Thermocouple Input Module
Channel Isolated Thermocouple
/Micro Voltage Input Module
MITSUBISHI
General-Purpose PROGRAMMABLE LOGIC CONTROLLER
Thank you for purchasing the Mitsubishi general-purpose
programmable logic controller MELSEC-Q series.
Prior to use, please read this manual thoroughly and
familiarize yourself with the product
© 2000 MITSUBISHI ELECTRIC CORPORATION
User's Manual
MODEL
MODEL
CODE
IB(NA)-0800155-B(0201)MEE
(Hardware)
Q64TD
Q64TDV-GH
Q64TD-U-H-JE
13JT30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q64TD and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Q64TD

  • Page 1 /Micro Voltage Input Module MITSUBISHI General-Purpose PROGRAMMABLE LOGIC CONTROLLER User’s Manual (Hardware) Q64TD Q64TDV-GH Thank you for purchasing the Mitsubishi general-purpose programmable logic controller MELSEC-Q series. Prior to use, please read this manual thoroughly and familiarize yourself with the product MODEL Q64TD-U-H-JE MODEL...
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using.) When using Mitsubishi equipment, thoroughly read this manual and the associated manuals introduced in this manual. Also pay careful attention to safety and handle the module properly. These SAFETY PRECAUTIONS classify the safety precautions into two categories: “DANGER”...
  • Page 3 [INSTALLATION PRECAUTIONS] CAUTION Use the PLC in an environment that meets the general specifications contained in the CPU user's manual. Using this PLC in an environment outside the range of the general specifications may cause electric shock, fire, malfunction, and damage to or deterioration of the product.
  • Page 4: Revisions

    Section5.2, Section5.3,Chapter6 This manual confers no industrial property rights or any rights of any other kind, nor dose it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
  • Page 5: Table Of Contents

    About the Manuals..................A-5 Conformance to the EMC Directive/Low Voltage Directive ......A-5 1. OVERVIEW ....................1 2. SPECIFICATIONS..................1 2.1 Specifications of Q64TD ................1 2.1.1 Performance specifications .............1 2.1.2 Usable thermocouples and measured temperature range accuracies..................2 2.2 Specifications of Q64TDV-GH ..............3 2.2.1 Performance specifications .............3...
  • Page 6: About The Manuals

    QTIU-E) Conformance to the EMC Directive/Low Voltage Directive For details on making Mitsubishi PLC conform to the EMC directive and low voltage instruction when installing it in your product, please see Chapter 3, "EMC Directive and Low Voltage Instruction" of the User's Manual (Hardware) of the PLC CPU to use.
  • Page 7: Overview

    1. OVERVIEW This user's manual provides the specifications, handling, part names and others of the Q64TD thermocouple temperature input module (abbreviated to the Q64TD) and Q64TDV-GH channel isolated thermocouple/micro voltage input module (abbreviated to the Q64TDV-GH) used with the MELSEC-Q series CPU module.
  • Page 8: Usable Thermocouples And Measured Temperature Range Accuracies

    2.1.2 Usable Thermocouples and Measured Temperature Range Accuracies Usable Measured Conversion Accuracy Temperature Characteristic Max. Temperature Thermo Temperature (At operating ambient (Per operating ambient Error at Ambient couple temperature 25 5 ) Range*1 temperature variation of 1 ) Temperature 55 Type 0 to 600 ———...
  • Page 9: Specifications Of Q64Tdv-Gh

    2.2 Specifications of Q64TDV-GH 2.2.1 Performance Specifications Item Specifications Number of channels 4 channels Temperature 16-bit, signed binary conversion value (-2700 to 18200: Value to the first decimal place 10 times) Micro voltage 16-bit signed binary (-25000 to 25000) conversion value Scaling value 16-bit, signed binary Standard with which...
  • Page 10 into a temperature *2: A period until a thermocouple input value/micro voltage input value is converted measurement value/micro voltage conversion value. *3: A period until a thermocouple input value/micro voltage input value is converted into a temperature measurement value/micro voltage conversion value and the resultant value is stored into the buffer memory.
  • Page 11: Usable Thermocouples And Measured Temperature Range Accuracies

    2.2.2 Usable Thermocouples and Measured Temperature Range Accuracies Usable Measured Conversion Accuracy Temperature Characteristic Max. Temperature Thermo Temperature (At operating ambient (Per operating ambient Error at Ambient couple Range*1 temperature 25 5 ) temperature variation of 1 ) Temperature 55 Type 0 to 600 ———...
  • Page 12: Loading And Installation

    3. LOADING AND INSTALLATION 3.1 Handling Instructions (1) Do not drop the case and connectors of the module and subject them to hard impact. (2) Do not remove the printed circuit boards of the module from the case. Doing so can cause a failure. (3) Be careful to prevent wire-offcuts and other foreign matter from entering the module.
  • Page 13: Names And Settings Of The Parts

    Q64TDV Q64TD Number Name and Appearance Description Indicates the operating status of the Q64TD/Q64TDV-GH. : Operating normally. Flicker : Offset/gain setting mode RUN LED : 5V power-off , Watchdog timer error occurrence or module change enabled status during online module change Indicates the error status of the Q64TD/Q64TDV-GH.
  • Page 14: Wiring

    5. WIRING 5.1 Wiring Instructions (1) Use separate cables for the AC control circuit and Q64TD/Q64TDV-GH's external input signals to avoid the influence of AC side surges and inductions. (2) Always place the thermocouple/micro voltage signal cable at least 100mm away from the main circuit cables and AC control circuit lines.
  • Page 15 (2) Micro voltage signal Pt100 Load cell or like Load cell or like *1:As cables, always use shielded conductors. Also, wire the shielded cables as short as possible. *2:Always connect to the earth terminal of the control box.
  • Page 16: Intelligent Function Module Switch Setting

    5.3 Intelligent Function Module Switch Setting Make the intelligent function module switch setting using the I/O assignment setting of GX Developer. You can make setting easily by entering hexadecimal numbers into 4 digits. Setting Item Input type Set value Thermocouple K Thermocouple E Thermocouple J Input type setting...
  • Page 17: Outline Drawings

    6. OUTLINE DRAWINGS 1) Q64TD Q64TD ERROR CH1+ CH2+ CH3+ CH4+ (FG) Q64TD 2(0.08) 112(4.41) 27.4(1.08) Unit: mm (in.) 2) Q64TDV-GH Q64TDV-GH ERROR CH1+ CH2+ CH3+ CH4+ (FG) Q64TDV 2(0.08) 112(4.41) 27.4(1.08) Unit: mm (in.)
  • Page 18 Warranty Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
