D Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front Can the rear-facing child passenger seat if the child restraint manufac- restraint touch the back of turer also allows contact.
Page 44 G E T T I N G S T A R T E D Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 45 G E T T I N G S T A R T E D Locating The Upper Tether Anchorages Bench Seat There are tether strap anchorages behind each rear seating position located on the back of the seat, near the floor. Quad Seats There are tether strap anchorages located behind the second row seating positions and the third row center seating position.
Page 46 G E T T I N G S T A R T E D To Install A LATCH-Compatible Child Restraint If the selected seating position has a Switchable Automatic Locking Retractor (ALR) seat belt, stow the seat belt, following the instructions below. See the section “Installing Child Restraints Using The Vehicle Seat Belt”...
Page 47 G E T T I N G S T A R T E D WARNING! • Improper installation of a child restraint to the LATCH anchorages can lead to failure of the restraint. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child restraint.
Page 48 G E T T I N G S T A R T E D Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Second Row Bench Seating – Non-Stow ‘N Go ALR = Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Cinch = Cinching Latch Plate Second Row Quad Seats ALR = Switchable Automatic Locking...
Page 49 G E T T I N G S T A R T E D Frequently Asked Questions About Installing Child Restraints With Seat Belts Can the rear-facing child Contact between the front passenger seat and restraint touch the back of the child restraint is allowed, if the child re- the front passenger seat? straint manufacturer also allows contact.
Page 50 G E T T I N G S T A R T E D Installing A Child Restraint With A Switchable Automatic Locking Retractor (ALR): Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder belt.
Page 51 G E T T I N G S T A R T E D Installing A Child Restraint With A Cinching Latch Plate (CINCH) — If Equipped: Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder belt.
Page 52 G E T T I N G S T A R T E D If the buckle or the cinching latch plate is too close to the belt path opening of the child restraint, you may have trouble tightening the seat belt. If this happens, disconnect the latch plate from the buckle and twist the short buckle-end belt up to three full turns to shorten it.
Page 53 G E T T I N G S T A R T E D 1. Look behind the seating position where you plan to install the child restraint to find the tether anchorage. You may need to move the seat forward to provide better access to the tether anchorage.
Page 54: Head Restraints
G E T T I N G S T A R T E D Transporting Pets Air Bags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 55 Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” in the Owner’s Manual on www.dodge.com/en/owners/manuals for further information. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button, located at the base of the head restraint, and push downward on the head restraint.
Page 56 • In the event of deployment of an Active Head Restraint, refer to “Occupant Re- straints” in “Things To Know Before Start- ing Your Vehicle” in the Owner’s Manual on www.dodge.com/en/owners/manuals for further information. Active Head Restraint (Normal Position) Active Head Restraint (Tilted)
Page 57 If your vehicle is equipped with a second row bench seat, the head restraints are not adjustable. Head Restraints — Third Row The head restraint in the center position can be raised and lowered for tether routing. Refer to “Occupant Restraints” in the Owner’s Manual www.dodge.com/en/owners/ manuals for further information. Raised Head Restraint...
Page 58: Power Seats
G E T T I N G S T A R T E D POWER SEATS Some models may be equipped with eight-way power seats for the driver and front passenger. The power seat switches are located on the outboard side of the seat. The switches control the movement of the seat cushion and the seatback.
Page 59 G E T T I N G S T A R T E D Adjusting The Seat Forward Or Rearward The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward. The seat will move in the direction of the switch. Release the switch when the desired position has been reached.
Page 60 G E T T I N G S T A R T E D Driver Memory Seat The Memory Buttons (1) and (2) on the driver's door panel can be programmed to recall the driver's seat, outside mirrors, and radio station preset settings. Your remote keyless entry key fob can also be programmed to recall the same positions when the unlock button is pushed.
Page 61 Memory” feature through the instrument cluster display. Refer to “Instrument Cluster Display” in “Understanding Your Instrument Panel” in you Owner’s Manual on www.dodge.com/en/owners/manuals for further information. To program your key fobs, perform the following: 1. Cycle the vehicle’s ignition to the OFF position.
Page 62 If your vehicle is not equipped with an instrument cluster display, your dealership can activate/deactivate this feature for you. For further information, refer to “Instrument Cluster Display” in “Understanding Your Instru- ment Panel” in the Owner’s Manual on www.dodge.com/en/owners/manuals.
