- Page 1 SNP-ELU520, SNP-ELH500, SNP-ELW500 & SNP-ELX550 USER MANUAL...
-
Page 2: Table Of Contents
Table of Contents Appendices ........46 Table of Contents ......2 Usage Notice ........3 Compatibility Modes ......46 RS232 Commands and Protocol Safety Information .......3 Function List ........50 Precautions .........4 RS232 Port Setting ......50 Introduction ........6 RS232 Signals Connection ....50 Package Overview ......6 Commands Set List ...... -
Page 3: Usage Notice
Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Precautions
Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user�s guide. ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture. - Page 5 Usage Notice Turn off and unplug the power plug from the AC outlet before cleaning the product. Use a soft dry cloth with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is ...
-
Page 6: Introduction
Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. VGA Cable Projector Power Cord Due to different applications in each country, some regions may have... -
Page 7: Product Overview
Introduction Product Overview Main Unit The interface is subject to model’s specifications. 1. Control Panel 6. Speakers 2. Focus Switch 7. Power Socket 3. Ventilation (inlet) 8. Input / Output 4. IR Receiver Connections 5. Ventilation (outlet) 9. Lens English... -
Page 8: Control Panel
Introduction Control Panel 1. Power LED 2. Enter 3. Temp LED 4. Lamp LED 5. Menu 6. Input 7. Four Directional Select Keys 8. Power/Standby button 9. IR Receiver English... -
Page 9: Input/Output Connections
Introduction Input/Output Connections F1 F2 11 10 14 15 16 Microphone HDBaseT Audio I/P VGA I/P AC Inlet Audio O/P 3D VESA VGA O/P Wired Remote HDMI 1 12V Trigger HDMI 2 Kensington Lock RS232 DCE mini USB USB Power HDMI USB Power English... -
Page 10: Remote Control
Introduction Remote Control Infrared transmitter Power On/Off P-Source P-Size Four Directional Select Keys Exit Menu Keystone (Horizontal/ Vertical) Video Mode Aspect Zoom- Re-sync HDMI-2 P-Swap P-Location Enter Mute Volume +/- Blank Freeze HDMI-1 HDBaseT Zoom+ Dongle P-Function English... -
Page 11: Installation
Installation Connecting the Projector Connect to Computer/Notebook MOLEX Router / Network Switch Due to the difference in Microphone applications for each country, some regions may External Display have different accessories. Audio Output (*) Optional accessory 1....................*RS232 Cable 2.....................VGA Cable 3....................*HDMI Cable 4....................*USB Cable 5....................*Audio Cable 6.................... -
Page 12: Connect To Video Sources
Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Microphone Due to the difference in applications for each country, some regions may have different accessories. (*) Optional Audio Output accessory 1....................*HDMI Cable 2....................*Audio Cable 3....................Power Cord 4....................*Audio Cable 5..................*Audio Input Cable English... -
Page 13: Powering The Projector On / Off
Installation Powering the Projector On / Off Powering On the Projector 1. Securely connect the power cord and signal cable. When connected, the POWER/STANDBY LED will turn Red. 2. Turn on the lamp by pressing “ ” button either on the projector or on the remote. -
Page 14: Powering Off The Projector
Installation Powering Off the Projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 10 seconds. -
Page 15: Adjusting The Projected Image
Installation Adjusting the Projected Image Adjusting the Projector�s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projector or counter clockwise to lower it. -
Page 16: Adjusting The Projector�S Focus
Installation Adjusting the Projector�s Focus To focus the image, slide the focus switch to left/right until the image is clear. XGA series: The projector will focus at distances (lens to wall) from 3.28~31.50 feet (1.00~9.60 meters). WXGA series: The projector will focus at distances (lens to wall) from 8.86~26.57 feet (2.70~8.10 meters). -
Page 17: Adjusting Projection Image Size (Diagonal)
Installation Adjusting Projection Image Size (Diagonal) XGA & WXGA series: Projection Image Size from 30” to 300” (0.91~9.09 meters). 1080P & WUXGA series: Projection Image Size from 36” to 300” (1.09~9.09 meters). Top View Screen Screen (W) Projection Distance (D) Width Screen (H) Screen... - Page 18 300" 664.0 374.0 261.4 147.2 790.0 311.0 122.5 122.5 48.2 48.2 image size Screen Size WxH Projection Distance (D) Offset (Hd) SNP-ELU520 inch inch inch inch Diagonal Width Height Width Height Wide Tele Wide Tele Wide Tele Wide Tele 36"...
