- Page 1 OPERATING AND INSTALLATION MANUAL Accumulation Tank NADO 500/25v6 NADO 300/20v6 NADO 750/35v6 NADO 1000/45v6 Družstevní závody Dražice - strojírna s.r.o. Dražice 69, 294 71 Benátky nad Jizerou Phone.: +420 /326 370 990 Fax: +420 / 326 370 980 E-mail: prodej@dzd.cz...
-
Page 2: Table Of Contents
DESIGNING THE SIZE AND CONNECTION OF STORAGE TANK TO THR HEATING SYSTEM ....4 TECHNICAL PARAMETERS ........................5 IMPORTANT NOTICES ..........................6 TECHNICAL DESCRIPTION .......................... 7 NADO 500/25v6, 750/35 v6, 1000/45 v6 ..................8 NADO 300/20v6 ..........................9 - 2 -... - Page 3 PRIOR TO THE INSTALLATION OF THE TANK, READ CAREFULLY THIS MANUAL! Dear Customer, The Works Cooperative of Dražice – Machine Plant, Ltd., would like to thank you for your decision to use a product of our brand. The present instructions will introduce you to the use, construction, maintenance and other information regarding electrical water tanks.
-
Page 4: Product Technical Specification
1 PRODUCT TECHNICAL SPECIFICATION 1.1 FUNCTION DESCRIPTION Storage tanks serve accumulation of excessive heat from its source. The source may be a solid fuel boiler, heat pump, solar collectors, fireplace inserts, etc. Some types of storage tanks allow combination of connecting even multiple sources. -
Page 5: Technical Parameters
The manufacturer explicitly emphasises the necessity of being particular in testing the tightness of the heating circuit (radiators, piping joints, floor heating, etc.) with the connection of the storage tank. No pressure grow above the maximum operating pressure of 0,3 MPa in the storage tank heating water compartment may occur, if the heating system is pressurised to higher than the maximum operating pressure, the inner stainless exchanger may get permanently damaged! -
Page 6: Important Notices
2 IMPORTANT NOTICES Connection of internal tank for hot water must comply with CSN 060830, i.e. on cold water inlet is necessary to install a safety valve. We recommend to start up the heating circle before commissioning and to clean possible dirts caught in the filter and after this the system would be fully functional. -
Page 7: Technical Description
3 TECHNICAL DESCRIPTION 1 - Bleeding (heating water outlet) 2 - Hot water outlet G 1¼“ 3 - Funnel for additional heating element TJ 6/4“ with an extended cooling compartment 2x 4 - Funnel for a thermowell 4x G 1/2“ 5 - Funnel for connecting another heating water source 6x G 1 ¼“... -
Page 8: Nado 500/25V6, 750/35 V6, 1000/45 V6
3.1 NADO 500/25v6, 750/35 v6, 1000/45 v6 NADO NADO NADO TYPE 500/25v6 750/35 v6 1000/45v6 1992 2031 2058 1035 1000 Thermal insulation: NEODUL Polyester sheet of 100 mm thickness. It consists of an upper cover, flange cover and hole caps. Insulation is supplied in a separate packaging. -
Page 9: Nado 300/20V6
3.2 NADO 300/20v6 VIEW "A" VIEW "B" Thermal insulation: BALCALDO 26-9-2017 - 9 -...