Page 63: Heated Seats
Refer to “Instrument Cluster Display” in “Understanding Your Instrument Panel” in the Owner’s Manual on www.dodge.com/en/owners/manuals for further information. Front Heated Seats There are two heated seat switches that allow the driver and passenger to operate the seats independently.
Page 64: Heated Steering Wheel
G E T T I N G S T A R T E D Rear Heated Seats On some models, the second row seats are equipped with heaters. There are two heated seat switches that allow the second row passengers to operate the seats independently. The heated seat switches are located on the sliding side door handle trim panels.
Page 65: Tilt/Telescoping Steering Column
Instrument Panel” Owner’s Manual www.dodge.com/en/owners/manuals for further information. WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions must exercise care when using the steering wheel heater. It may cause burns even at low temperatures, especially if used for long periods.
Page 66: Engine Break-In Recommendations
The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. Refer to “Maintenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual on www.dodge.com/en/owners/manuals for further details. NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation.
Page 67: Multifunction Lever
O P E R A T I N G Y O U R V E H I C L E MULTIFUNCTION LEVER The multifunction lever is located on the left side of the steering column. Multifunction Lever 1 — Mist (Push To First Detent) 2 —...
Page 68 O P E R A T I N G Y O U R V E H I C L E Windshield Wiper And Washers The wipers and washers are operated by a switch within the multifunction lever. Rotate the end of the multifunction lever to select the desired wiper speed. NOTE: Always remove any buildup of snow that prevents the windshield wiper blades from returning to the off position.
Page 69 (if equipped). Refer to “Instrument Cluster Display/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” in your Owner’s Manual on www.dodge.com/en/owners/manuals for further information. The Rain Sensing system has protective features for the wiper blades and arms. It will not operate under the following conditions: •...
Page 70: Headlight Switch
O P E R A T I N G Y O U R V E H I C L E • Remote Start Mode Inhibit — On vehicles equipped with Remote Starting system, Rain Sensing wipers are not operational when the vehicle is in the remote start mode. Once the operator is in the vehicle and has placed the ignition switch in the RUN position, rain sensing wiper operation can resume, if it has been selected, and no other inhibit conditions (mentioned previously) exist.
Page 71 O P E R A T I N G Y O U R V E H I C L E Dimmer Controls The dimmer switch is located next to the headlight switch. With the parking lights or headlights on, rotating the dimmer control upward will increase the brightness of the instrument panel lights.
Page 72: Electronic Range Select (Ers)
Switching between ERS and DRIVE mode can be done at any vehicle speed. Refer to “Automatic Transmission” in “Start- ing And Operating” located in the Owner's Manual www.dodge.com/en/owners/ manuals for further details. Electronic Range Select...
Page 73: Fuel Economy (Econ) Mode
O P E R A T I N G Y O U R V E H I C L E FUEL ECONOMY (ECON) MODE The Fuel Economy (ECON) mode can improve the vehicle’s overall fuel economy during normal driving conditions. •...
Page 74: Three Zone Automatic Temperature Controls (Atc)
O P E R A T I N G Y O U R V E H I C L E THREE ZONE AUTOMATIC TEMPERATURE CONTROLS (ATC) Three Zone Automatic Temperature Controls (ATC) 1 — Push Driver Temp. Control Up 9 — Push Passenger Temp. Control Down 2 —...
Page 75 O P E R A T I N G Y O U R V E H I C L E Air Recirculation • Use Air Recirculation for maximum A/C operation. • For window defogging, turn the Air Recirculation button off. •...
Page 76: Parksense Rear Park Assist
If the radio display screen appears foggy, clean the camera lens located on the liftgate. Refer to your Owner's Manual on www.dodge.com/en/owners/manuals for further details. WARNING! Drivers must be careful when backing up even when using the ParkView Rear Back Up Camera.
Page 77: Blind Spot Monitoring With Rear Cross Path
The BSM system can also be configured to sound an audible (chime) alert and mute the radio to notify you of objects that have entered the detection zones. Refer to “Blind Spot Monitoring” in “Understanding The Features Of Your Vehicle” in the Owner's Manual on the www.dodge.com/en/owners/manuals for further information.
