- Page 1 MSI MS-3871 Wireless 11b/g/n + Bluetooth BT2.1 EDR Combo Slim Module User’s Guide...
-
Page 2: Fcc Caution
FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 3: End Product Labeling
End Product Labeling This transmitter module is authorized only for use in device where antenna may be installed such that 20 cm may be maintained between antenna and users (for example access points, routers, wireless ADSL and similar equipment). The final end product must be labeled in a area with the following: “... - Page 4 Bluetooth Combo Slim Module, which can be used to integrate with such systems as notebook, mini-barebone, portable PC. With MSI MS-3871 embedded inside, a system could provide users with the ability and flexibility to connect up to Internet wirelessly via 802.11b/g/n with speed up to 150Mbps, and to link with peripherals wirelessly through Bluetooth v2.1 and...
- Page 5 >>> 1.2 How MS-3871 Works 1.2.1 In WLAN Environment Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
- Page 6 Internet, email, file transfer, and printer sharing. The scale and range of the Infrastructure networking are larger and wider than that of the Ad-hoc networking. MS-3871 MS-3871 WLAN+Bluetooth Combo Slim Module WLAN+Bluetooth Combo Slim Module...
- Page 7 Every Bluetooth device that provides a service must be prepared to respond to a connection request. Bluetooth soft- ware is always running in the background on the server, ready to respond to connection requests. MS-3871 WLAN+Bluetooth Combo Slim Module Bluetooth-enabled Devices...
-
Page 8: Specifications
>>> 1.3 Specifications Operation voltage 3.3V+/-10% Operating System Microsoft W indows XP 32/ 64-bit, ® ® Vista 32/64-bit, W in7 32/64-bit Environmental - Operating Temperature: Hardware 0 ~ 65 Specification - Operating Humidity: 10 ~ 90%, non-condensing Dimensions (W xDxH) 80 x 6 x 3 mm Weight 3.5g... - Page 9 Network Standard IEEE 802.11b/g/n Frequency Band 2.400-2.4835 GHz Data Rate IEEE 802.11b (auto-fallback): - CCK: 11, 5.5 Mbps - DQPSK: 2 Mbps - DBPSK: 1 Mbps IEEE 802.11g (auto-fallback): WLAN - OFDM: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps Specification IEEE 802.11n (auto-fallback):...
- Page 10 Channel IEEE 802.11g/n: Ch. 1-11 – N. America Ch. 1-13 – Japan Ch. 1-13 – Europe ET SI Ch. 10-11 – Spain Ch. 10-13 – France IEEE 802.11b: Ch. 1-11 – N. America Ch. 1-14 – Japan Ch. 1-13 – Europe ET SI Ch.
- Page 11 Network Standard Bluetooth v2.1 Class II +EDR Frequency Band 2.400 - 2.4835 GHz Data Rate Up to 3Mbps Channel 79 sub-channels Transmission FHSS (Frequency Hopping Spread Spectrum) Bluetooth Modulation n/4 DQPSK@2Mbps, 8DQPSK@3Mbps Specification Antenna Type PCB printed antenna Power Consumption 66mA in continuous Tx 8.6mA in standby mode Max.
-
Page 12: System Requirements
>>> 1.4 System Requirements Before installing MS-3871, your PC should meet the following items: - Windows XP 32/ 64-bit, Vista 32/64-bit, Win7 32/64-bit ® operating system. - Minimum 5MB free disk space for installing the driver and utilities. - One CD-ROM drive, double speed or higher. -
Page 13: Software Installation
Setup CD to copy files during the installation. Please NOTE that the MS-3871 should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to configure the new device. - Page 14 Insert the software CD into your CD-ROM drive, and the Setup ST EP program should launch automatically. If the Autorun program doesn’t launch automatically, click Start at the taskbar and select Run..Type (where E:\setup.exe your CD-drive) in the Open box and click OK to launch the Setup program manually.
- Page 15 Click the Install Bluetooth Driver button. ST EP The welcome screen of InstallShield Wizard appears. Click Next. Read and accept the License Agreement; then, click Next. Click Next to install the driver in the default destination folder. Click Install and the program will copy the necessary files to the system.
