INSTALLATION, USE AND MAINTENANCE INSTRUCTION
GB
SL51 fresco 1200 - SL35 fresco 1200
SL53 excel 900 - SL7 900 - SL7 1200 - SL19 900
SL22 900 - SLCR 83 - SL_EM41 - SLTC53 120
SLTC-EM53 90
TECHNICAL INFORMATION
TYPE: FSLA-FSLB-FSLC-FSLD
Advertisement
Related Manuals for Sirius Brand SL51 fresco 1200
Summary of Contents for Sirius Brand SL51 fresco 1200
- Page 1 COMMERCIAL INFORMATION FOR THE CONSUMER INSTALLATION, USE AND MAINTENANCE INSTRUCTION SL51 fresco 1200 - SL35 fresco 1200 SL53 excel 900 - SL7 900 - SL7 1200 - SL19 900 SL22 900 - SLCR 83 - SL_EM41 - SLTC53 120 SLTC-EM53 90...
- Page 3 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 4 CONTENTS Warnings Uses Installation Working Maintenance...
- Page 5 * Before carrying out any cleaning or main- WARNINGS taining operations, the appliance needs to be removed from the electric grid. If the ap- pliance is not provided with a non-separable flexible cable and plug, or with another de- vice ensuring omnipolar disconnections from “This appliance is not intended for use by the grid, with an opening distance between persons (including children) with reduced...
- Page 6 Connection external motor version. INSTALLATION In external motor version it is necessary to connect the cable of the external motor to the corresponding connection in the hood. If the connection from the external motor has two plugs, it is necessary to remove the cover Before installing the appliance, make sure of the bipolar connection before installation.
- Page 7 WORKING Mod. SL - Module - Luxury version (Fig. 13) A: Light switch on/off B: Motor switch on/off (1st rate level) C: 2nd rate level switch D: 3rd rate level switch E: 4th rate level switch F: 10-minute timer. Mod. SL TC - Touch Control version (Dis. 14) A: Light switch On/Off B: Reduce speed C: Luminous telltale...
- Page 8 * To replace the halogen lamps, remove first MAINTENANCE the glass-blocking ring (Fig. 11A), by leve- ring with a screw-driver and thus removing the opaque glass (Fig. 11B) - when perfor- ming this operation hold the opaque glass carefully. Remove the lamp (Fig. 11C) without * An accurate maintenance guarantees good touching it with uncovered hands.
- Page 9 WIRING DIAGRAM SL - EM41...
- Page 24 90000100053 - GM 07/12...