Page 78: Electronics Your Vehicle's Sound System
E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Voice Command Button pg. 103 2. Uconnect Phone Button pg. 99 3. Steering Wheel Audio Controls (Left) pg. 98 4. Steering Wheel Audio Controls (Right) pg. 98...
Page 79 E L E C T R O N I C S 5. USB Port pg. 88 6. Audio Jack pg. 88 7. USB Port (inside upper glove compartment) pg. 98...
Page 80: Cybersecurity
Privacy of any wireless and wired communications cannot be assured. Third parties may unlawfully intercept information and private communications without your consent. For further information, refer to “Onboard Diagnostic System (OBD II) Cybersecurity” in “Maintaining Your Vehicle” in your Owner’s Manual on www.dodge.com/en/owners/manuals.
Page 81: Uconnect 130
E L E C T R O N I C S UCONNECT 130 Uconnect 130 1 — CD Eject Button 9 — Set Clock Button 2 — SEEK Down Button 10 — Audio Settings/Rotate To Tune 3 — SEEK Up Button 11 —...
Page 82 E L E C T R O N I C S 5. Push the TUNE/SCROLL control knob to save the changes. 6. Push any button/knob or wait five seconds to exit. Equalizer, Balance And Fade 1. Push the TUNE/SCROLL control knob and “BASS” will display. 2.
Page 83: Uconnect 130 With Siriusxm Satellite Radio
E L E C T R O N I C S UCONNECT 130 WITH SIRIUSXM SATELLITE RADIO Uconnect 130 With SiriusXM Satellite Radio 1 — CD Eject Button 12 — Audio Jack 2 — SEEK Down Button 13 — Set Preset/CD Random Play 3 —...
Page 84 E L E C T R O N I C S Clock Setting 1. Push and hold the TIME button until the hours blink. 2. Turn the TUNE/SCROLL control knob to set the hours. 3. Push the TUNE/SCROLL control knob until the minutes begin to blink. 4.
Page 85 E L E C T R O N I C S SETUP Button • Pushing the SETUP button allows you to select between items that are available in that particular mode. • Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/ SELECT button to select an entry and make changes.
Page 86: Uconnect 430/430N
E L E C T R O N I C S Audio Jack Operation The AUX/Audio Jack provides a means to connect a portable audio device, such as an MP3 player or an iPod, to the vehicle’s sound system. This requires the use of a 3.5 mm stereo audio patch cable.
Page 87 E L E C T R O N I C S NOTE: • Your radio may not be equipped with the Uconnect Voice Command and Uconnect Phone features. To determine if your radio has these features, push the Voice Command button on the radio. You will hear a voice prompt if you have the feature, or see a message on the radio stating “Uconnect Phone not available”...
Page 88 E L E C T R O N I C S Display Settings • Push the MENU button on the faceplate and press the “Display Settings” button on the touchscreen to access the Display Settings menu. • Select the “Daytime Colors” button on the touchscreen to switch to manual daytime mode and to adjust the bright- ness of the display using daytime colors.
Page 89 E L E C T R O N I C S NOTE: If the Presets are not visible on the right side of the screen, press the “PRESETS” button on the touchscreen. CD/DVD Disc Operation • Push the MEDIA button on the faceplate to display the media source tabs at the top of the screen.
Page 90 E L E C T R O N I C S Audio Jack Operation The AUX/Audio Jack provides a means to connect a portable audio device, such as an MP3 player or an iPod, to the vehicle’s sound system. This requires the use of a 3.5 mm stereo audio patch cable.
Page 91 E L E C T R O N I C S Copying Music From USB • The USB port on the radio face plate allows you to copy files to your hard drive. To access, lift up on the cover. •...
Page 92 E L E C T R O N I C S Display A Picture On The Radio Screen • Once the import is complete, the pictures will then be available in the “MY PICTURES” screen. • Push the MY FILES button on the faceplate, then press the “My Pictures” button on the touchscreen.
Page 93 E L E C T R O N I C S Cleaning Your Touchscreen Radio • If necessary, use a dry micro fiber lens cleaning cloth dampened with a cleaning solution such as isopropyl alcohol or an isopropyl alcohol and water solution ratio of 50:50.
Page 94 E L E C T R O N I C S Main Navigation Menu Finding Points Of Interest • From the main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Points of Interest” button on the touchscreen. •...