-
Page 19: User Controls
User Controls Control Panel & Remote Control Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” POWER section on pages 13-14. Enter Press “Enter” to confirm your item selection. INPUT Press “INPUT” to select an input signal. Press “MENU”... -
Page 20: Remote Control
User Controls Remote Control Using the Remote Control Infrared transmitter Sends signals to the projector. Refer to the “Power On/Off the Projec- Power tor” section on pages 13-14. Set PIP/PBP Function Main/Sub P-Source Source P-Function Set PIP/PBP Function On/Off P-Swap Swap PIP/PBP Main/Sub Source P-Size Set PIP Sub Source Size... -
Page 21: Using The Remote Control
User Controls Using the Remote Control Select the display mode from Bright, Video Mode PC, Movie, Game, Blending and User. Momentarily turns off/on the audio and Blank video. Zoom in Zoom in the projector display. Zoom out Zoom out the projector display. Pause the screen image. -
Page 22: On-Screen Display Menus
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad. -
Page 23: Picture
User Controls Picture Color Mode There are many factory presets optimized for various types of im- ages. Use the ◄ or ► button to select the item. Bright: For brightness optimization. Presentation: For meeting presentation. Movie: For playing video content. ... -
Page 24: Dynamic Black
User Controls Contrast The Contrast controls the difference between the lightest and dark- est parts of the picture. Adjusting the contrast changes the amount of black and white in the image. Press the ◄ button to decrease the contrast. Press the ►... -
Page 25: Screen
User Controls Screen Aspect Ratio Auto: Keep the image with original width-height ratio and maxi- mize the image to fit native horizontal or vertical pixels. 4:3: The image will be scaled to fit the screen and displayed using a 4:3 ratio. 16:9: The image will be scaled to fit the width of the screen and ... -
Page 26: Geometric Correction
User Controls Digital Zoom Press the ◄ button to reduce the size of an image. Press the ► button to magnify an image on the projection screen. Projection Front: The image is projected straight on the screen. Front Ceiling: This is the default selection. -
Page 27: Setting
User Controls Setting Language Choose the multilingual OSD menu. Press the ◄ or ► button into the sub menu and then use the ▲ or ▼ button to select your preferred language. Press ► on the remote control to finalize the selection. - Page 28 User Controls Test Pattern Display a test pattern. Reset Choose “Yes” to return the parameters on all menus to the factory default settings. English...
-
Page 29: Volume
User Controls Volume Speaker Choose “On” to enable the speaker. Choose “Off” to disable the speaker. Line Out Choose “On” to enable the line out function. Choose “Off” to disable the line out function. Microphone Choose “On” to enable the microphone. ... -
Page 30: Options
User Controls Options Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered Default: The default startup screen. User: Use stored picture from “Logo Capture” function. ... - Page 31 User Controls Auto Power Off (Min) Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes). SSI Settings Refer to page 32.
-
Page 32: Options | Laser Settings
User Controls Options | Laser Settings Laser Hours Used (Normal) Display the projection time of normal mode. Laser Hours Used (ECO) Display the projection time of ECO mode. Laser Power Mode Normal: Normal mode. ECO: Use this function to dim the projector SSI which will lower ... - Page 33 User Controls “Frame Sequen- Auto: When a HDMI 1.4a 3D timing identification signal is de- tial” is supported tected, the 3D image is selected automatically. the DLP Link 3D input signals from Choose “On” to enable 3D function. VGA / HDMI con- Choose “Off”...
-
Page 34: Blending Mode
User Controls Blending mode Brightness For user to manually adjust the brightness of projectors used in blending mode. Color Temp For user to manually map the color temperature of projectors used in blending mode. Blending application System Architecture Calibration Camera Network Switch Laptop Laptop... -
Page 35: Lan
User Controls Status Display the network connection status. DHCP Configure the DHCP settings. On: Choose “On” to let the projector to obtain an IP address automatically from your network. Off: Choose “Off” to assign IP, Subnet Mask, Gateway, and DNS ... - Page 36 User Controls Group Name Display the group name. Projector Name Display the projector name. Location Display the projector location. Contact Display the contact information. English...
- Page 37 User Controls How to use web browser to control your projector 1. Turn on DHCP to allow a DHCP 4. Based on network web-page for the server to automatically assign an IP, or input-string in [tools] tab, the limitation manually enter the required network for Input-Length is in the below list information.
- Page 38 User Controls 1. When making a direct connection from your computer to the projector Step 1: Find an IP Address (192.168.0.100) from LAN function of projector. Step 2: Select apply and press “Enter” button to submit function or press “menu” key to exit.
- Page 39 User Controls 2. Access to Web Management Page Open IE browser and type in the IP address 192.168.0.100 in the URL then press “Enter” key and key in password to enter Web Management page System Status User can retrieve the System Status in this page English...
- Page 40 User Controls General Setup User can configure general parameters in this page. Projector Control User can configure the projector parameters and control the projector in this page. English...
- Page 41 User Controls Network Setup User can configure LAN parameters in this page. Alert Setup User can assign the email address and categorize alert notice. English...
