HLK-WIIF-M04 is the new third-generation
embedded Uart-Wifi modules studied by
Shenzhen Hi-Link ElectronicTechnology
co.,Ltd
Uart-Wifi is an embedded module based
on the Uart serial,according with the WiFi
wireless WLAN standards, It accords with
IEEE802.11 protocol stack and TCP / IP
protocol stack ， and it enables the data
conversion between the user serial and the
wireless
network
Uart-Wifi
module,
devices can easily access to the wireless
network.
HLK-WIIF-M04 does a comprehensive
hardware and software upgrades based on
the products of the first two generations,now
it's more functional and more Convenient to
use,its main features include,
 Support transparent transmission of
serial completely,and achieve a plug
and play serial.
 Support new AT+instruction set,
深圳市海凌科电子有限公司 Shenzhen Hi-Link ElectronicTechnology co.,Ltd
Http: //www.hlktech.com
module.
through
the
traditional
serial
Tel: +86-0755-83575155
Characteristic
Interface
 RS232(DB9 Male)
 The range of baud rate: 1200~
115200bps
 single 5V power supply
Wireless
 support IEEE802.11b/g wireless
standards
 support
2.412~2.484 GHz
 support two types of wireless
networks:
Ad hoc and Infrastructure
 support
cation mechanisms:
WEP64/WEP128/ TKIP/CCMP(AES)
WEP/WPA-PSK/WPA2-PSK
 support quick networking
the
 support wireless roam
O
thers
 support multiple network protocols:
TCP/UDP/ICMP/DHCP/DNS/HTTP
 support two types of work modes:
auto and command
 Support transparent transmission
mode
 support AT+ instruction set
Fax: +86-0755-83575189
the
range
of
frequency:
multiple
security
authenti-