Page 95 E L E C T R O N I C S Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen.
Page 96: Siriusxm Satellite Radio/Travel Link
E L E C T R O N I C S SIRIUSXM SATELLITE RADIO/TRAVEL LINK • SiriusXM Travel Link requires a subscription, sold separately after the five (5) year trial subscription included with your vehicle purchase. • SiriusXM Travel Link is only available in the United States. •...
Page 97 E L E C T R O N I C S SiriusXM Satellite Radio Favorites (SAT Favorites) • You can save 50 favorite songs and 50 favorite artists. • Press the “Add Favorite” button on the touchscreen to add either the song or the artist of the currently playing program to the SAT Favorites list.
Page 98 E L E C T R O N I C S You may use the “LIST” button on the touchscreen to toggle between: • Favorite Songs • Favorite Artists • Currently playing favorites SAT Favorites Replay • While you are in SAT mode, you can replay 44 minutes of the current SiriusXM channel (when the channel is changed, this audio buffer is erased).
Page 99 E L E C T R O N I C S SiriusXM Travel Link (Uconnect 430N Only) • SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips. • To access Travel Link, push the MENU button on the faceplate, then the “Travel Link” button on the touchscreen.
Page 100: Steering Wheel Audio Controls
E L E C T R O N I C S STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to increase or decrease the volume.
Page 101: Uconnect Phone
E L E C T R O N I C S Touchscreen Radios: To hear audio from devices connected to the USB port, push the “MEDIA” button on the faceplate, then press the “AUX” or “iPod” button on the touchscreen. When connected to this feature: •...
Page 102 E L E C T R O N I C S NOTE: The Uconnect Phone requires a mobile phone equipped with the Bluetooth Hands-Free Profile, Version 1.0 or higher. For Uconnect Customer Support: U.S. residents - visit UconnectPhone.com call 1-877-855-8400. Canadian residents visit...
Page 103 E L E C T R O N I C S Phonebook Phonebook Download — Automatic Phonebook Transfer From Mobile Phone If equipped and specifically supported by your phone, Uconnect Phone automatically downloads names (text names) and number entries from your mobile phone’s phonebook. Specific Bluetooth Phones with Phone Book Access Profile may support this feature.
Page 104 E L E C T R O N I C S Receiving A Call — Accept (And End) • When an incoming call rings/is announced on Uconnect, push the “Phone” button • To end a call, push the “Phone” button Mute (Or Unmute) Microphone During Call •...
Page 105: Uconnect Voice Command
E L E C T R O N I C S UCONNECT VOICE COMMAND Voice Command Operation The Uconnect Voice Command system allows you to control your AM, FM radio, satellite radio, disc player, HDD, Uconnect Phone, a memo recorder, and supported portable media devices.
Page 106 E L E C T R O N I C S While In: Voice Command Example: “Track” (#) (to change the track) “Next Track” (to play the next track) Disc Mode “Previous Track” (to play the previous track) “Main Menu” (to switch to the main menu) To switch to the voice recorder mode, say “Memo.”...
Page 107: Bluetooth Streaming Audio
E L E C T R O N I C S WARNING! Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.
Page 108: Instrument Cluster Display
Using either the touchscreen radio or remote control, select AUX from the REAR VES CONTROL or the MODE SELECTION screen. Refer to “Video Entertainment System (VES)” in the vehicle Owner's Manual on www.dodge.com/en/owners/manuals for further information. INSTRUMENT CLUSTER DISPLAY The instrument cluster display features a driver interactive display that is located in the instrument cluster.
Page 109: Programmable Features
The following features may also be programmed by using the key fob or the ignition and driver's door lock switch. Refer to “Uconnect Settings” in “Understanding Your Instru- ment Panel” in the Owner’s Manual on www.dodge.com/en/owners/manuals for further information. NOTE: Pushing the lock button while you are inside the vehicle will activate the vehicle security alarm.
Page 110 E L E C T R O N I C S Unlock On First Press To unlock either the driver's side, or all doors, on the first press of the unlock button: 1. Push and hold the lock button for at least four seconds, but no longer than 10 seconds. Then, push and hold the unlock button while still holding the lock button.
Page 111 E L E C T R O N I C S UNIVERSAL GARAGE DOOR OPENER (HomeLink) HomeLink replaces up to three hand-held transmitters that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink unit is powered by your vehicles 12 Volt battery.
