Exposure Lights BLAZE User Manual

CHARGING
Fully Charge your light before first use.
Locate the charge port on top of the light by lifting the silicone top cap.
Charge Port
IMPORTANT: After charging is complete correctly replace the top-cap to prevent water ingress.
LIGHT OPERATION & BATTERY LIFE
To turn the light on press the function button twice in quick
succession.
The light will turn on in the mode that was last used. A single
press of the function button will cycle between a constant
beam and a pulse.
To turn the light off hold the function button down until there is
a double flash and then release.
The Function Button also displays mode and battery life. When
you turn the light on or change to another mode the Function
Button will glow amber for Pulse Mode and green for Constant
for 2 seconds, thereafter the Function Button becomes the
Fuel Gauge and indicates battery life remaining.
NOTE: When the battery has only 5% charge remaining the
light will automatically switch to the low flash setting and the
Function Button will flash red.
USER GUIDE
Fully insert the USB Top-Up Cable and
begin charging from a USB supply.
An LED behind the Function Button will
flash green to indicate that it is charging
and then turn solid green when the light
is 95% charged, the remaining 5% is a
trickle charge.
Approximate charge time from a
500 mA supply is 4 hours.
Function Button
Fuel Gauge
LED COLOUR
GREEN
AMBER
RED
RED FLASH
BLAZE
BATTERY %
100 - 80
80 - 25
25 - 5
5 - EMPTY
