Summary of Contents for Viper V760

  • Page 2: Features & Technical Specifications

    • 103 key rollover anti-ghosting • Supports up to 6 Profiles The Viper software allows you to custom color each key up to 16.8 million LED colors, and program up to 103 keys with macros. The Viper soft- • Quick start guide •...

  • Page 3: Hardware Installation

    INSTALLATION HARDWARE INSTALLATION Connect the keyboard to two available USB ports. Wait 5-10 seconds for the keyboard to be recognized by the computer. KEYBOARD SHORTCUTS SOFTWARE INSTALLATION Please download the keyboard software from the product page at http://www.patriotmemory.com to change light effects, cre- ate and manage macros, manage profiles, adjust latency, response and more.

  • Page 4: Multi-Media Keys

    MULTI-MEDIA KEYS BACKLIGHT RECORDING MODES Record and Save custom key configurations FN+1 FN+2 FN+3 PLAY/PAUSE PREVIOUS NEXT TRACK Pressing any key in record mode will change the color of the key and pressing it again will cycle When Recording is complete, press through preset colors.

  • Page 5: Ripple Mode

    RADAR/SPOTLIGHT/WAVE MODES RIPPLE MODE Press FN+F6 -Continuously to alternate between modes SPOTLIGHT MODE RADAR MODE WAVES MODE RIPPLE MODE Keys light up on both sides of the keyboard, Lighting travels along the edge of the keyboard Color spectrum moves from one end of the When pressing any key, the lighting will be spread in all directions;...
  • Page 6 VORTEX/SIDEWINDER MODES RAINDROP/REACTIVE MODES Press FN+F8 -Continuously to alternate between modes Press FN+F9 -Continuously to alternate between modes VORTEX MODE SIDEWINDER MODE RAINDROP MODE REACTIVE MODE Entire keyboard lights up one key at a time from Lighting effect starts at the top and winds to side Keys are randomly lit resembling the pattern When pressing any key, the key will light up the top-left towards the center of the keyboard...
  • Page 7 STATIC/SPECTRUM BREATHE Press FN+F11 Continuously to alternate between modes STATIC MODE SPECTRUM MODE BREATHE MODE All keys are illuminated with one specific color Keys cycles through colors of the rainbow Selected color brightens and then fades FN+PgUp FN+PgDn FN+PgUp FN+PgDn Decreases Fading Speed of Increases Speed of Breathe Decreases Speed of Breathe...
  • Page 8 KEYBOARD SOFTWARE The V760’s light effects can be set from the Viper software by selecting the effect from the drop down menu. Color selection, brightness, speed, and pattern direction can all be set, depending on the light effect, from the...
  • Page 9 CUSTOM LIGHTING PROFILES Check the box next to DIY to access custom color mode. You may create custom lighting profiles by selecting one of the five Lighting Profiles from the drop down menu in Select a key or select a group of keys and choose a color from the color pallet. Click OK, and then Apply to change and save Light Effects.
  • Page 10 MACROS Response Time and Report Rate Creating a macro- Click on the Macros button from the main menu to open the macro editor. You may adjust the response time and report rate for the keyboard from the main menu. A lower response time will decrease You may create and save 32 different macro scripts, of 47 characters in length reaction time, and a higher report rate also decreases reaction time.
  • Page 11 KEY ASSIGNMENTS Select a Lighting Profile and check the box on Keymap. This gives you access to the SELECTED KEY menu. You may assign specific functions to each key through the SELECTED KEY menu. • Single/Combine • Macro • Basic •...
  • Page 12 MACRO This allows you to assign macro scripts you have created and saved to specific keys. Click a key you wish to assign a macro to on the keyboard image (except for the Windows® key). Click on the Macro tab from the SELECTED KEY menu and choose the macro you wish to assign from the list. Click Save, enable GAME MODE, click Apply.
  • Page 13 To load a saved profile to the keyboard, simply click on Profiles in the lower left Double click on the profile you wish to load from your user profile folder and hit To create a user profile, follow the steps outlined above to custom color keys, Name the profile and Save.

  • Page 14: General Settings

    FACTORY RESET WINDOWS KEY LOCK GENERAL SETTINGS To reset the keyboard to factory default settings, click on the You may disable the Windows® key during game play by checking setting icon in the upper right corner and then click Reset settings. the box next to WINDOWS KEY LOCK, and then clicking Apply.

  • Page 15: Fcc Notice

    FCC and Legal: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 ofthe FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in ac- cordance with the instructions, may cause harmful interference to radio communications.
