Summary of Contents for Atomic Aquatics BC1
- Page 1 OWNERS MANUAL...
-
Page 2: Table Of Contents
Securing the weight pouches into the BC1 ...... 19 Warranty ................34 Tips for using the EZ-LOK weight system ......20 AT O M I C A QU AT I C S BC1 O W NE RS M A NU AL... -
Page 3: Bc1 Key Design Features
Congratulations… The New Atomic BC1 is for the diver who wants the absolute BEST World-Class BC available. As with every Atomic Aquatics product, we design it with the intention of redefining the product category. Just as we did with regulators, fins, masks and computers…we decided it was time to design the ultimate BC. -
Page 4: Bc1 Features
9. EZ-LOK weight pouches/ release handles 10. Waist strap and buckle 11. Cummerbund 12. Sand-resistant accessory pocket zippers 13. Power Inflator/SS1 AT O M I C A QU AT I C S BC1 O W NE RS M A NU AL... - Page 5 14. Chest strap 15. Shoulder strap/buckle 16. Right shoulder dump knob 17. Low pressure hose retainer 18. Low pressure hose 19. Corrugated hose 20. Right shoulder dump/ overpressure valve 21. Trim weight pockets 22. Lower rear dump knob 23. Lower rear dump/ OPR valve 24.
-
Page 6: Warranty Registration
If you are uncertain as to the meaning of this statement, contact your Atomic Aquatics Authorized Dealer or Atomic Aquatics for clarification. AT O M I C A QU AT I C S BC1 O W NE RS M A NU AL... -
Page 7: Precautions And Safety Information
This manual is intended to help acquaint you with the basic features and operation of the Atomic BC1, but it is impossible to provide you with all of the information and the hands-on training you need in order to use the product in a safe and enjoyable manner. -
Page 8: Adding Ballast
If you are unsure how to properly set up your weights, consult with a professional diving instructor for advice. AT O M I C A QU AT I C S BC1 O W NE RS M A NU AL... - Page 9 • NITROX – The Atomic BC1 is intended for use with compressed air or EAN (enriched air nitrox) containing not more than 40% oxygen. Use of other gas mixtures may pose a fire hazard or cause accelerated deterioration of materials used in the BC.
- Page 10 Ai Power Inflator SS1 Safe Second Inflator AT O M I C A QU AT I C S B C1 O WN E RS M ANUA L...
-
Page 11: High Performance Inflator Options
It is strongly recommended that your professional retailer or scuba repair technician do the final installation and check of the SS1 or Ai Power Inflator Attaching the inflator to the corrugated hose of the BC1 The corrugated hose attached to the left shoulder of... -
Page 12: Attaching The Low Pressure Hose With Quick Disconnect To The Regulator
The low pressure hose and quick disconnect is usually routed over the left shoulder where it follows the corrugated hose of your BC1. The low pressure port plug is removed by unscrewing with a 5/32 (4mm) hex wrench. Install the low pressure hose with quick disconnect into the port of choice and snug up with a wrench. -
Page 13: Ratcheting Cam-Lok Tank Band
High-pressure port Low pressure quick disconnect Low-pressure ports Ratcheting CAM-LOK tank band Yet another Atomic design exclusive. You will be amazed how easy this is to use, and how securely it holds your tank in place. The concept is similar to the bindings on ski boots and snowboards. The ratcheting band quickly adjusts to accommodate a variety of tank sizes and the over-center buckle locks everything tightly in place with an easy push. -
Page 14: Placement Of The Band In The Backpack
The tank band will fit all popular tank sizes up to 8" (203mm) diameter. The BC1 is shipped from the factory with the band in the position for a standard 80 Cu ft. (10 liter) tank. The band assembly does not need to be changed to accommodate different size tanks. -
Page 15: Tank Buckle Operation
Tank buckle operation The tank band is attached to the buckle, which is composed of 4 parts. The band itself, the link which attaches the band to the cam handle that opens or closes the buckle, the ratchet frame which is connected to the Ratchet Frame cam handle, and the ratchet lock that is used to adjust the band tension. - Page 16 To remove the band from the tank, lift open the cam handle. Depress the ratchet lock to loosen the band. You can loosen it just enough to lift off of the tank, or pull the tank band completely out of the buckle. Lift cam handle.