Page 112 E L E C T R O N I C S 3. Push and hold the HomeLink button you want to program while you push and hold the hand-held transmitter button. 4. Continue to hold both buttons and observe the indicator light. The HomeLink indicator will flash slowly and then rapidly after HomeLink has received the frequency signal from the hand-held transmitter.
Page 113 E L E C T R O N I C S Using HomeLink To operate, push and release the programmed HomeLink button. Activation will now occur for the programmed device (e.g., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.). The hand-held transmitter of the device may also be used at any time.
Page 114: Recreational Towing (Behind Motorhome, Etc.)
U T I L I T Y TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) GCWR (Gross Max. GTW Engine/ Max. Tongue Combined Wt. Frontal Area (Gross Trailer Transmission Rating) Wt.) Up to 2 persons 8,750 lbs 40 sq ft & Luggage 360 lbs (3,969 kg) (3.72 sq m)
Page 115 U T I L I T Y Recreational Towing — All Models Recreational towing is allowed ONLY if the front wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this procedure: 1.
Page 116: What To Do In Emergencies Roadside Assistance
W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
Page 117 W H A T T O D O I N E M E R G E N C I E S — Oil Pressure Warning Light This light indicates low engine oil pressure. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible.
Page 118 W H A T T O D O I N E M E R G E N C I E S Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label.
Page 119 W H A T T O D O I N E M E R G E N C I E S — Engine Temperature Warning Light This light warns of an overheated engine condition. If the light turns on or flashes continuously while driving, safely pull over and stop the vehicle.
Page 120 W H A T T O D O I N E M E R G E N C I E S NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level conditions. The vehicle should have service performed, and the brake fluid level checked.
Page 121 W H A T T O D O I N E M E R G E N C I E S Instrument Cluster Indicator Lights — Turn Signal Indicator The arrows will flash with the exterior turn signals when the turn signal lever is operated. A tone will chime, and an instrument cluster display message will appear if either turn signal is left on for more than 1 mile (1.6 km).
Page 122: If Your Engine Overheats
W H A T T O D O I N E M E R G E N C I E S To reset the oil change indicator system (after performing the scheduled maintenance), refer to the following procedure. Vehicles Not Equipped With Keyless Enter-N-Go 1.
Page 123: Tire Service Kit
W H A T T O D O I N E M E R G E N C I E S WARNING! You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool.
Page 124 W H A T T O D O I N E M E R G E N C I E S Tire Service Kit Components And Operation Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or seal- ant mode.
Page 125 W H A T T O D O I N E M E R G E N C I E S • When the Tire Service Kit sealant is in a liquid form, clean water, and a damp cloth will remove the material from the vehicle or tire and wheel components.
Page 126 W H A T T O D O I N E M E R G E N C I E S Sealing A Tire With Tire Service Kit (A) Whenever You Stop To Use Tire Service Kit: 1. Pull over to a safe location and turn on the vehicle’s Hazard Warning flashers. 2.
Page 127 W H A T T O D O I N E M E R G E N C I E S 2. Connect the Power Plug (8) to a different 12 Volt power outlet in your vehicle or another vehicle, if available. Make sure the engine is running before turning the Tire Service Kit on.
Page 128 W H A T T O D O I N E M E R G E N C I E S (D) Drive Vehicle: Immediately after injecting sealant and inflating the tire, drive the vehicle 5 miles (8 km) or 10 minutes to ensure distribution of the Tire Service Kit Sealant within the tire. Do not exceed 55 mph (90 km/h).
Page 129: Jacking And Tire Changing — If Equipped
W H A T T O D O I N E M E R G E N C I E S 6. Replace the Sealant Bottle (1) and Sealant Hose (6) assembly at your authorized dealer as soon as possible. Refer to (F) “Sealant Bottle And Hose Replacement”. NOTE: When having the tire serviced, advise the authorized dealer or service center that the tire has been sealed using the Tire Service Kit.
Page 130 W H A T T O D O I N E M E R G E N C I E S Jack Location The jack, jack handle and winch handle tools are stowed behind the rear left side trim panel in the rear cargo area. Turn the two cover latches to release the cover. Jack And Tool Location Spare Tire Removal The spare tire is stowed inside a protective cover located under the center of the vehicle...
