Summary of Contents for NUUO SCB-C31A
- Page 1 The Point of Sale Solution SCB-C31A Hardware & Software Installation user’s manual 2011, May...
-
Page 2: Table Of Contents
Definition of Terms ....................2 Product Specification ..................3 HARDWARE INSTALLATION ..................4 SCB-C31A data capture convertor ............... 4 SOFTWARE INSTALLATION ..................6 SCB-C31A POS data capture convertor ............6 NUUO NVR/DVR/Hybrid system installation ..........7 NUUO NVR/DVR/Hybrid software setup............7 page-1... -
Page 3: System Introduction
Intelligent Surveillance Solution System Introduction SYSTEM INTRODUCTION NUUO POS, a Point of Sale Systems based on NUUO NVR/DVR/NVDR, provides financial transaction’s surveillance solution in one central system. The architecture is as below; POS transaction data flows to NVR by Ethernet. Each Cash Register with an external receipt printer is connected by DB9 cable. -
Page 4: Product Specification
Intelligent Surveillance Solution System Introduction Product Specification NUUO Capture Box SCB-C31A Input RS232 Output Ethernet DC In DC +9V to +24V Power consumption 500 mA -20 to 65℃ Operating Temperature Operating Humidity 0-90 % Non-Condensing Baud Rate 110 bps to 230.4 kbps... -
Page 5: Hardware Installation
Null-Modem. The connection between SCB C31A POS Data capture box and Y-cable must be null modem (in package). Step 4: Check the system switch of the SCB-C31A POS is switch to OFF, OFF position. Step 5: Connect power source with SCB-C31A POS. - Page 6 Intelligent Surveillance Solution System Introduction The LED Indicators: Link LED: Ethernet cable connection and data active. Run LED: System is ready (Blinking). Serial 1: Transiting/Receiving Indicator. page-5...
-
Page 7: Software Installation
Intelligent Surveillance Solution Software Installation SOFTWARE INSTALLATION SCB-C31A POS data capture convertor Step 1: Use IE-browser to setup SCB-C31A POS, the default IP address is 192.168.1.1 Step 2: Setup IP address and password, and then setup IP address. Note: Each time you switch the page of the web, please click Save at first. -
Page 8: Nuuo Nvr/Dvr/Hybrid System Installation
(refer page 5). Hold for 3 seconds and release. The Link and Run light will go out and turn back on. The SCB-C31A POS will revert to the last setting. Note:... - Page 9 Intelligent Surveillance Solution page-8...