-
Page 17: Ez-Lok Integrated Weight Release System
In the event of an emergency you can choose to jettison one or both weight pouches, thereby creating more buoyancy. The weight pouches can be easily reloaded into the BC1 pockets while you are wearing the BC for use during training. -
Page 18: Loading The Ez-Lok Weight Pouches
The weight pouches can be filled with either hard “block” weights or lead-filled mesh “soft” weights. Regardless of the type of weight being used, fill each pouch with equal amounts of weight so the BC1 will be balanced in the water. -
Page 19: Securing The Weight Pouches Into The Bc1
Securing the weight pouches into the BC1 Each weight pouch will fit into either left or right weight pocket on the BC1. With the fabric side of the pouch facing out, slide the pouch into the pocket and push it in until you hear or feel it “SNAP” or “click” into place. To confirm that it is locked in place, tug on the small webbing test tab on the front of the pocket. -
Page 20: Tips For Using The Ez-Lok Weight System
You may choose to install the weights before donning the BC1 or afterwards, whichever works best for you. The weight pouches will load and unload easier if the BC1 is not fully inflated. The weight pouches can be easily removed in the water or swim step and handed to someone on board to assist in getting out of the water. -
Page 21: Non-Releasable Trim Weight Pockets
Don’t pull on the handle to test it or it will release. Non-releasable trim weight pockets On the rear of the BC1 you will see two pocket flaps for non- releasable weights. Each pocket holds up to 5 lbs. (2.2 Kg) - 3 lbs. on the small size. These are used to ‘balance”... -
Page 22: Maximum Weight Capacity
Maximum weight capacity The maximum lift capacity of the BC1 is listed on the permanent label attached to it, usually on the waist band or pocket. AT OM I C A Q U AT I C S B C1 O W NE RS M ANU AL... -
Page 23: Pre-Dive Inspection
Pre-Dive Inspection You should inspect your BC and its associated equipment before leaving for your dive destination. If in the event you find something that needs attention, this could provide time to remedy the issue and perhaps avoid the disappointment of having to cancel a dive after you have reached your destination. -
Page 24: Accessories
Accessories 10 D-Rings The BC1 has a total of 10 triangular shaped D–rings in various locations to accommodate a variety of possible accessories. Heavy duty 1-1/2" 316 Stainless Steel rings with Titanium PVD coating are located on the shoulders and top edge of the pockets. -
Page 25: Accessory Pockets With Sand-Resistant Zippers
Underneath the arms and directly over the weight pockets are the zippered accessory pockets. They are in an easy-to- access location and maintain their volume even when the BC1 is inflated. The zippers are water resistant and protect the teeth from sand and debris. -
Page 26: Fitting The Bc1
Fitting the BC1 The BC1 comes in a variety of sizes to fit a wide range of men and women wearing a variety of exposure suit types. All the straps have adjustable length sliding buckles. Once you have selected the basic size appropriate for you, the waistband can be further adjusted if too long or too short. -
Page 27: Waistband Adjustment
Both the cummerbund and the overlapping webbing waist strap can be shortened or lengthened. To change the cummerbund length, place the BC1 backpack down and open it to expose the lumbar pad. Fold back the lumbar pad and you will see the end of the cummerbund looped through... -
Page 28: Lumbar Adjustment
The plastic lumbar plate has about 1-1/2" of vertical adjustment. The plates are factory set for the specific size of the BC1. However, they can be repositioned. Grasp the lumbar pad and, using a ¼" hex wrench, loosen the lower back plate bolt just enough until you can slide the plate up or down. -
Page 29: Operation
BC1 and depress the large deflation button. If you are face down, the inflator will be lower than the air bubble in the BC1 and it will not vent. Overpressure relief valves: There are 3 combination overpressure/dump valves on the BC1. - Page 30 BC1. A cable inside the inflator hose is attached to the combination overpressure/dump valve in the module where the hose is attached to the BC1. Do not pull or stretch the inflator hose unless you deliberately intend to vent the BC1. The valve will open without excessive force and it only requires less than one half inch of travel.
- Page 31 On the back of the BC1 on the lower right side is a manual dump valve with a short cable and anti-floating pull knob. Pull this knob to vent the BC1 if in an inverted upside down position. CAUTION The proper function of either overpressure relief valve is vital to prevent damage to the BC bladder.
-
Page 32: Post Dive Cleaning
Leave the zippered weight pouches and accessory pockets unzipped until dry. 4. Fill the BC1 bladder about 1/4 of the way with clean fresh water through the oral inflation mouthpiece. Inflate the BC and shake to rinse inside the BC. Hold the BC upside down, depress the deflation button on the oral inflator, and drain the water out of the bladder. -
Page 33: General Care
6. Routine Service Checks It is highly recommended the BC1 be checked annually by an authorized dealer for air leakage, condition of the hoses and general operation. This process generally is a simple inspection and can prevent your having to cancel a dive due to an operational problem you may not recognize with your BC. -
Page 34: Warranty
Atomic Aquatics shall not be liable for loss of use of this product or incidental or consequential costs or damages incurred with the use of this BC1 Buoyancy Compensator. Some states do not allow this exclusion so the above may not apply to you. - Page 35 Special note on Rental use: This warranty does not extend to commercial or rental use. BCs used for rental/diving centers, professional purposes or other intensive use must be checked at least every 6 months by a qualified professional dive equipment technician. The conditions of the primary components necessary for safe operation such as the bladder, overpressure valves, elbows, weight system and corrugated hose, must be inspected.
- Page 36 Toll Free: (888) 270-8595 www.atomicaquatics.com...