Page 131 W H A T T O D O I N E M E R G E N C I E S Super Console For vehicles equipped with the Super Console, the spare tire winch assembly drive nut is located beneath the console. 1.
Page 132 W H A T T O D O I N E M E R G E N C I E S 3. Remove the liner from the console's storage compartment to access the spare tire winch drive nut. Winch Drive Nut Location Premium/Base/Cargo Center Console Pull the Winch Cover assembly plug (if equipped) to access the winch drive nut.
Page 133 W H A T T O D O I N E M E R G E N C I E S Spare Tire Tools The tool pouch contains three pieces and can be assembled into a spare tire hook; to remove the compact spare tire/cover assembly from under the vehicle, or a Winch T-handle;...
Page 134 W H A T T O D O I N E M E R G E N C I E S Spare Tire Removal Instructions The spare tire is located under the vehicle beneath the center console area. 1. Assemble the spare tire tools into a T-handle and place the square end over the spare tire winch drive nut.
Page 135 W H A T T O D O I N E M E R G E N C I E S 4. Stand the tire/cover assembly upright and remove the wheel spacer by squeezing the winch retaining tabs together. Push the retainer through the spare tire to release it from the wheel.
Page 136 W H A T T O D O I N E M E R G E N C I E S 6. Block both the front and rear of the wheel diagonally opposite of the jacking position. For example, if changing the right front tire, block the left rear wheel. NOTE: Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 137 W H A T T O D O I N E M E R G E N C I E S CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. NOTE: Refer to the “Compact Spare Tire”...
Page 138 W H A T T O D O I N E M E R G E N C I E S Rear jack locations are between a pair of down-facing tabs on the sill flange of the vehicle side body. Rear Jacking Location Engaged Front jack location is on the sill flange of the vehicle body and is located 6 inches (150 mm) from door edge.
Page 139 W H A T T O D O I N E M E R G E N C I E S WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 5.
Page 140 W H A T T O D O I N E M E R G E N C I E S WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided.
Page 141 W H A T T O D O I N E M E R G E N C I E S 3. Turn the compact spare tire so that the valve stem is down, and place the tire into the compact spare tire/cover assembly.
Page 142 W H A T T O D O I N E M E R G E N C I E S Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle. 2. To ease the installation process for steel wheels with wheel covers, install two lug nuts on the mounting studs which are on each side of the valve stem.
Page 143: Jump Starting
W H A T T O D O I N E M E R G E N C I E S Vehicles Without Wheel Covers 1. Mount the road tire on the axle. 2. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
Page 144 W H A T T O D O I N E M E R G E N C I E S Preparations For Jump-Start The battery in your vehicle is located on the left side of the engine compartment. Positive Battery Post WARNING! •...
Page 145 W H A T T O D O I N E M E R G E N C I E S Jump Starting Procedure WARNING! Failure to follow this jump-starting procedure could result in personal injury or property damage due to battery explosion. CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle.
Page 146 W H A T T O D O I N E M E R G E N C I E S 6. Once the engine is started, remove the jumper cables in the reverse sequence: Disconnecting The Jumper Cables 1. Disconnect the negative (-) end of the jumper cable from the engine ground of the vehicle with the discharged battery.
Page 147: Gear Selector Override
W H A T T O D O I N E M E R G E N C I E S GEAR SELECTOR OVERRIDE If a malfunction occurs and the gear selector cannot be moved out of the PARK position, you can use the following procedure to temporarily move the gear selector: 1.
Page 148: Towing A Disabled Vehicle
W H A T T O D O I N E M E R G E N C I E S TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The ALL MODELS Ground...
Page 149: Freeing A Stuck Vehicle
W H A T T O D O I N E M E R G E N C I E S The manufacturer recommends towing your vehicle with all four wheels OFF the ground using a flatbed. If flatbed equipment is not available, and the transmission is operable, the vehicle may be flat towed (with all four wheels on the ground) under the following conditions: •...
Page 150: Enhanced Accident Response System (Ears)
Push the "ESC Off" switch, to place the Electronic Stability Control (ESC) system in "Partial Off" mode before rocking the vehicle. Refer to “Electronic Brake Control System” in “Starting And Operating” in your Owner’s Manual on www.dodge.com/en/owners/manuals for further information. Once the vehicle has been freed, push the "ESC Off" switch again to restore "ESC On"...