- Page 42 User Controls Reset to Default User can use this function to set the LAN module parameters to default values. Reboot System User can use this function to re-boot the LAN module. English...
- Page 43 User Controls Crestron User can control projector via Crestron flash UI. English...
-
Page 44: Crestron Roomview Control Tool
User Controls Crestron RoomView Control Tool Crestron RoomView™ provides a central monitoring station for 250+ control systems on a single Ethernet network (more are possible, the number depends on the combination of IP ID and IP address). Crestron RoomView monitors each projector, including projector’s online status, system power, lamp life, network setting and hardware faults, plus any custom attribute as defined by the Administrator. - Page 45 User Controls 3. Edit Attribute 4. Edit Event For further information, please visit: http://www.crestron.com & www.crestron.com/getroomview. English...
-
Page 46: Appendices
Appendices Compatibility Modes A. VGA Analog (1) PC Signal V.Frequency H.Frequency Pixel CLK Modes Resolution EDID Description [Hz] [KHz] [MHz] 640x480 31.5 Established Timings 1 25..2 640x480 35.0 26.8 Established Timings 1 640x480 37.9 Established Timings 1 31.5 640x480 37.5 Established Timings 1 31.5 640x480... - Page 47 Appendices WXGA: (Native)Detailed Timing / 1280x800 49.6 83.5 Descriptor Block 1 XGA: Standard Timing Identification 1366x768 47.7 84.8 1440x900 59.9 106.5 Standard Timing Identification WXGA: Standard Timing Identification WSXGA+ 1680x1050 65.3 146.3 XGA: N/A 1920x720 44.35 92.25 (3) Component Signal 720x480 480i 59.94(29.97)
- Page 48 Appendices WXGA: Established Timings 2 XGA: Established Timings 2 1024x768 48.4 65.0 and (Native)Detailed Timing / Descriptor Block 1 1024x768 56.5 75.0 Established Timings 2 1024x768 60.0 78.8 Established Timings 2 1024x768 68.7 94.5 1024x768 99.0 137.8 Standard Timing Identification Apple, Mac II 1152x870 68.7...
- Page 49 Appendices Short Video Descriptor of CEA EDID 1080i 1920x1080 60(30) 33.8 74.25 Timing Short Video Descriptor of CEA EDID 1080i 1920x1080 50(25) 28.1 74.25 Timing Short Video Descriptor of CEA EDID 1080p 1920x1080 23.98/24 27.0 74.25 Timing Short Video Descriptor of CEA EDID 1080p 1920x1080 67.5...
-
Page 50: Rs232 Commands And Protocol Function List
Appendices RS232 Commands and Protocol Function List RS232 Port Setting Items Method Communication Method Asynchronous Communication Bits per seconds 19200 Data bits 8 bits Parity None Stop bits Flow control None RS232 Signals Connection RS232 shell is grounded. Computer COM Port Projector COM Port (D-Sub 9pin connector) -
Page 51: Commands Set List
Appendices Commands Set List Command Projector ASCII Code n value Note Description Return 0 : Off Power #0000 n 1 : On 1 : Up 2 : Left 3 : Right 4 : Down 5 : Menu Emulate Remote #0001 n 6 : Source 7 : V. - Page 52 Appendices 1 : Auto 2 : 4:3 Aspect Ratio #0020 n 3 : 16:9 4 : 16:10 / Ultra Wide 0 : Zoom- Zoom #0021 n 1 : Zoom+ Keystone #0022 n -40~40 1 : Front 2 : Rear Ceiling Mount #0023 n 3 : Front Ceiling 4 : Rear Ceiling...
- Page 53 Appendices Microphone #0042 n 0~30 Volume Auto Power Off #0050 n 0~120 Step = 5 (min) 0 : Off High Altitude #0051 n 1 : On n : 1/2/3/4/5/6/7 = Color Mode Bright / Presentation / #00110 1 Read Movie / RGB/ Blending / DICOM/User n : 1/2/3/4 = Auto / 4:3 Aspect Ratio...
-
Page 54: Regulation & Safety Notices
Appendices Regulation & Safety Notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. -
Page 55: Operation Conditions
Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. - Page 56 Appendices Safety notice LASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT WAVE LENGTH: 450-460 nm / MAX OUTPUT: 15.9 mW / PULSE DURATION: 1.25 ms IEC 60825-1:2014 CLASS 1 LASER PRODUCT / RISK GROUP 2 Possibly hazardous optical radiation emitted from this product. Do not stare into the beam, May be harmful to the eyes.
- Page 57 MFG: Sonnoc (Beijing) Technology Co.,Ltd. Address: Room 806, Floor 7, Building 5, Desheng Zhiye Building, No 26 Huangsi Street, Xicheng District, Beijing 100120, China Postcode:100120 Fax: 010-82075080 Tel: 400-898-5393 Website: www.sonnoc.cn...