Page 151: Maintaining Your Vehicle Opening The Hood
M A I N T A I N I N G Y O U R V E H I C L E OPENING THE HOOD 1. Pull the hood release lever located on the instrument panel, below the steering column. 2.
Page 152: Engine Compartment — 3.6L
M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 3.6L 1. Air Cleaner Filter 2. Brake Fluid Reservoir 3. Integrated Power Module (Fuses) 4. Battery 5.
Page 153 M A I N T A I N I N G Y O U R V E H I C L E 6. Engine Oil Dipstick 7. Engine Oil Fill 8. Engine Coolant Pressure Cap 9. Washer Fluid Reservoir 10. Power Steering Fluid Reservoir...
Page 154: Fluid Capacities
M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, API Certified). 6 Quarts 5.6 Liters Cooling System *...
Page 155: Maintenance Procedures
We recommend you use Mopar Power Steering Fluid +4, Mopar ATF+4 Automatic Transmission Fluid. MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Main- tenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or an applicable supplement at www.dodge.com/en/owners/manuals for further information.
Page 156: Maintenance Schedule
“Instrument Cluster Warning Lights” in “What To Do In Emergencies” in this guide or “Instrument Cluster Display” in “Understanding Your Instrument Panel” in your Owner's Manual at www.dodge.com/en/owners/manuals for further details. NOTE: Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km), twelve months or 350 hours of engine run time, whichever comes first.
Page 157 M A I N T A I N I N G Y O U R V E H I C L E Maintenance Chart Required Maintenance Intervals. Refer to the maintenance schedules on the following page for the required maintenance intervals.
Page 158 M A I N T A I N I N G Y O U R V E H I C L E...
Page 159 M A I N T A I N I N G Y O U R V E H I C L E...
Page 160 M A I N T A I N I N G Y O U R V E H I C L E...
Page 161: Fuses
M A I N T A I N I N G Y O U R V E H I C L E FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating.
Page 162 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description – – Not Used Headlamp Wash/Manifold Tuning 30 Amp Pink – Valve – If Equipped Power Sliding Door Module/Anti–...
Page 163 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Mini-Fuse Description Rear View Mirror, Instrument Clus- – 20 Amp Yellow ter, Multifunction Control Switch, Tire Pressure Monitor Airbag Module/Occupant Classifi- –...
Page 164: Tire Safety Information
M A I N T A I N I N G Y O U R V E H I C L E TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P”...
Page 165 M A I N T A I N I N G Y O U R V E H I C L E EXAMPLE: 65, 85, 80 = Aspect ratio in percent (%) – Ratio of section height to section width of tire, or 10.5 = Section width in inches (in) R = Construction code –...
Page 166 M A I N T A I N I N G Y O U R V E H I C L E Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side.
Page 167 M A I N T A I N I N G Y O U R V E H I C L E Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door.
Page 168 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recom- mended load capacity for your vehicle.
Page 169 M A I N T A I N I N G Y O U R V E H I C L E To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs” on the Tire and Loading Information placard.
Page 170 M A I N T A I N I N G Y O U R V E H I C L E Metric Example For Load Limit For example, if “XXX” amount equals 635 kg, and there will be five 68 kg passengers in your vehicle, the amount of available cargo and luggage load capacity is 295 kg (635-340 (5x68) = 295 kg) as shown in step 4.
Page 171: Tires — General Information
M A I N T A I N I N G Y O U R V E H I C L E TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 172 M A I N T A I N I N G Y O U R V E H I C L E Ride Comfort And Vehicle Stability Proper tire inflation contributes to a comfortable ride. Over-inflation produces a jarring and uncomfortable ride. Tire Inflation Pressures The proper cold tire inflation pressure is listed on the driver's side B-Pillar or rear edge of the driver's side door.
Page 173 M A I N T A I N I N G Y O U R V E H I C L E Tire Pressures For High Speed Operation The manufacturer advocates driving at safe speeds and within posted speed limits. Where speed limits or conditions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 174 M A I N T A I N I N G Y O U R V E H I C L E Summer Or Three Season Tires — If Equipped Summer tires provide traction in both wet and dry conditions, and are not intended to be driven in snow or on ice.
Page 175 M A I N T A I N I N G Y O U R V E H I C L E Spare Tires — If Equipped NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to the “Tire Service Kit”...
Page 176 M A I N T A I N I N G Y O U R V E H I C L E Collapsible Spare Tire — If Equipped The collapsible spare is for temporary emergency use only. You can identify if your vehicle is equipped with a collapsible spare by looking at the spare tire description on the Tire and Loading Information Placard located on the driver’s side door opening or on the sidewall of the tire.
Page 177 M A I N T A I N I N G Y O U R V E H I C L E WARNING! Limited use spares are for emergency use only. Installation of this limited use spare tire affects vehicle handling. With this tire, do not drive more than the speed listed on the limit use spare wheel.
Page 178 M A I N T A I N I N G Y O U R V E H I C L E Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: •...
Page 179 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, resulting in changes to steering, handling, and braking of your vehicle.
Page 180 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! Avoid products or automatic car washes that use acidic solutions or strong alkaline additives or harsh brushes. Many aftermarket wheel cleaners and automatic car washes may damage the wheel's protective finish.
Page 181: Department Of Transportation Uniform Tire Quality Grades
M A I N T A I N I N G Y O U R V E H I C L E DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire's manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 182: Adding Fuel
M A I N T A I N I N G Y O U R V E H I C L E Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 183 M A I N T A I N I N G Y O U R V E H I C L E Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.
Page 184: Flexible Fuel — If Equipped
M A I N T A I N I N G Y O U R V E H I C L E FLEXIBLE FUEL — IF EQUIPPED E-85 General Information The information in this section is unique for Flexible Fuel vehicles only. These vehicles can be identified by a unique fuel filler door label that states Ethanol (E-85) or Unleaded Gasoline Only and a yellow fuel cap.
Page 185: Fca Canada Inc. Customer Center
Warranty Booklet. United States customers may visit the Dodge Contact Us page at www.dodge.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Compartment Material” from the left menu. You can also purchase a copy by calling 1-800-423-6343 (U.S.) or 1-800-387-1143...
Page 186: Reporting Safety Defects In The United States
C O N S U M E R A S S I S T A N C E REPORTING SAFETY DEFECTS IN THE UNITED STATES If you believe that your vehicle has a defect that could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying FCA US LLC.
Page 187: Authentic Accessories By Mopar
For the full line of Authentic Dodge Accessories by Mopar, visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.
Page 188: Frequently Asked Questions Frequently Asked Questions
F R E Q U E N T LY A S K E D Q U E S T I O N S FREQUENTLY ASKED QUESTIONS GETTING STARTED • How do I install my LATCH Equipped Child Seat? pg. 44 •...
Page 189 F R E Q U E N T LY A S K E D Q U E S T I O N S UTILITY • How do I know how much I can tow with my vehicle? pg. 112 WHAT TO DO IN EMERGENCIES •...
Page 190: Index
I N D E X Accessories ....185 Back-Up Camera ... .74 Mopar ....185 Battery .
Page 191 I N D E X Electronic Speed Control ON Emergencies, What To Do In ..114 Indicator ....119 Emergency ....114 Electronic Speed Control Emergency, In Case Of SET Indicator .
Page 192 I N D E X Fuel, Flexible....182 Key Fob Programmable Features . . .107 Fuses ....159 Lane Change Assist .
Page 193 I N D E X Multi-Function Control Lever ..65 Radio Operation...80, 82 Rear Camera ....74 Navigation .
Page 194 I N D E X Rear Seat ....14 Life Of Tires ... .176 Reminder ... . .117 Load Capacity .
Page 195 I N D E X Washer Windshield Washers ...66 Adding Fluid ... .153 Windshield Wiper Blades ..153 Washing Vehicle .
Page 196 N O T E S...
Page 197 N O T E S...
Page 198 N O T E S...
Page 199 N O T E S...
Page 200 N O T E S...
Page 201 N O T E S...
Page 202 N O T E S...
Page 203 ( U. S. ) , ww w. m opar.ca ( Canada) or your local Dodge b ra nd d e a l e r.
Page 204 Dodge brand vehicle. Simply download the app, select your make and model and enjoy the ride. To get this app, go directly to the App Store or Google Play and enter the search keyword “Dodge”...
